Anest Iwata W-400 Instruction Manual

Ｉ Ｎ Ｓ Ｔ Ｒ Ｕ Ｃ Ｔ Ｉ Ｏ Ｎ ＭＡ Ｎ Ｕ Ａ Ｌ
Spray Gun
W-400
Main Specifications Maximum Working Pressure
Noise level (LAeqT)
Temperature range
Model Type of
feed
W-400-122G
W-400-132G
W-400-142G
Gravity
W-400-162G
W-400-182G
W-400-251G
※ 1 . Atomizing air pressure means air pressure at gun inlet when trigger is pulled and air flows．
■ PARTS LIST
№
Description
1 Air cap set
◆
2 Fluid nozzle-fluid needle set
◆
2-1 Fluid nozzle
◆
2-2 Fluid needle set
◆
3 Needle packing set
4 Needle packing seat
5 Body set
5-1 Air nipple
5-2 Fluid nipple
6 Pattern adj. set
7 Air valve seat set
◆
7-1 O ring
◆
8 Air valve
9 Air valve spring
10 Fluid adj. guide
11 Fluid needle spring
12 Fluid adj. knob
◆
13 Air valve shaft
14 Air adj. set
15 Trigger stud
16 Trigger
17 E stopper
18 Filter
19 Brush
20 Instruction manual
When ordering parts, specify gun's model, part name with ref.
No. and marked No. of air cap set, fluid nozzle and fluid needle.
◆ Marked parts are wearable parts.
和文取説は、 裏面にあり ます
(For Oversea's Sales)
６ .８ bar (９ ８ PSI)
７ ９ .７ dB(A)
５ 〜４ ０ ℃
※1 Nozzle Air cap set ※2 Atomizing
orifice
φmm(in)
1.2 (0.047)
1.3（ 0.051）
LV2
1.4 (0.055)
1.6 (0.063)
1.8 (0.071) LV1
2.5(0.098) W1
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
This manual contains IMPORTANT
WARNINGS and INSTRUCTIONS.
Equipment in this manual is exclusively for painting
purposes.
Do not use for other purposes.
The operator shall be fully conversant with the
requirements stated in this instruction manual including
important warnings, cautions and operation and correct
handling.
Read and understand the instruction manual, before
use and retain for reference.
Fluid
air pressure output consumption
bar (PSI) ml/min l/min(cfm)
2.0 (29) 140 280 (9.9)
3.0 (43) 160 370(13.1)
2.0 (29) 160 280 (9.9)
3.0 (43) 200 370(13.1)
2.0 (29) 210 280 (9.9)
3.0 (43) 265 370 (13.1)
2.0 (29) 240 280 (9.9)
3.0 (43) 310 370 (13.1)
2.0 (29) 320 290 (10.2)
3.0 (43) 400 380 (13.4)
3.0 (43) 580 360 (12.7)
− 1 −
Air Pattern width
Spray
mm(in)
distance
175(6.9) 150(5.9)
250(9.8) 250(9.8)
225(8.8) 150(5.9)
300(11.8) 250(9.8)
255(10.0) 200(7.9)
320(12.6) 250(9.8)
270(10.6) 200(7.9)
340(13.4) 250(9.8)
250(10.2) 200(7.9)
320(12.6) 250(9.8)
340(13.4) 250(9.8)
Fluid nozzle-fluid needle set combination
Fluid nozzle
Orifice
φmm(in)
φ1.2(0.047)
φ1.3(0.051)
φ1.4(0.055)
φ1.6(0.063)
φ1.8(0.071)
φ2.5(0.098)
Weight
g(lbs)
380(0.84)
Fluid needle set
Mark Mark
W200/12 40012
W200/13
20015
W400/14
W400/16
W200/18 W20018
W200/25 W20025
