YASKAWA AC Drive J1000

Compact V/f Control Drive

Quick Start Guide

Type: CIMR-JC

Models: 200 V Class, Three-Phase Input: 0.1 to 5.5 kW

200 V Class, Single-Phase Input: 0.1 to 2.2 kW

400 V Class, Three-Phase Input: 0.2 to 5.5 kW

To properly use the product, read this manual thoroughly

and retain for easy reference, inspection, and maintenance.

Ensure the end user receives this manual.

MANUAL NO. TOEP C710606 27A

Table of Contents

Need help?

Do you have a question about the CIMR-JC and is the answer not in the manual?

Questions and answers

Summary of Contents for YASKAWA CIMR-JC

Page 1 YASKAWA AC Drive J1000 Compact V/f Control Drive Quick Start Guide Type: CIMR-JC Models: 200 V Class, Three-Phase Input: 0.1 to 5.5 kW 200 V Class, Single-Phase Input: 0.1 to 2.2 kW 400 V Class, Three-Phase Input: 0.2 to 5.5 kW To properly use the product, read this manual thoroughly and retain for easy reference, inspection, and maintenance.
Page 2 YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide...
Page 3: Table Of Contents
3 Electrical Installation ............9 4 Keypad Operation .............. 16 5 Start Up ................18 6 Parameter Table ..............22 7 Troubleshooting..............25 8 Instructions for UL and cUL..........28 YASKAWA Electric TOEP C710606 27A AC Drive - J1000 Quick-Start-Guide...
Page 4: Safety Instructions And General Warnings
Yaskawa must be supplied to the end user with appropriate warnings and instructions as to the safe use and operation of that part. Any warnings provided by Yaskawa must be promptly provided to the end user. Yaskawa offers an express warranty only as to the quality of its products in conforming to standards and specifications published in the manual.
Page 5 • Do not attempt to modify or alter the drive in any way not explained in this manual. Failure to comply could result in death or serious injury. Yaskawa is not responsible for any modification of the product made by the user. This product must not be modified.
Page 6 • Do not carry the drive by the front cover. Failure to comply may result in minor or moderate injury from the main body of the drive falling. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide...
Page 7 • Do not modify the drive circuitry. Failure to comply could result in damage to the drive and will void warranty. Yaskawa is not responsible for modification of the product made by the user. This product must not be modified.
Page 8 Ground the neutral point of the main power supply for 400 V Class drives. Precautions for UL/cUL Standards Compliance This drive is tested in accordance with UL standard UL508C and complies with UL require- ments. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide...
Page 9: Mechanical Installation
1000 m or less Vibration 10 - 20 Hz at 9.8 m/s , 20 - 55 Hz at 5.9 m/s Orientation Install the drive vertically to maintain maximum cooling effects. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide...
Page 10 67.5 2A0004 38.5 99.5 2A0006 58.5 119.5 2A0010 120.5 2A0012 137.5 2A0020 134.5 4A0001 72.5 4A0002 90.5 4A0004 137.5 4A0005 145.5 4A0007 145.5 4A0009 145.5 4A0011 134.5 YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN10...
Page 11: Electrical Installation
0 to +10 Vdc (2mA) (default setting) (Output frequency) Analog input Symbols: Indicates a main circuit terminal Use twisted pair cables Indicates a control circuit terminal. Use shielded twisted pair cables YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN11...
Page 12 M3.5 M3.5 2A0006 FS23637-8-07 M3.5 M3.5 M3.5 2A0010 FS23637-14-07 2A0012 FS23637-14-07 2A0020 FS23637-24-07 4A0001 FS23639-5-07 4A0002 FS23639-5-07 4A0004 FS23639-5-07 4A0005 FS23639-10-07 4A0007 FS23639-10-07 4A0009 FS23639-10-07 4A0011 FS23639-15-07 YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN12...
Page 13 A6T40 FWH-90B Three-Phase 400 V Class 4A0001 A6T3 FWH-40B 4A0002 A6T6 FWH-40B 4A0004 A6T15 FWH-50B 4A0005 A6T20 FWH-70B 4A0007 A6T25 FWH-70B 4A0009 A6T25 FWH-90B 4A0011 A6T30 FWH-90B YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN13...
Page 14 Cable shield cable grounding clamp grounding clamp cable Ground shield at Ground shield at motor side motor side EMC Standards Compliant Wiring of Single- and Three Phase Units YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN14...
Page 15 16 mm (Al). –The power supply must be disconnected automatically in case of discontinuity of the protective earthing conductor. • Keep ground wires as short as possible. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN15...
Page 16 DC power supply input For connecting a DC power supply. For 200 V class: Ground with 100 Ω or less Ground Terminal For 400 V class: Ground with 10 Ω or less (2 terminals) YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN16...
Page 17 250 Vac, 10 mA to 1 A Digital output common Output AM Analog monitor output 0 to 10 Vdc (2 mA or less), Resolution: 1/256 (8 bit) Monitor Output Monitor common YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN17...
Page 18: Keypad Operation
On: The output frequency is displayed on the data screen. FOUT FOUT LED Light Off: Anything else than the output frequency is displayed on the data screen. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN18...
Page 19 In the Parameter Setting Mode all Parameter Setting Mode drive parameters can be set up. <1> Switching to reverse: The LED is lit when LOCAL is selected YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN19...
Page 20: Start Up
Connect the load, run the motor and check the operation Fine tune and set application parameters if necessary. Final check the operation and verify the settings. Drive is ready to run the application YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN20...
Page 21 If the drive is operated in the REMOTE mode, make sure that the correct sources for the fre- quency reference and Run command are set in parameters b1-01/02 and that the drive is in the REMOTE mode. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN21...
Page 22 Analog input Apply the frequency reference signal to terminal A1. Serial Communica- RS232C or RS422/485 Memobus communication tions Option Potentiometer Option Potentiometer Option YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN22...
Page 23 After taking the steps listed above, the drive should be ready to run the application and per- form the basic functions. For details about more advanced setup refer to the technical man- ual. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN23...
Page 24: Parameter Table
0: Heavy Duty (HD) b2-02 rent as a percentage of the drive Normal/ Braking Constant torque applications rated current. C6-01 Heavy Duty Current 1:Normal Duty (ND) Selection Variable torque application YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN24...
Page 25 E2-02 Motor rated slip in hertz (Hz). Motor Sets the motor overload protection Rated Slip L1-02 Overload time in min. Normally no change is Prot. Time necessary. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN25...
Page 26 Minor fault (Alarm) (ON: Alarm displayed) (terminal S2 enabled) U1-10 1: Digital input 3 (terminal S3 enabled) 1: Digital input 4 (terminal S4 enabled) 1: Digital input 5 (terminal S5 enabled) YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN26...
Page 27: Troubleshooting
• The load is too heavy. Overcurrent • The accel./decel. times are too short. • Wrong motor data or V/f pattern settings. • A magnetic contactor was switched at the output. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN27...
Page 28 • The power supply failed or one input phase has been lost. • The power supply is too weak. DC Charge Circuit Fault The charge circuit for the DC bus is broken. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN28...
Page 29 • Correct the values set to b1-01 and b1-02. • b1-02=2 oPE10 • Check the V/f pattern settings. The V/f pattern setting is incorrect. • Refer to the instruction manual for more details. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN29...
Page 30: Instructions For Ul And Cul
Do not install the drive to an area greater than pollution severity 2 (UL standard). Main Circuit Terminal Wiring Yaskawa recommends using UL-listed copper wires (rated at 75°C) and closed-loop connec- tors or CSA-certified ring connectors sized for the selected wire gauge to maintain proper clearances when wiring the drive.
Page 31 75°C 600 V UL approved vinyl sheathed insulation. Ambient temperature should not exceed 30°C. Input Fuse Selection Use the fuses listed up in the table on page 11 when wiring the main circuit. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN31...
Page 32 (A1-02 = 2 or 3). The motor protection parameter L1-01 is set as factory default. Set E2-01 to the full load amps (FLA) stamped on the nameplate of the motor. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN32...
Page 33 − when running at 100% load. The OL1 function does not derate the motor at any speed. Setting L1-01 = 4 selects protection for a PM motor. YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN33...
Page 34 Ramp to Stop Coast to Stop Fast-Stop Alarm Only (factory default) L1-04 Motor Overload Fault Operation Selection Setting Description Ramp to Stop Coast to Stop (factory default) Fast-Stop YASKAWA Electric TOEP C710606 27 AC Drive - J1000 Quick Start Guide EN34...
Page 35 Revision History The revision dates and numbers of the revised manuals are given on the bottom of the back cover. MANUAL NO. TOEP C710606 27A Published in Japan June 2009 08-1 Revision number Date of original publication Date of publication Date of Publication Rev.
Page 36 Specifications are subject to change without notice for ongoing product modifications and improvements. © 2008 YASKAWA ELECTRIC CORPORATION. All rights reserved. MANUAL NO. TOEP C710606 27A Published in Japan...
