VS mini J7 to J1000 Replacement Instructions
1
Applicable Drives .................................................................................................................2
2
Drive Replacement Checklist...............................................................................................2
3
Terminals ..............................................................................................................................4
3.1
Main circuit terminals ..................................................................................................4
3.2
Control Terminals, Signal Levels.................................................................................4
3.3
DIP Switches...............................................................................................................4
3.4
Main Terminal Size/ Electric Wire Differences............................................................5
3.5
Control terminal sizes and wire sizes .........................................................................6
4
Dimensions...........................................................................................................................7
5
Options Replacement...........................................................................................................8
6
Parameter Settings ..............................................................................................................9
6.1
J7 to J1000 Parameter Correspondence for Drive Replacement............................9
6.2
J7 and J1000 Differences in Parameter Settings .....................................................14
6.3
Replacement of J7 Drives with Special Software .....................................................15
7
Rated Power, Current and Carrier Frequency ...................................................................15
Revision History .......................................................................................................................16
-- Contents --
VAN-V07007E [J7→J1000] Replacement Instructions
Yaskawa Electric Corporation
Marketing Sect. Marketing Dept.
Drives Division
1/16
