OPERATION MANUAL / SPARE PARTS LIST
BATTERY - POWERED
PLASTIC STRAPPING TOOL
MODEL P318
43.0830.01
CE Declaration of conformity
We declare that the machine P318
is in conformity with the following standard or
standardised documents:
2006/42/EC,
2004/108/EC
Technical file at:
M.Rauch
FROMM System GmbH
Neulandstrasse 10
D-77855 Achern
3.11.2009
R.Fromm
Director
FROMM Holding AG
Hinterbergstrasse 26
CH - 6330 Cham
For Parts & Service 1-877-862-6699

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P318 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fromm P318

Summary of Contents for Fromm P318

  • Page 1 OPERATION MANUAL / SPARE PARTS LIST BATTERY - POWERED PLASTIC STRAPPING TOOL MODEL P318 43.0830.01 CE Declaration of conformity We declare that the machine P318 is in conformity with the following standard or standardised documents: 2006/42/EC, 2004/108/EC Technical file at: M.Rauch...

  • Page 2: Table Of Contents

    INDEX PAGE GENERAL SAFETY RULES SAFETY RULES FOR STRAPPING TOOLS TECHNICAL DATA ACCESSORIES Battery ............7 Battery - chargers .

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/ or serious injury. The term "power tool" in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. SAVE THESE INSTRUCTIONS.
  • Page 4 1.4 Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.

  • Page 5: Safety Rules For Strapping Tools

    Use only cutters designed for strap and never hammers, pliers, hacksaws, axes, etc. 2.6 Environment protection Do not dispose of used batteries in the household refuse, water or by burning them. FROMM distributors offer an environment friendly battery disposal service. P318manen-12.fm For Parts & Service 1-877-862-6699...

  • Page 6: Technical Data

    Description of the tool The tool model P318 has been designed to strap packages with plastic strapping. The plastic strapping is fed around the package manually or in combination with a strap feeder. The straps are inserted in the tool, automatically tensioned, sealed by friction welding and separated.

  • Page 7: Accessories

    ACCESSORIES Use only parts and accessories mentioned in the operating instruction. Using other parts or accessories can cause injuries to you and other persons. Battery N5.4328 N5.4330 The battery is not automatically supplied with the tool. The battery has to be ordered separately under the following item numbers.

  • Page 8: Wearing Plate

    P32.0168 must be used. P32.0168 Suspension When working stationary the P318 can be suspended at a spring loaded balancer by using a suspension bracket. For working in normal position a stiff suspension bracket with screws and washers can be ordered under item number P32.0112.

  • Page 9: Turning Button Kit

    For working in alternating positions a turnable suspension bracket with screws and washers can be ordered under item number P32.0137. P32.0137 N1.1904 N1.6503 P32.1307 P32.1310 P35.2069 P35.2073 N2.5623 Mobilux EP2 N1.5105 Turning button kit For a remaining adjustment of tension force and welding time. After exchanging of the turning buttons the adjustment can only be changed with the allen key (2mm) that comes with the kit.

  • Page 10: Operating Elements

    OPERATING ELEMENTS Tension button ndication at the tool LED - I Sealing lever Green During tensioning the LED lights green. Green During welding the LED lights green. Yellow Cooling time is running, the tool must not be removed from the strap. Green Cooling time is finished, the tool can be removed from the...

  • Page 11: Adjustments

    Displaying of the status of the battery charge Push here By pressing a button the status of the battery can be shown in four steps. If four lamps are lighting the battery is full. If only one lamp is lighting shortly the battery has to be charged.

  • Page 12: Feeding The Strap Around The Package

    Feeding the strap around the package The strapping is fed around the package as illustrated. Warning! The plastic strap which will be welded must be free from oil, grease and other dirt. Dirty plastic straps can't be welded correct! Inserting the strap Pull up the handle lever firmly with your right hand.

  • Page 13: Sealing Of The Joint

    Sealing of the joint Press sealing lever down until it locks and let it go immediately. The plastic strap is welded and cut off from the rest of the strap. During the welding the LED lights green. After elapsing of the adjusted welding time (see 6.2.2) the cooling time begins (LED lights yellow).

  • Page 14: Chart Of Types

    CHART OF TYPES Item No. Model Strap width Strap thickness Strap quality 43.0820 P318/08.0/0.35-0.80/PET 8 mm / 5/16" 0.35- 0.80 mm / .014 - .031" 43.0822 P318/09.0/0.35-0.80/PET 9 mm 0.35- 0.80 mm / .014 - .031" 43.0828 P318/12.0/0.35-0.80/PET 12 mm 0.35- 0.80 mm / .014 - .031"...

  • Page 15: Exchange Of Wearing Parts

    EXCHANGE OF WEARING PARTS Remove always the battery from the tool before starting maintenance works. Exchange of tensioning wheel and grippers Disassembling • Unscrew end cover P31.1120 and remove it; • Remove the torsion spring N2.5823; • Remove the tensioning body P31.1105; •...

  • Page 16: Exchange Of Cutter, Welding Stop Gripper And Welding Gripper

    Exchange of cutter, welding stop gripper and welding gripper Disassembling • Unscrew end cover P31.1120 and remove it; • Remove the torsion spring N2.5823 and the tensioning body P31.1105; • Remove the tensioning wheel P31.1107 together with the bearing N3.1172 from the tool; •...

  • Page 17: Adjustment Of The Coupler

    (see name and address on the rear page of this manual). Use original packing. The battery powered plastic strapping tool P318 is a high performance tool. We strongly recommend you to have it serviced by an authorized service shop after 12 months at the latest if used one shift per day. If used two or more shifts per day the tool has to be serviced after a shorter period of time.

  • Page 18: Disposal

    13 WARRANTY CONDITIONS AND LIABILITY FROMM Holding AG warrants all its strapping tools and machine heads during a period of 12 months from the date sale. The warranty includes all deficiencies clearly resulting from poor manufacturing or faulty materials. Damage claims as a result of production shutdowns and claims for damage to persons and to property resulting from warranty deficiencies cannot be asserted by the customer.
  • Page 19 43083001.z For Parts & Service 1-877-862-6699...
  • Page 20 43083001.z For Parts & Service 1-877-862-6699...
  • Page 21 43083001.z For Parts & Service 1-877-862-6699...
  • Page 22 43083001.z For Parts & Service 1-877-862-6699...
  • Page 23 15 SPARE PARTS LIST 43.0830.01 43.0830.01 P318/13.0/0.35-0.80/PET P318.0001.01 27.10.09 Item-No. in group Pcs. Description Dimension Field N1.1305 P31.0102 2 SCREW M4 X 7.8 N1.1553 P32.1250 1 HEXAGON SCREW M4 X 8 N1.1904 3 SCREW M5 X 20 N1.1909 P31.0104 2 FLAT HEAD SCREW M3 X 5 N1.1922...
  • Page 24 43.0830.01 P318/13.0/0.35-0.80/PET P318.0001.01 27.10.09 Item-No. in group Pcs. Description Dimension Field N2.5295 P31.0102 1 PRESSURE SPRING 1.5 X 21 X 27/5.5 N2.5296 P31.0102 1 PRESSURE SPRING 0.5 X 4 X 24/16.5 N2.5822 P31.0102 1 TORSION SPRING 1.25 X 12/3.75 N2.5823 1 TORSION SPRING 2.8 X 17/4...
  • Page 25 43.0830.01 P318/13.0/0.35-0.80/PET P318.0001.01 27.10.09 Item-No. in group Pcs. Description Dimension Field P31.1109 P31.0106 1 PLANET SHAFT P31.1114 1 STRAP STOP P31.1119 1 STRAP GUIDE P31.1120 1 END COVER P31.1124 P31.0102 1 TUBE [P31.1126] P31.0110 1 CIRCUIT BOARD [P32.0119] P31.0109 1 GEAR WHEEL [P32.0139]...
  • Page 26 43.0830.01 P318/13.0/0.35-0.80/PET P318.0001.01 27.10.09 Item-No. in group Pcs. Description Dimension Field [P32.1414] P31.0110 1 LEVER P32.1415 P31.0110 1 HANDLE SHAFT P32.1422 P32.1414 1 LEVER [P32.2006] P31.0110 1 HANDLE LEVER P32.2009 P31.1126 2 TURNING BUTTON P32.2012 P31.0102 1 GUIDE P32.2015 P32.0150 1 GEAR WHEEL P32.2016...
