Summary of Contents for England's Stove Works 15-W01
Page 1
15‐W01 (ESW0037 MODEL) INSTALLATION & OPERATION MANUAL Manufactured By: Stove Builder International inc. 250, rue de Copenhague, St‐Augustin‐ de‐Desmaures (Québec) Canada, G3A www.englander‐stoves.com Safety tested according to ULC S627 standard by an Email: tech@sbi‐international.com accredited laboratory Tel : 1 (877) 356‐6663 CAUTION Please read this entire manual before installation and use of this wood fuel‐...
Page 2
IMPORTANT: IF YOU HAVE A PROBLEM WITH THIS UNIT, DO NOT RETURN IT TO THE DEALER. CONTACT TECHNICAL SUPPORT @ 1‐877‐356‐6663 Retain for your files Model Number Date of Purchase Date of Manufacture Serial Number * This information can be found on the safety tag attached to the rear of the unit. Have this information on hand if you phone the factory or your dealer regarding this product.
Page 3
IMPORTANT NOTE: The ash pan on this wood stove must be installed correctly before operation. The locking lip on the bottom of the ash pan must be slid INSIDE the stove pedestal so that it can lock the ash pan in place, flush against the pedestal. Tilt the ash pan up toward you as you slide it into the opening to do this.
Thank you for purchasing this fine product from Englander! Englander was started, and is still owned by, a family that believes strongly in a "Do It Yourself" spirit – that’s one reason you found this product at your favorite “Do It Yourself” store. We intentionally design and build our stoves so that any homeowner can maintain his or her unit with basic tools, and we're always more than happy to show you how to do the job as easily and as...
INSTALLATION Installation Overview When choosing a location for your new stove, there are a multitude of factors that should be taken into account before beginning the installation. 1. Traffic Patterns – To help prevent accidents, the stove should be placed in a location where it is out of the way of normal travel through the home.
INSTALLATION Clearances to Combustibles Parallel Corner Installation Wall Installation WARNING ‐ INSTALL VENT AT CLEARANCES SPECIFIED BY THE VENT MANUFACTURER Chimney Chimney Chimney Unit to Side Connector Unit to Unit to Connector to Connector Wall * to Side Rear Wall Corner Rear Wall to Corner...
INSTALLATION Venting Introduction Venting Guidelines This wood stove operates on a • ALWAYS install vent pipe in strict natural draft system, in which the chimney adherence to the instructions and system pulls air through the stove. This unit clearances included with your must be installed in accordance with the venting system.
INSTALLATION Additional Venting Information • Do not mix and match components from different pipe manufacturers when assembling your venting system (i.e. Do NOT use venting pipe from one manufacturer and a thimble from another). • We require a minimum chimney height of 15.0 ft. Chimney systems shorter than this may not create the amount of draft which is required to operate this wood burning unit.
Wall Pass-Throughs In Canada, the installation must conform to CAN/CSA-8365 when passing through combustible construction.
Page 12
INSTALLATION Approved Venting Method 1: Through the Wall Factory Built Chimney 10 ft. Termination Cap The 10‐3‐2 Rule: The chimney system Storm Collar must terminate 3.0 ft. above the point where its centerline passes through the roof AND the chimney must terminate 2.0 ft.
INSTALLATION Approved Venting Method 2: Through the Ceiling Termination Cap 10 ft. 2 ft. The 10‐3‐2 Rule: The chimney system 3 ft. must terminate 3.0 ft. above the point where its centerline passes through the roof AND the chimney must terminate 2.0 ft.
Page 14
INSTALLATION Approved Venting Method 3: Internal or External Masonry Chimney System 10 ft. The 10‐3‐2 Rule: The chimney system must terminate 3.0 ft. above the point where its centerline passes through the Chimney liner cross‐sectional roof AND the chimney must terminate area (Length x Width) must be 2.0 ft.
INSTALLATION INSTALLATION INTO A MASONRY FIREPLACE Preparation The 10‐3‐2 Rule: The chimney system must terminate 3.0 ft. above the Measure your hearth to ensure it is large point where its centerline passes through the roof AND the chimney enough to accept the unit. must terminate 2.0 ft.
FLOOR PROTECTION • The spark and ember floor protector should be ULC and must be noncombustible. Since the majority of the heat from this unit is radiant, the floor protector only serves to keep ashes and sparks from landing on combustible flooring near the unit. A hearth rug is NOT an approved substitute for a proper hearth pad.
First Fire‐ Remember to open a door and/or window to ventilate the area. OPERATION You may find it necessary to open several doors or windows for plenty of Break‐In Fires ventilation. • This wood burning unit is constructed of heavy gauge steel and cast iron and is built to last a long time.
Page 18
OPERATION • The optional room air convection blower was designed to extract the maximum amount of heat from the stove, for the highest possible heat transfer into the room. Since the blower is so efficient at removing heat from the unit, it is very important to only operate the room air blower after a fresh wood load has been allowed to burn for at least thirty (30) minutes.
Page 19
DO NOT STORE FUEL CLOSER THAN SPECIFIED CLEARANCES TO COMBUSTIBLES OR WITHIN THE SPACE NEEDED FOR LOADING THE STOVE AND FOR ASH REMOVAL. OPERATION Additional Safety Guidelines CAUTION: When adding fuel to the stove, the blower must be turned OFF. •...
Page 20
function. • If the unit is connected to outside air, be certain to monitor the exterior inlet to the combustion system for icing or snow accumulation. Allowing the outside air connection to become restricted will result in air starvation to the unit. Safe Wood‐Burning Practices Once your wood‐burning appliance is properly installed, follow these guidelines for safe operation:...
MAINTENANCE Daily Maintenance • Inspect the firebox for ash accumulation; remove excess ash and follow instructions below regarding disposal. Ash should not be allowed to accumulate in the stove to the point that it covers the dog box hole. The ash dump plug in the firebox may be removed and ashes raked into the ash pan below for temporary storage.
MAINTENANCE Inspecting Gaskets An airtight seal at the door opening is crucial to proper stove performance. Any air leakage at this area can cause an over‐fire situation and is therefore a serious safety threat. Because of this, gaskets should always be maintained in good condition. Gasket tightness can be checked using the “dollar‐bill”...
REPLACING COMPONENTS Glass This unit has a ceramic glass panel (Part No. AC‐G50) in the viewing door; self adhesive window gasket is included with replacement windows purchased directly from Englander. Never replace ceramic glass with tempered or any other type of glass and never operate this unit with cracked or broken glass.
REPLACING COMPONENTS Burner tube replacement There are three different burner tubes in the top of the stove. To replace a tube, first be sure that you order the correct tube you need to replace. Then using a 5/16” socket or open end wrench, remove the screw located on the left side of the tube.
Other Components continued: At this point you can access the primary air control damper assembly, thermostatic actuator assembly and the damper release lever. Although these shouldn’t need to be replaced, they can be easily. The primary air control damper assembly can be replaced by removing the small spring handle from the front of the unit, then sliding the assembly out.
TROUBLESHOOTING Issue Cause Solution(s) Stove smokes into room 1. Weak Draft 1.1 Be certain chimney is sufficiently tall to meet the 10‐3‐2 rule. 1.2 Add additional height to the chimney. 2. Negative Pressure in 2.1 Add an outside combustion air hookup to the Home the unit.
Page 27
REPLACEMENT PARTS LIST Diagram Description Part No. Unit Rear heat shield (BOLT ON) AC‐W01HS Rear panel (BOLT ON) AC‐W01RP Primary air control damper assembly AC‐W01PDA Not shown Damper release lever AC‐W01DRL Not shown Thermostatic actuator assembly AC‐W01TAA Ash drawer AC‐ADW01 Door hinges AC‐DHW01 Side heat shields...
BRICK LAYOUT AND REPLACEMENT NOTE: The bricks on the sides and rear will need to be installed after delivery *Top rear bricks on each side may or may not be notched. If notched, order part number AC-SBN1X3. QUANTITY DIAGRAM BRICK SIZE PART NUMBER NUMBER STOVE...
Page 30
You may write your unit’s Manufacture Date and Serial Number in the blank spaces on this sample tag, for future reference. This sample tag also shows the safety info. such as ULC testing standard, etc. for your local officials, or anyone else who may need reference information.
Page 31
LIMITED FIVE (5) YEAR WARRANTY From the date of purchase to the original owner The manufacturer extends the following warranties: Five Year Period: Carbon steel and welded seams in the firebox are covered for five (5) years against splitting. The cast iron door and hinges are covered for five (5) years against cracking.
Important Notice This registration information MUST be on file for this warranty to be valid. Please mail this information within thirty (30) days from the original date of purchase. Use any of these three easy ways to send your warranty information in! Mailing Address Stove Builder International inc.
Page 33
WARRANTY REGISTRATION for Englander Purchaser Information I. Purchased By (Name) II. Address III. City State Zip Code IV. Telephone Number V. Email Address Dealer Information VI. Purchased From VII. Address VIII. City State Zip Code Unit Information *Refer to the sticker on the back of the manual or box to complete this section. IX.
Page 34
PLEASE NOTE: The following additions to your owner’s manual will enable you to achieve optimal emissions performance from your stove. Important safety tips are also included. Proper Installation – Please refer to the Installation section of your owner’s manual and follow the guidelines listed therein for safety and for optimal emissions performance.
Page 35
meets local and national fire codes, and if you’re uncertain about how to safely install the stove, we strongly recommend contacting a local certified installer to perform the installation. Venting Guidelines: ALWAYS install vent pipe in strict adherence to the instructions and clearances included with your venting system.
Page 36
Operation and Maintenance – Please refer to the ‘Operation’ (Operating Instructions) and Maintenance (including Ash Removal/Disposal) sections of your owner’s manual and follow the guidelines listed therein for safety and for optimal emissions performance. Additional Information: Following the instructions in your owner’s manual for Building a Fire will ensure a proper fire, as well as helping minimize visible emissions.
Page 37
Moisture Meter Information Firewood is ready at 10‐25% moisture content. • Newly‐cut logs can have a moisture content (MC) of 80% or more, depending on species. • Since wood shrinks, and can also split, twist or otherwise change shape as it dries, most wood is dried before being used.
Page 38
WHAT FUELS NOT TO USE: CAUTION NEVER USE GASOLINE, GASOLINE‐TYPE LANTERN FUEL, KEROSENE, CHARCOAL LIGHTER • FLUID, OR SIMILAR LIQUIDS TO START OR “FRESHEN UP” A FIRE IN THIS HEATER. KEEP ALL SUCH LIQUIDS WELL AWAY FROM THE HEATER WHILE IN USE. ADDITIONALLY, NEVER APPLY FIRE‐STARTER TO ANY HOT SURFACE OR EMBERS IN THE STOVE.
Page 39
Remember to check your local air quality forecast before you burn. • Air Controls: SEE YOUR OWNER’S MANUAL for information on the Proper Use of Air Controls (in the Operation section). ASH REMOVAL – Follow your Owner’s manual’s instructions regarding removal and disposal of ashes.
Page 40
Tamper Warning: “This wood heater has a manufacturer‐set minimum low burn rate that must not be altered. It is against federal regulations to alter this setting or otherwise operate this wood heater in a manner inconsistent with operating instructions in this manual.”...
