INSTALLATION & OPERATION MANUAL
VENTED MODELS:
NOTE:
IF YOU HAVE A PROBLEM WITH THIS UNIT DO NOT RETURN IT TO THE
DEALER. CONTACT CUSTOMER SERVICE @ 1-800-245-6489.
Questions? Need Parts or Options?
Please Note the Following Precautionary Statements:
NOTE:
THIS UNIT IS NOT A DIRECT VENT STOVE AND THEREFORE REQUIRES 4"
B-VENT GAS PIPE WITH ONE INCH (1") CLEARANCE TO COMBUSTIBLES. THIS
STOVE
IS
INSTALLATION. DO NOT INSTALL THIS UNIT IN A BEDROOM.
England's Stove Works highly recommends the use of smoke detectors and Carbon
Monoxide detectors with any hearth product, including this unit. Follow all
manufacturer's instructions when using smoke or Carbon Monoxide detectors.
WARNING:
READ THIS MANUAL PRIOR TO INSTALLATION OF THE UNIT. IF THE
INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE. REFER TO AND SAVE THIS MANUAL. CONSULT
A QUALIFIED INSTALLER, SERVICE AGENCY OR YOUR GAS COMPANY
BEFORE INSTALLATION.
•
DO NOT TRY TO LIGHT ANY APPLIANCE. OPEN ALL WINDOWS AND EXTINGUISH ANY OPEN
FLAME. DO NOT TOUCH ANY ELECTRICAL SWITCH. DO NOT USE THE TELEPHONE IN YOUR
BUILDING - CALL THE GAS COMPANY FROM A NEIGHBOR'S HOUSE AND FOLLOW THE GAS
COMPANY'S INSTRUCTIONS. IF YOU CANNOT REACH THE GAS COMPANY, CALL THE FIRE
DEPARTMENT.
WARNING: DO NOT STORE OR USE GASOLINE OR ANY OTHER FLAMMABLE
MATERIAL IN THE VICINITY OF THIS OR ANY OTHER HEATING APPLIANCE.
Rev. 5/06
26-GBVLP
60-SHBVLP
60-TRBVLP
Save These Instructions
NOT
APPROVED
WHAT TO DO IF YOU SMELL GAS
www.englanderstoves.com
FOR
MOBILE
HOME
26-GBVNG
60-SHBVNG
60-TRBVNG
OR
DOUBLEWIDE
Advertisement
Table of Contents
Related Manuals for England's Stove Works 26-GBVLP
Summary of Contents for England's Stove Works 26-GBVLP
- Page 1 Questions? Need Parts or Options? Please Note the Following Precautionary Statements: NOTE: THIS UNIT IS NOT A DIRECT VENT STOVE AND THEREFORE REQUIRES 4” B-VENT GAS PIPE WITH ONE INCH (1”) CLEARANCE TO COMBUSTIBLES. THIS STOVE INSTALLATION. DO NOT INSTALL THIS UNIT IN A BEDROOM.
- Page 2 A letter from our Technical Support department: Thank you for purchasing this fine product from England’s Stove Works! England's Stove Works was started, and is still owned by, a family that believes strongly in a "Do It Yourself" spirit – that’s one reason you found this product at your favorite “Do It Yourself”...
-
Page 3: Safety Precautions
COMPLETELY SHUT OFF. ALWAYS BE SURE THE STOVE IS COMPLETELY COOLED DOWN PRIOR TO DOING ANY TYPE OF SERVICE WORK. THIS STOVE HAS A STANDING PILOT LIGHT THAT IS LIT USING A PIEZO ELECTRIC SPARK GENERATOR AS DESCRIBED IN OTHER PARTS OF THIS MANUAL. NEVER ATTEMPT TO LIGHT THE PILOT OR MAIN BURNER WITH A MATCH OR LIGHTER. -
Page 4: Listing And Code Approvals
Single wall pipe may be used between the stove and ceiling or stove and wall; a minimum of six inches (6”) clearance to combustible materials is required for this type of pipe. It is imperative that the single wall pipe be terminated at the ceiling or wall, by connecting to a double wall B-1 Vent Pipe. -
Page 5: Section Ii: Unit Preparation And Pre-Installation
Contact the factory at 1-800-245-6489 if you see a cracked or broken log. C. Top or Rear Vent Your stove comes with the option of venting out of the top or rear of the unit. The stove must be set up for the desired venting direction prior to operating the unit. -
Page 6: Section Iii: Wall And Floor Protection
Next, find the vent safety shut-off switch inside the draft hood on the back of the stove. It is the small disc-shaped object screwed to an L-shaped bracket; there are two (2) sets of holes on this bracket. Position the vent safety shut-off switch so the switch is as far down in the flue as possible, or in a position closest to the floor. -
Page 7: Section Iv: Freestanding Hook-Up
It is a good idea to leave some extra wire behind the stove so the unit can be moved out for cleaning. -
Page 8: Section V: Blower
Blower activation is achieved with a temperature switch that mounts to the back of the firebox. When the back wall of the stove heats up, the blower will activate and when it cools down, the blower will automatically shut off. The blower will activate at the speed as set on the variable speed dial. -
Page 9: Lighting Instructions
LIGHTING INSTRUCTIONS STOP! Read “For Your Safety” above. Set the thermostat to lowest setting. Turn off all electric power to the appliance. This appliance is equipped with a manual piezoelectric ignition device. Do not attempt to light the pilot by hand. Turn gas valve control knob fully clockwise →... -
Page 10: Section Vii: First Fire Hints You Should Know
Once the pilot is burning, by looking from the front of the stove you can see a flame -- this small, yellow tipped, blue flame should be visible when the main burner is not operating. When the main burner is on, it is evident from the larger visible flame in the firebox. - Page 11 The high setting allows the maximum amount of gas to enter your stove, and is used for cold winter nights or when you desire to heat a larger space;...
-
Page 12: Section Viii: Maintenance
Note: Let the unit cool down to room temperature before cleaning! It is recommended that you use a clean, dry paintbrush to clean the interior of the stove and a vacuum cleaner to remove the carbon from the logs. The glass in the door may be cleaned with a glass cleaner, but we advise never to use an abrasive cleaner for this operation. -
Page 13: Troubleshooting Guide
Warning: To avoid electrical shock, always disconnect the unit before attempting any trouble shooting procedures (unless otherwise indicated in this manual). If the solution in this guide does not correct the problem, consult your local dealer or call the factory. “Caution: Label all wires prior to disconnection when servicing controls. - Page 14 Installation Drawings – Through-the-Ceiling and Through-the-Wall Note: When running double-walled pipe up the side of home, you must build a chase around the chimney pipe.
- Page 15 The dealer from whom the stove was purchased or the factory will perform warranty service at our option.
-
Page 17: Dealer Information
WARRANTY REGISTRATION for England’s Stove Works Purchased by (Name) ______________________________________________ Address _________________________________________________________ City ________________________ State __________ Zip _________________ Telephone _______________________________________________________ Email Address ____________________________________________________ Purchased From (Dealer) ___________________________________________ Address _________________________________________________________ City ________________________ State __________ Zip _________________ (Please be sure to refer to sticker on back of manual or box to complete this section)
