INSTALLATION & OPERATION MANUAL
Thank you for purchasing this product from a fine line of heating equipment.
We wish you many years of safe heating pleasure.
Visit our web site at
frequently asked questions, parts & accessory orders and more.
NOTE: IF YOU HAVE A PROBLEM WITH THIS UNIT DO NOT RETURN IT TO THE
DEALER. CONTACT CUSTOMER SERVICE @ 1-800-245-6489.
Please note the following Precautionary Statements:
CAUTION: This unit must be installed in accordance with these instructions and
must comply with local building and fire codes. Failure to do so could result in a
chimney or house fire, property damage, bodily injury or even death.
England's Stove Works highly recommends the use of smoke detectors and Carbon
Monoxide detectors with any hearth product, including this unit. Follow all manufacturer's
instructions when using smoke or Carbon Monoxide detectors.
Keep children, furniture, fixtures and all combustibles away from any heating appliance.
Maintain a minimum clearance of thirty inches (30") from the firebox and eighteen inches
(18") from the flue pipe to any combustible. This can be reduced to six inches (6") by
using a heat shield and double wall or shielded pipe.
This product contains a catalytic combustor, which needs periodic inspection and
replacement for proper operation. It is against the law to operate this wood heater with
the catalytic combustor removed, deactivated or in a manner inconsistent with the
operating instruction in this manual.
Our catalytic stoves are designed to burn seasoned, dry wood.
THIS STOVE IS NOT MOBILE HOME APPROVED.
DO NOT PLACE IN A MOBILE HOME!
24-ICD, 50-SHW25 and 50-TRW25
Revised 1/06
www.englandsstoveworks.com
COMPLIANCE STATUS
Type of Fuel
Emission Rate
Tested Overall Efficiency
EPA Certificate Number
This unit is certified to EPA phase II standards.
for helpful information,
Wood
2.4 Grams/Hour
83.78%
443
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for England's Stove Works 24-ICD
Summary of Contents for England's Stove Works 24-ICD
- Page 1 Failure to do so could result in a chimney or house fire, property damage, bodily injury or even death. England’s Stove Works highly recommends the use of smoke detectors and Carbon Monoxide detectors with any hearth product, including this unit. Follow all manufacturer’s instructions when using smoke or Carbon Monoxide detectors.
-
Page 2: Safety Notice
84.8 square inches. C. Top or Rear Exhaust This stove comes with an adaptable top or rear exhaust system. The unit is packaged at the plant with the top exhaust system but can be changed by switching the parts; if you switch to a rear exhaust be sure the gaskets are in place and all the bolts are tight. - Page 3 This involves connecting a metal pipe (usually three inches (3”) in diameter - check your stove - and the pipe can be flex or rigid) from the air inlet pipe located on the bottom rear of the stove through your floor or wall.
-
Page 4: Section Ii: Floor And Wall Protection
Single wall 24 gauge pipe is used from the stove up to the ceiling. The second method is to go through the wall and up the outside of the house. This method is more expensive, because it requires insulated pipe through the wall and up the outside of the house;... -
Page 5: Section Iii: Placement And Installation
The AC-IHS (SH-HS25) Side and Rear Heat Shield is a two-piece shield that attaches to the rear of the unit. When attached to the stove it covers the back of the unit and approximately twelve inches (12”) on each side. This allows six inches (6”) clearance from the rear;... -
Page 6: Section Iv: Accessory Items
AC-IHS/SH-HS25 Side and Rear Heat Shield This accessory is a two piece heat shield that is installed to the rear of the stove and will give six inches (6”) clearance to a combustible. The shield is attached one piece at a time, with the bolts mounting to the four weld nuts on the rear of the stove. - Page 7 A one fourth inch (¼”) button plug is located on the top left side of the stove. This plug can be removed and a Condor probe thermometer (Part #AC-13) inserted, which will display the actual temperature of the combustor.
-
Page 8: Section Vi: Care And Maintenance
With the use of a poker, pull the bed of hot ashes towards the front door of the unit, then fill the stove with seasoned wood and burn the unit for approximately thirty (30) minutes with the door cracked. The next step is to close the door and the by-pass damper and set the front slide damper to your desired burn. - Page 9 This unit has a four-tube blower system, which consists of a manifold welded into the top of the unit. At the rear of the stove is a blower duct where the room air blower (Part #AC-16) attaches. This blower is a squirrel cage type motor with bearings that will require some lubrication;...
-
Page 10: Section Vii: Chimney And Flue Pipe Maintenance
Your pipe should be inspected monthly and cleaned at least once per year. Most people will clean their pipe and stove at the end of the heating season, which will eliminate odors from entering the house during the summer months. The flue pipe must be replaced every three to five years, depending on the thickness of the pipe (thicker pipe will last longer). -
Page 11: Replacement Parts List
Have this information on hand if you phone the factory or your dealer regarding this product. Retain for your files: Model Number __________________________ Date of Purchase ________________________ Date of Manufacture _________________ Serial #_____________________ LIMITED 5 YEAR WARRANTY FROM THE DATE OF PURCHASE TO THE ORIGINAL OWNER The manufacturer extends the following warranties: Five Year Period: 1. - Page 12 AC-110 Brass Window Trim AC-111 Brass Door Trim AC-16 100 CFM Blower Variable Speed Blower AC-DGKC Door Gasket Kit AC-FGKC Flue Collar Gasket Kit AC-SB Small Brick (10 Brick on Bottom of Unit) AC-LB Large Brick (15 Brick on Sides and Back of Unit) AC-6C3 Catalytic Combustor AC-MCSP...
-
Page 13: Dealer Information
WARRANTY REGISTRATION for England’s Stove Works Purchased by (Name) ______________________________________________ Address _________________________________________________________ City ________________________ State __________ Zip _________________ Telephone _______________________________________________________ Email Address ___________________________________________________ Purchased From (Dealer) ___________________________________________ Address _________________________________________________________ City ________________________ State __________ Zip _________________ (Please be sure to refer to sticker on back of manual or box to complete this section)
