England's Stove Works 30-NCP Installation & Operation Manual

Hide thumbs Also See for 30-NCP:

Advertisement

Table of Contents

INSTALLATION & OPERATION MANUAL
MODEL NUMBERS:
Thank you for purchasing this product from a fine line of heating equipment.
We wish you many years of safe heating pleasure with your new heating appliance.
NOTE:
IF YOU HAVE A PROBLEM WITH THIS UNIT DO NOT RETURN IT TO
THE DEALER. CONTACT CUSTOMER SERVICE @ 1-800-245-6489.
Please Note the Following Precautionary Statements:
England's Stove Works highly recommends the use of smoke detectors and Carbon Monoxide
detectors with any hearth product, including this unit. Follow all manufacturers' instructions
CAUTION: This stove must be installed in accordance with the Manufactured Home and Safety
Standard (HUD), CFR 3280, Part 24 and must comply with local building and fire
codes. Failure to follow these instructions could result in property damage, bodily
injury or even death. Keep children, furniture, fixtures and all combustibles away
from any heating appliance.
NOTE:
THIS STOVE IS MOBILE HOME AND DOUBLE WIDE APPROVED (WITH OUTSIDE
AIR HOOK-UP) FOR THE PEDESTAL MODEL ONLY – NOT FOR LEG MODELS. DO
NOT INSTALL IN A SLEEPING ROOM. THE STRUCTURAL INTEGRITY OF THE
MOBILE HOME FLOOR, WALL AND CEILING/ROOF MUST BE MAINTAINED.
CAUTION: This unit must be installed in accordance with these instructions and must comply
with local building and fire codes. Failure to do so could result in a chimney or
house fire. Keep children, furniture, fixtures, and all combustible materials away
from any heating appliance. Refer to this owner's manual for all clearances to
combustible materials.
Read this entire manual before you install and use your new room heater. If this room
heater is not properly installed, a house fire may result. To reduce the risk of fire,
follow the installation instructions.
property damage, bodily injury, or even death.
30-NCP
30-NCL
30-NCG
Save These Instructions.
Questions? Need Parts or Options?
when using smoke or Carbon Monoxide detectors
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Rev. 9/08
50-SNC30P
50-SNC30L
50-SNC30G
www.englanderstoves.com
Failure to follow instructions may result in
50-TNC30P
50-TNC30L
50-TNC30G
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 30-NCP and is the answer not in the manual?

Questions and answers

Related Manuals for England's Stove Works 30-NCP

Summary of Contents for England's Stove Works 30-NCP

  • Page 1 INSTALLATION & OPERATION MANUAL MODEL NUMBERS: 30-NCP 50-SNC30P 50-TNC30P 30-NCL 50-SNC30L 50-TNC30L 30-NCG 50-SNC30G 50-TNC30G Thank you for purchasing this product from a fine line of heating equipment. We wish you many years of safe heating pleasure with your new heating appliance.
  • Page 2 A letter from our Technical Support Department: Thank you for purchasing this fine product from England’s Stove Works! England's Stove Works was started, and is still owned by, a family that believes strongly in a "Do It Yourself" spirit – that’s one reason you found this product at your favorite “Do It Yourself”...

  • Page 3: Before Installation Of Your Appliance

    CAUTION If you have any doubt concerning your ability to complete your installation in a professional-like manner after reading these instructions, you should obtain the services of an installer who is versed in all aspects as to the correct and safe installation. Do not use temporary, makeshift compromises during installation.
  • Page 4 WHY THE CORRECT FLUE SIZE IS IMPORTANT: 6” “Draft” is the force that moves air from the appliance up through the chimney. The amount of draft in your chimney depends on the length of the chimney, local geography, nearby obstructions, and other factors.

  • Page 5: Flue System

    FLUE SYSTEM Existing Flue System If you have chosen a freestanding unit, this stove is designed to connect to an existing flue system, such as masonry or a pre-manufactured Class A flue system. If you have a masonry flue system, the inner liner should be inspected carefully for cracks;...
  • Page 6 INSTALLATION APPLICATIONS Illustration 1 NOTE: Horizontal run not to exceed 6’. Total flue length should not exceed 25’. (Exterior) Wall Floor protection required: Supported Min. size 39” x 52.5”. Always check local codes for clearances, installation, etc. Lined with 18” Min. clay tile or 18”...
  • Page 7 INSTALLATION APPLICATIONS, Cont’d. Illustration 1b...

  • Page 8: Floor And Wall Protection

    Pre-Manufactured Flue System: In the past few years pre-manufactured flue systems have become very popular, because this type system is easily installed and, when done correctly, is very safe. There are many pre-manufactured flue systems on the market, and when making your choice it should be U.L., B.O.C.A.
  • Page 9 Installation on a Combustible Floor If the appliance is to be installed on a combustible floor or a combustible floor covering, it must be installed on a 1” thick non-combustible millboard floor protector or a durable equivalent, with a “R” factor of at least “1.5” (English units) or equivalent. The pad must be installed beneath the unit, extending 16”...
  • Page 10 3. Side Heat Shields Side This accessory item comes Heat with the hardware (six (6) Shield mounting screws) necessary to install it on the rear of the stove. This is a two-piece heat Rear Heat shield, but is installed one Shield piece at a time.

  • Page 11: Installation

    FREESTANDING PLACEMENT AND INSTALLATION The first problem you may encounter is getting your stove into your home -- all of our stove products are well constructed, which makes them rather heavy. Three to four adults can normally handle a unit, but we still recommend using a handcart. Never attempt to handle a heating product alone!!! The door and brick can be temporarily removed to lighten the unit (refer to Brick Layout).
  • Page 12 CHIMNEY REFER TO CHIMNEY AND CHIMNEY CONNECTOR MANUFACTURER’S INSTRUCTIONS CONTACT YOUR LOCAL BUILDING AUTHORITY FOR APPROVED METHODS OF INSTALLATION 3 Ft. min. from 1. This appliance requires a masonry or pre- Roof Penetration manufactured chimney listed to UL103HT sized correctly. 2.

  • Page 13: Operation

    OPERATION Do not use a grate or elevate the fire. Build the wood fire directly on the bricks. When the stove is used for the first time, solvents in the paint will smoke off as the stove “cures.” WOOD – This heater is designed to burn natural wood only.

  • Page 14: Glass Care

    GLASS CARE REPLACE GLASS ONLY WITH HIGH-TEMPERATURE ROBAX PYROCERAM OF THE PROPER SIZE AND THICKNESS. The following use and safety tips should be observed: Inspect the glass regularly for cracks or breaks. If you detect a crack or a break, extinguish the fire immediately, and contact your dealer or Customer Service at (800) 245-6489 for replacement (or log on to www.englanderstoves.com...
  • Page 15 The following steps should be followed for replacement of the door gasket: Ensure the appliance is not in operation and is thoroughly cooled. Remove the old door gasket and clean the gasket channel. Using an approved high-temperature gasket cement, apply a thin coat in the bottom of the channel.

  • Page 17: Ash Disposal

    CREOSOTE When wood is burned slowly, it produces tar and other organic vapors. These combine with moisture to form creosote. Creosote vapors condense in the relatively cool chimney flue of a slow-burning fire – as a result, creosote residue accumulates on the lining of the flue. If ignited, this creosote makes an extremely hot fire.
  • Page 18 IMPORTANT: HELPFUL HINTS AND TIPS WORTH REVIEWING What is the correct way to start a fire? You will need small pieces of dry wood (kindling) and paper. Use only newspaper or paper that has not been coated or that has had materials glued or applied to it. Never use coated or colored paper (such as advertising flyers).
  • Page 19 Why is there always a large quantity of thick black smoke in the firebox? A large quantity of thick black smoke in the firebox is a possible indication that you have poor draft. Is it normal for soot to cover the glass at the beginning of a fire? This stove has been built with an air wash system that will help keep the glass clear when the firebox has reached a good operating temperature, and also has a good draft.
  • Page 20 PARTS, ACCESSORIES AND OPTIONS LIST (Options and trim (i.e. brass and nickel) interchange for variety. Gold door and legs may also be ordered to replace existing door and pedestal or regular cast legs.) REPLACEMENT PARTS AC-G30 DOOR GLASS KIT WITH GASKET AC-GGK DOOR GLASS GASKET KIT (gasket only, no glass)
  • Page 21 DIRECTIONS FOR INSTALLATION OF LEGS OR PEDESTAL: (Stove must be cooled and all ashes cleaned out) Remove bricks, disconnect flue, and turn stove on its back. * If you are replacing existing legs or pedestal, disconnect the existing legs or pedestal. To install legs: 1.
  • Page 22 Have this information on hand if you phone the factory or your dealer regarding this product. Retain for your files: Model Number __________________________ Date of Purchase ________________________ Date of Manufacture _________________ Serial #_____________________ LIMITED 5 YEAR WARRANTY FROM THE DATE OF PURCHASE TO THE ORIGINAL OWNER The manufacturer extends the following warranties: Five Year Period: Carbon steel and welded seams in the firebox are covered for 5 years against splitting.

  • Page 23: Unit Information

    WARRANTY REGISTRATION for England’s Stove Works Purchased by (Name) ______________________________________________ Address _________________________________________________________ City ________________________ State __________ Zip _________________ Telephone _______________________________________________________ Email Address ___________________________________________________ DEALER INFORMATION Purchased From (Dealer) ___________________________________________ Address _________________________________________________________ City ________________________ State __________ Zip _________________ UNIT INFORMATION (Please be sure to refer to sticker on back of manual or box to complete this section) Model Number _____________________ Purchase Date _________________ Purchase Price ____________________ Serial Number _____________________ Mfg.

This manual is also suitable for:
