Wiring diagram with T-Harness (THCHN3 Rev. 3)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Use the style of
OBDll connector that
fits the best.
(green CAN junction connector
male
OR
male
female
OBDII
Diagnostic Connector
male
Not Used
Not Used
T-02
6-pin
White
Connector
7 933.CHRYSLER15 1.16.198.9 2018 Jeep Wrangler (Smart Key)
©2023 Directed. All rights
1
CAN C High:
2
3
Tan/White, pin 1
1
2
CAN C Low:
3
Yellow, pin 2
CAN Junction
behind glove box)
Cut the
Tan, Tan/Black,
Orange/Brown and
Orange/Green loops.
Refer to the Optional starter
disable connection section for
relay and connection details.
Siren
Ignition Node
(black connector
Connect the
at Ignition switch)
T-Harness male
connector into
the ignition
switch
male
T-01
6-pin Black
Connector
CAN IHS High:
Orange,
pin 1
CAN IHS Low:
White/Orange,
pin 2
HS CAN 3 Low: Tan
HS CAN 3 High: Tan/Black
HS CAN 2 High: Orange/Green
HS CAN 2 Low: Orange/Brown
22-pin White Connector
(-) GWA Output: Blue/White
(+) Siren Output: Brown/Red
Hood Pin
(-) Hood Input: Gray
(MUX) Parking Light Output: Violet/Brown
Headlight Switch
(black 10-pin conn.)
(MUX)
Parking Lights:
White/Brown,
pin 1
1 2 3 4 5
6 7 8 9 10
1
2
CAN Junction
3
(white CAN junction connector
behind glove box)
A module can also be used for
8-pin White Connector
8-pin White Connector
this installation.
THCHN3 Rev.3
(optional T-Harness)
IMPORTANT:
Position the
fuses correctly!
12-pin Black Connector
12-pin Black Connector
Slide to open
Legend:
).
3
1
2
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
