Directed Directechs DS3+ Installation Manual page 11

Module
Conn./Pin Color Description
H2/17 Black/White (-) E-Brake Input
H2/18 Orange/Black (+) Instant Alarm Input
H2/19 Blue (-) Trunk Trigger Input
H2/20 Green (-) Door Trigger Input
H2/21 Gray
(-) Hood Switch Input
H2/22 Violet/White (AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. - Immo. Data Interrupt (connector side):
H3/2 Blue/Red Relay N.O. - No Connection
H3/3 Blue Relay COM. - Immo. Data Interrupt (vehicle side):
H3/4 White/Brown Relay N.C. - No Connection
H3/5 White Relay COM. - No Connection
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. - No Connection
H3/8 Lt. Green Relay COM. - No Connection
H3/9 Lt. Green/White Relay N.C. - No Connection
H3/10 Black (-) Ground
H3/11 White Relay COM. - No Connection
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Flex Relay (pin 87a)
H4/4 Pink/White (+) Flex Relay Output
H4/5 Red (+) 12 Volt Input
H4/6 Green Starter Disable (key side)
H4/7 Violet (+) Starter Output (vehicle side)
H4/8 Orange (+) Accessory Output
H4/9 Red/White (+) 12 Volt Input
11 933.CHRYSLER15 1.16.198.9 2018 Jeep Wrangler (Smart Key)
©2023 Directed. All rights
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
[1] The installation of an aftermarket hood pin is only required on vehicles
that are not equipped with a factory hood pin or if not supported in
data.
No Connection
Connects To
Wire Location
Keyless Ignition Node (Start Stop Button), black 6 pin plug, pin 5
No Connection
Keyless Ignition Node (Start Stop Button), black 6 pin plug, pin 5
No Connection
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 16
No Connection
No Connection
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 4
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 16
Warning! Only 10A!
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
(+/-) Wire Color Connection
Data White/Green Remote Start
Only
Data White/Green Remote Start
Only
+ Gray/Red (10A) Mandatory
- Black Mandatory
+ Gray/Red (10A) Mandatory
(+/-) Wire Color Connection
