Under Cabinet Range Hood
User Manual
and
Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS
Carefully read the important information
regarding installation, safety and maintenance.
Keep these instructions for future reference.
MAAN1278-01
2022-01-24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AN-1278 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ancona AN-1278

  • Page 1 Under Cabinet Range Hood User Manual Installation Instructions IMPORTANT SAFETY INSTRUCTIONS Carefully read the important information regarding installation, safety and maintenance. Keep these instructions for future reference. MAAN1278-01 2022-01-24...
  • Page 2: Before You Begin

    Before You Begin INSTALLERS - Start Here Safety Instructions are on pages 4 and 5 and Installation Instructions are on pages 8 to 15. Please perform these steps: 1. Read the safety instructions. 2. Read all instructions in the Installation section of this manual BEFORE installing the range hood.
  • Page 3: Table Of Contents

    Table of Contents Before You Begin ..........................2 Table of Contents ..........................3 Important Safety Information ......................4 Included Parts ........................... 6 Range Hood Dimensions ........................7 Specifications ............................ 7 Installation ............................8 Step 1 - Read the Safety Instructions .................... 8 Step 2 - Unpack Range Hood and Prepare Tools ................
  • Page 4: Important Safety Information

    Important Safety Information READ ALL INSTRUCTIONS BEFORE USE Read and follow all instructions before using the range hood to prevent the risk of fire, electric shock, personal injury, or damage when using the range hood or appliances with the range hood. This guide does not cover all possible conditions that may occur.
  • Page 5 Important Safety Information WARNING: TO REDUCE RISK OF A RANGE To reduce the risk of injury to persons in the TOP GREASE FIRE: event of a gas leaks: a) Never leave surface units unattended at high • Extinguish any open flame. settings. Boilovers cause smoking and greasy • DO NOT turn on the lights or any type of appliance.
  • Page 6: Included Parts

    Included Parts Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material. Please consult your installation specialist regarding the optimal type of mounting screws and wall anchors to suit your home’s construction. Range Hood Rectangular Vent/Damper 3.25 ×...
  • Page 7: Range Hood Dimensions

    Range Hood Dimensions 9.25 in. (23.5 cm) 9.6 in. (24.5 cm) 20.6 in. (52.5 cm) 2.3 in. (5.8 cm) 9.6 in. (24.5 cm) 1.8 in. (4.6 cm) 20.6 in. (52.5 cm) Specifications Body Design Stainless Steel Power Rating 120 V / 60 Hz (cETLus Certified) Total Input Power 215 W (210 W + 2 ×...
  • Page 8: Installation

    Installation STEP 1 Read the Safety Instructions • It is very important to read the safety instructions on pages 4 and 5. IMPORTANT: It is the installer’s responsibility to comply with installation clearances. STEP 2 Unpack Range Hood and Prepare Tools • Carefully unpack the range hood and parts.
  • Page 9: Step 5 - Venting Installation Guidelines

    Installation STEP 5 Venting Installation Guidelines • The following steps are for exterior ventilation. IMPORTANT: For the most efficient and quiet operation: • Vent system must terminate to the outside (roof or side wall). • It is recommended that the range hood be vented • DO NOT terminate the vent system in an attic or other vertically through the roof through 6 in.
  • Page 10 Installation IMPORTANT: for gas stove tops and no higher than 30-inch (76.2 cm) • A minimum of 6 in. (15.3 cm) round or 3-1/4 × 10 in. (8.3 for electric cook tops. cm × 25.4 cm) rectangular duct must be used to maintain • It is important to install the hood at the proper mounting maximum airflow efficiency.
  • Page 11: Step 6 - Preparations

    Installation STEP 6 Preparations NOTE: To avoid damage to your hood, prevent debris from entering the vent opening. • Determine and mark the centre line on the ceiling or wall where the range hood will be installed. • Make sure there is proper clearance within the ceiling or wall for exhaust vent. • Due to the weight and size of this unit, please make sure that the support system or framework being used is stable and secure in the ceiling or wall.
  • Page 12: Step 8 - Rotating The Motor (For Rear Venting Only)

    Installation Remove rear vent back plate • Position the unit face down on a flat non-abrasive surface with rear of product facing you. • Remove the back plate by removing the 4 screws (see Figure 5). SAFETY WARNING: Risk of electrical shock. This range hood must be properly grounded. Make sure this is done by a qualified electrician in accordance with all applicable national and local electrical codes.
  • Page 13: Step 9 - Install Top Vent Plate And Rear Damper (For Rear Venting Only)

    Installation STEP 9 Install top vent plate and rear damper (For rear venting only) • Re-install the plate removed in step 7 to block top venting hole. • Put plate in position and put in 4 screws from step 7 (see Figure 10). • Install rectangular air damper outlet on the rear vent location (see Figure 11).
  • Page 14: Step 12 - Attaching The Unit Under The Kitchen Cabinets

    Installation Method 2: attach the ducting to the rear rectangular damper and exhaust outdoors. Figure 14 Fig #13 STEP 12 Fig #13 Attaching the unit under the kitchen cabinets • Mark or drill a small hole on the mounting position according to the space and dimensions cited on the following drawings.
  • Page 15: Step 13 - Connect To Ac

    Installation STEP 13 Connect to AC 3-Pronged Plug • Connect AC plug into a grounded AC outlet having 120V, 60Hz. Place the outlet at a maximum distance of 33-1/2 in. (851 mm) from where the cord exits on the hood. Ground Plug 3-Prong Receptacle IMPORTANT:...
  • Page 16: Operation

    056B 056B 056B 056B 056B 056B 056B 013B Operation 056B 056B 056B 056B 013B 013B 056B 056B 056B 056B 056B 056B 056B 013B 013B 013B 013B Lamp Auto Timer Decrease Increase Power 056B (On/off) NOTE: When the hood has been initially connected to the 013B 013B 013B...
  • Page 17: Maintenance

    Maintenance Replacing the Light Pucks IMPORTANT: ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN PANEL BEFORE CARRYING OUT ANY OPERATION ON THE APPLIANCE. Make sure the range hood is unplugged or turn OFF Replace with a 10.2 Volt, 2.5 Watt max, LED lights. breaker.
  • Page 18: Cleaning Filters

    Maintenance Cleaning Filters IMPORTANT: Drain oil from baffles, spacers, filters, oil tunnels, oil containers before oil and residue overflow! • Remove all baffles, spacers, filters, grease tray, and oil containers and discard oil and residue. • Wash with warm soapy water. NOTE: Stainless steel baffles, spacers and oil tunnel are top rack dishwasher safe. • Dry thoroughly before replacing and follow directions for installation in reverse. • Filters should be cleaned after every 30 hours of use. • Should filters wear out due to age and prolonged use, replace with a new filter.
  • Page 19: Range Hood Assembly

    Range Hood Assembly Number Part Round duct or valve (Exhaust) Air outlet cover Housing assembly Back plate Power cord Electronic box Cover plate Capacitor Electronic box cover Blower assembly (includes motor) Switch bracket Switch box Switch board Light panel LED puck lights Baffle filters Bars Hooks...
  • Page 20: Assembly

    90P-2G ���� [C5 Motor, 3-Speed] Assembly + 2 x � 2.5W (LSD E) LED Circuit Diagram Motor 0V 60Hz Capacitor Main PCB _ _ _ LED Pucks CH B MAX 10.2V 250mA 2.5W Temperature / Humidity Sensor (Optional) Blower Assembly Number Part 90P-2G ����...
  • Page 21: Use And Care Information

    Use and Care Information Operations • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating fans could catch on to hair, fingers and loose clothing.
  • Page 22 Ancona is in association with Mr Appliance for all after sales service calls. Please contact their service provider or visit their website: Phone: 1-888-998-2011 Website: www.mrappliance.com MAAN1278-01 © 2022 Copyright of Ancona Home. All rights reserved. This material may not be reproduced, displayed, modified or distributed. — 22 —...
