• Mode button – The Mode button sets the display mode for the port status indicator LEDs (i.e. Status, Duplex
or Speed). It can also be used to reset the device if held for 5 seconds.
• Alarm Indicator LED – The alarm indicator LED illuminates when an alarm condition exists.
• Power Module Indicator LEDs – The power module indicator LEDs indicate the status of the power modules.
▪ Green – The power supply is supplying power
▪ Red – Power supply failure
▪ Off – No power supply is installed
• RS-232 Console Port – The serial console port is for interfacing directly with the device and accessing initial
management functions. For information about connecting to the device via the serial console port, refer to
Section 2.5, "Connecting to the
Description
Device".
