Chapter 1
Introduction
• Screw or pluggable terminal blocks for reliable, maintenance-free connections
• CSA/UL 60950-1 safety approved to 85 °C (185 °F)
Section 1.2

Description

The RUGGEDCOM RSG2100 features various ports, controls and indicator LEDs on the display panel for
connecting, configuring and troubleshooting the device. The display panel can be located on the rear, front or top
of the device, depending on the mounting configuration.
Figure 1: RUGGEDCOM RSG2100
1. Fiber or Copper Ethernet Ports
Mode Indicator LEDs
• Communication Ports – Ports for communicating with other devices or accessing the RUGGEDCOM ROS
operating system are described in
• Port Status Indicator LEDs – Port status indicator LEDs indicate the operational status of each port,
dependent on the currently selected mode.
Mode
Status
Duplex
Speed
• Display Mode Indicator LEDs – The display mode indicator LEDs indicate the current display mode for the
port status indicator LEDs (i.e. Status, Duplex or Speed).
2
2. Port Status Indicator LEDs
6. Alarm Indicator LED 7. Power Module Indicator LEDs
Chapter 3, Communication
Green (Solid)
Green (Blinking)
Off
Green
Orange
Off
Green (Solid)
Green (Blinking)
Orange (Solid)
Off
1
3. Mode Button
Ports.
Color/State
5
2 3 4
4. RS-232 Serial Console Port (RJ45)
Description
Link detected
Link activity
No link detected
Full duplex mode
Half duplex mode
No link detected
100 Mb/s
1000 Mb/s
10 Mb/s
No link detected
RUGGEDCOM RSG2100
Installation Guide
6
7
5. Display
Description
