Controls

Back Panel

CH3 CH4 Switch
Selects the channel to which you will tune the TV to see the
VCR picture if you connect the VCR using one of the basic
hookups.
IN FROM ANTENNA Connector
Receives the signal from an antenna, cable system, or
satellite receiver that is attached to this connector.
OUT TO TELEVISION Connector
Passes signal to TV using the cable supplied.

Display Panel

This VCR includes a feature that enables you to change the brightness level of the
fluorescent display panel.
1. Press MENU¥PROG on the remote to see the VCR MAIN MENU on the
TV screen.
2. Press 6 to display the PREFERENCES menu.
3. Press 4 to select Panel Display: AUTO, BRIGHT, or DIM.
Select AUTO to keep the display panel bright when VCR is on and dim
when it is off.
Select BRIGHT to keep the display panel bright.
Select DIM to keep the display panel dim.
50
MONO
L L
VIDEO
R R
IN
IN OUT
AUDIO
ANTENNA
OUT
TELEVISION
CH
3 4
VIDEO and AUDIO IN (R and MONO L) Jacks
Receives signals from another component, like a VCR or
camcorder, when it is connected to these jacks. Use INPUT
to select L1 in the VCRÕs display panel.
Attach a component that is not stereo to the MONO L jack
to hear sound on both channels.
VIDEO and AUDIO OUT (R and L) Jacks
Sends signals from VCR to another component, like a TV
monitor or VCR, when it is connected to these jacks.
Controls
IN
FROM
OUT
TO
VCR MAIN MENU
1 VCR Plus+
2 Timer Recordings
3 Time
4 Channels
5 Setup
6 Preferences
7 Language/Langue
8 Audio
0 Exit
PREFERENCES
1 Remote Control: VCR1
2 Auto Play: ON
3 Auto TV/VCR: ON
4 Front Panel: AUTO
5 CA Marking: ON
6 CA Playback: AUTO
7 CA Display: BLUE
8 Set Auto Repeat
0 Exit
