This manual is intended to be used as part of an employee training program as required by OSHA. When used and
maintained in accordance with the manufacturer's instructions, this product helps provide the method of emergency
escape when working at height, as referenced by OSHA and industry guidelines including API RP 54 6.12.
DESCRIPTION:
The Rollgliss™ High Speed 200 foot Emergency Descent Devices with Auto-Retract are comprised of a Wire Rope Lifeline
housed in a cast aluminum enclosure. An internal brake controls sloped descent speed of a single user attached to a manual
brake trolley at the end of the lifeline.
Figure 1 - 200 Ft (61m) Emergency Sloped Descent Device Models
Descent Device Model
Galvanized
3303015
Stainless Steel
3303016
Form: 5903739 Rev: F
Rollgliss
200 Ft Emergency Sloped Descent Device
High Speed with Auto-Retract
User Instruction Manual
Brake Trolley Model
With Yellow Zinc Plated Snap
Hook, included with 3303015.
With Stainless Steel Snap Hook,
included with 3303016.
®
2103144
2103145
© 3M 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DBI-SALA Rollgliss 3303015 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for 3M DBI-SALA Rollgliss 3303015

Summary of Contents for 3M DBI-SALA Rollgliss 3303015

  • Page 1 Figure 1 - 200 Ft (61m) Emergency Sloped Descent Device Models Descent Device Model Brake Trolley Model Galvanized 3303015 With Yellow Zinc Plated Snap 2103144 Hook, included with 3303015. Stainless Steel 3303016 With Stainless Steel Snap Hook, 2103145 included with 3303016. Form: 5903739 Rev: F © 3M 2023...

  • Page 2: Safety Information

    Never exceed the maximum free fall distance specified for your Fall Protection equipment. Do not use any Fall Protection equipment that fails inspection, or if you have concerns about the use or suitability of the equipment. Contact 3M Technical Services with any questions.

  • Page 3: System Requirements

    Emergency Descent Device. 2.0 SYSTEM REQUIREMENTS COMPATIBILITY OF COMPONENTS: 3M Fall Protection equipment is designed for use with 3M Fall Protection approved components and subsystems only. Substitutions or replacements made with non-approved components or subsystems may jeopardize compatibility of equipment and may effect the safety and reliability of the complete system.

  • Page 4: Installation And Use

    TEST THE SYSTEM: 3M Fall Protection recommends performing a test descent using a 120 lb (55 kg) test weight. The descent speed should be uniform and allow the user to reach the landing area safely. The descent speed should be approximately as stated in Section 1.2B.
  • Page 5 AFTER A DESCENT: After use of the Emergency Descent Device, the auto retract function retracts the lifeline back in the device under control. Depending on the slope of the application, it may be necessary to assist the Brake Trolley back to the Descent Device. The Emergency Descent Device must be serviced by an authorized service center after a descent as the result of an emergency.
  • Page 6 CONNECT THE EMERGENCY DESCENT DEvICE TO A GUIDE CABLE: Sloped angle descent applications require attaching the Emergency Descent Device to the Guide Cable. Use the suspension bar kit to attach the Emergency Descent Device to the Guide Cable as shown in Figure 5. Step 1.
  • Page 7 If you are a first-time user, contact a Customer Service representative in the US at 800-328-1667. If you have already registered, go to: www.3M.com. Follow the instructions provided with the handheld RFID reader or on the web RFID portal to transfer your data to the web log.

  • Page 8: Specifications

    NOTE: Only 3M Fall Protection or parties authorized in writing may make repairs to this equipment. STORAGE AND TRANSPORT: Store and transport the Emergency Descent Device in a cool, dry, clean environment, out of direct sunlight. Avoid areas where chemical or organic vapors are present. Thoroughly inspect the Emergency Descent Device after extended storage.
  • Page 9 8.0 LABELING The following labels should be securely attached to the Emergency Descent Device and should be fully legible:...

  • Page 10: Inspection And Maintenance Log

    9.0 INSPECTION AND MAINTENANCE LOG SERIAL NUMBER: MODEL NUMBER: DATE PURCHASED: DATE OF FIRST USE: INSPECTION DATE INSPECTION ITEMS CORRECTIvE ACTION MAINTENANCE NOTED PERFORMED Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By:...
  • Page 11 INSPECTION DATE INSPECTION ITEMS CORRECTIvE ACTION MAINTENANCE NOTED PERFORMED Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By:...
  • Page 12 LIMITED REMEDY: Upon written notice to 3M, 3M will repair or replace any product determined by 3M to have a factory defect in workmanship or materials. 3M reserves the right to require product be returned to its facility for evaluation of warranty claims. This warranty does not cover product damage due to wear, abuse, misuse, damage in transit, failure to maintain the product or other damage beyond 3M’s control.
