Loading Media And Ribbon
Media
Guard
7. Verify that the left edge of the media is against the fixed guide
8. Push the media width guide in until it is flush with the outer
9. Check the horizontal position of the lower media sensor
22
Lower
Media Sensor
Media
Damper
on the bottom of the media damper.
edge of the media.
(located under the media guard) and the upper media sensor
(shown on page 27). (See "Positioning The Media Sensors" on
page 28.)
Fixed
Guide
Media Width
Guide
