Printhead

Platen

6. Thread the media under the media damper and then between

the platen (rubber drive roller) and the printhead.

You can also refer to the arrows on the printer frame or to the

label inside the media cover for media loading instructions.

Loading Roll Media

Media and

Ribbon Loading

Instructions

Media

Media Damper
