  • Page 1 Installation and Maintenance Manual MRW-01 Radial Winch 35.2 PT...
  • Page 2 Procedure 2 Installation procedure Maintenance Washing Maintenance table Disassembly procedure Exploded view with maintenance products Assembly Harken limited worldwide warranty ® Ordering spare parts Exploded view Parts list Radial Winch 35.2 PTA 35.2 PT Installation and Maintenance Manual Radial Winch...
  • Page 3: Technical Characteristics

    Maximum working load WARNING! The maximum working load (MWL) for the 35.2 PT Radial Winch is 650 Kg (1433 lb) Subjecting the winch to loads above the maximum working load can cause the winch to fail or pull off the deck suddenly and unexpectedly during high loads causing severe injury or death.
  • Page 4: Installation

    It is the installer's responsibility to choose the correct screws ® taking account of the loads they will have to bear. Harken assumes no responsibility for incorrect installation of its winches or for an incorrect choice of mounting screws.
  • Page 5 3. Lift off the drum n°22 Install the winch on the deck in the position you have chosen, keeping in mind the limits described on page 4 and using socket head (SH) bolts. (See paragraph on installation) 35.2 PT Installation and Maintenance Manual Radial Winch...
  • Page 6 1. Remove the skirt n°2 with the help of 2. Take off the skirt n°2 the screwdriver placed as shown by the symbol 3. Position the 5 M6 hexagonal headed bolts in their holes 35.2 PT Installation and Maintenance Manual Radial Winch...
  • Page 7 A. Position the base of the winch on the deck and mark the position of the holes or use the drilling cut-out template at the point where you have decided to place the winch. Below is a reduced scale diagram. The drilling cut out template is available on the Harken® website, www.harken.com 35.2 PT Installation and Maintenance Manual...
  • Page 8: Maintenance

    C. Bolt the base of the winch to the deck using five M6 Socket Head (SH) bolts for Procedure 1 or five ® hexagonal headed M6 bolts for Procedure 2 (neither is supplied by Harken ), correctly chosen for the thickness and type of the boat deck. Consult the yard that built the boat in case of doubt.
  • Page 9 Installation and maintenance of winches must be carried out exclusively by specialized personnel. ® In the case of doubt contact Harken Tech Service at techservice@harken.it Disassembly procedure Tools needed...
  • Page 10 10. Remove the gearing n°7 and remove the 11. Slide off gear n°3 pawls n°4. To facilitate the operation press the spring against the pawl with a blade. 12. Slide off gear n°14 13. Slide off gear n°10 35.2 PT Installation and Maintenance Manual Radial Winch...
  • Page 11 Use a brush to lightly lubricate all gears, gear pins, teeth and all moving parts with grease. Lightly lubricate the pawls and springs with oil. Do not use grease on the pawls! 35.2 PT Installation and Maintenance Manual Radial Winch...
  • Page 12 Exploded view with maintenance products Anti-seize ® Harken Grease ® Harken Pawl Oil Apply Harken grease on assy socket screw ® Apply Harken ® grease on drum gear 35.2 PT Installation and Maintenance Manual Radial Winch...
  • Page 13: Ordering Spare Parts

    Once in position, check that the pawls can be easily opened and closed with a finger. ® In case of doubt concerning the assembly procedure contact Harken Tech Service: techservice@harken.it ® Harken limited worldwide warranty ®...
  • Page 14 , Inc. ® Tech Service 1251 East Wisconsin Avenue Email: technicalservice@harken.com Pewaukee, Wisconsin 53072-3755 USA Tel: (262) 691.3320 Customer Service Fax: (262) 691.3008 Tel: (262) 691-3320 Email: harken@harken.com Email: customerservice@harken.com Web: www.harken.com 35.2 PT Installation and Maintenance Manual Radial Winch...
  • Page 15: Exploded View

    Exploded view 1/2 35.2 PT Installation and Maintenance Manual Radial Winch...
  • Page 16 Exploded view 2/2 35.2 PT Installation and Maintenance Manual Radial Winch...
  • Page 17: Parts List

    PT spacer M0600903 Screw M6x20 UNI5931 A94136400 Assy Socket W20-80 Screw M8x20 UNI 6109* Washer Ø7.7xØ25x5.8* Socket Handle W20/80* *Service kit available; see winch kit section on the website www.harken.com **Winch product sticker 35.2 PT Installation and Maintenance Manual Radial Winch...
