The Cnvt2Fls Utility Program - Printronix L1524 Setup Manual

downloadable format. You can then copy them to the printer's flash memory as
binary data files, as instructed later in this section.
The procedures that follow assume that you are familiar with DOS file
commands.

The CNVT2FLS Utility Program

The CNVT2FLS program is a DOS utility that is supplied with the emulation
software. This utility converts logo, form, TIFF, setup, and font files into
downloadable format.
To convert files into downloadable format, do the following:
1. Create a directory on the hard drive and copy the CNVT2FLS utility to
that directory.
2. Copy all of the files to be converted to the directory where the
CNVT2FLS utility resides.
3. Change to the drive and directory where the CNVT2FLS utility resides.
4. To display a brief help message, at the DOS prompt, enter the
command name CNVT2FLS with no parameters:
CNVT2FLS <Return>
You will then see a help message similar to the following:
USAGE:
CNVT2FLS file_name1 file_name2 file_name3 A <return>
or
CNVT2FLS file_name1 file_name2 file_name3 A FONT <return>
file_name1: Input file name to be converted from.
file_name2: Output file name for file download.
file_name3: Flash file name to be stored in file system
after download.
hw_type:
FONT: Optional, specify
Configuring the Printer
Specify A all the time.
FONT if this is a font file.
3–51
