12. Have a second person hold the Console (6) near
the Console Bracket (26).
Plug the 6-pin and 8-pin Wires (90, 91) into the
matching receptacles on the back of the Console
(6); make sure to plug the Wire marked with
red into the receptacle marked with red,
and plug the Wire marked with yellow into
the receptacle marked with yellow. Make
sure that the flat side of each Wire is facing
outward.
Tip: Avoid pinching the wires. If necessary,
tilt the Console Bracket (26) upward to
make this step easier. Attach the Console (6)
to the Console Bracket with four M4 x 16mm
Screws (81); start all the Screws, and then
tighten them.
13. Set the Hand Weights (59) in the Weight
Rests (11, 12).
12
26
6
13
59
59
11, 12
12
81
81
90, 91
Avoid pinching
the wires
