- Page 1 RisingHF RHF2S025 user manual UM01825 RHF2S025 User Manual V0.3 Document information Info Content RisingHF, LoRaWAN, WiFi, Industrial Gateway, User Keywords Manual Abstract This document is a user manual for RHF2S025. V0.3 2019-04-23 www.risinghf.com...
-
Page 2: Table Of Contents
RisingHF RHF2S025 user manual Content Content..................................2 Figure..................................3 Table...................................4 1. Preface.................................. 5 2. Connect to iotsquare server..........................5 2.1. Get Started..............................5 2.1.1Add Gateway..............................5 2.1.2 Add Applications............................6 2.1.3 Add Device..............................7 2.1.3.1 Add abp Device............................7 2.2. Connect to internet in different modes and modes switch..............8 2.2.1. -
Page 3: Figure
Figure 3- 2 Login on the web page........................16 Figure 3- 3 Page after login..........................16 Figure 3- 4 LoRa SDK configuration........................18 Figure 3- 5 RHF2S025 panel display......................... 18 Figure 4- 1 register gateway..........................20 Figure 4- 2 select Packet Forwarder........................21 Figure 4- 3 Fill in the gateway information...................... -
Page 4: Table
RisingHF RHF2S025 user manual Table Table 3- 1 Led descriptions..........................18 Table 3- 2 Functions of the Keys........................19 V0.3 2019-04-23 www.risinghf.com... -
Page 5: Preface
RHF2S025 is an intelligent gateway with LoRaWAN ,LTE 4G(optional)and WiFi functions.It is developed and produced by RisingHF. RHF2S025 has a small size, simple appearance and high reliability, which could help customer to setup a LoRaWAN network quickly and with efficiency. -
Page 6: Add Applications
RisingHF RHF2S025 user manual Figure 2- 2 Gateway informations to be filled 2.1.2 Add Applications Enter “Applications->add application” Figure 2- 3 Add application on the iotsquare server V0.3 2019-04-23 www.risinghf.com... -
Page 7: Add Device
RisingHF RHF2S025 user manual 2.1.3 Add Device Select the application, add a node device, select otaa/abp according to the mode of the node, fill in the node information and frequency plan. Suggested node naming method: node model / product name _ number. -
Page 8: Connect To Internet In Different Modes And Modes Switch
AP mode is RHF2S025’s factory default mode. In this mode, the gateway could connect to the network via DHCP way with a cable. Please connect RHF2S025 network port to the DHCP LAN port of the router with the network cable. - Page 9 RHF2S025 user manual 1) Get IP address of the device 1. Scan the SSID of RHF2S025 in your PC and connect your PC to the device, usually with the default name “RHF2S025_XXXXXX”, “XXXXXX” stands for last 3bytes of the device MAC address.
-
Page 10: Ap/Sta Mode
5) Click “Switch protocol” to wait for tens of seconds to connect to the internet. 2.2.2. AP/STA mode In this mode, RHF2S025 gateway will have both AP and STA functions. The gateway will connect to the internet and cloud server via wireless WiFi, and also provide WiFi services to others stations. - Page 11 RisingHF RHF2S025 user manual Figure 2- 12 Select the scanned SSID 4) Click “Switch mode” to switch mode, wait about 1 minute till the page will automatically refresh, or you could refresh the page by manual. The WiFi led will turn green if it succeeds. If you fill in with wrong Stakey or invalid SSID, the device will return to AP mode.
-
Page 12: Pppoe Mode
All the methods above could help you connect the gateway RHF2S025 access to the internet and also the cloud server. Then you can demo the LoRaWAN communication with the node. - Page 13 Figure 2- 16 RHF3M076B LoRaWAN Modem 1) RHF3M076 is a USB CDC device. Please install the driver before using it. For installation drivers please refer to the RisingHF UM01516 User’s manual. The driver file can be downloaded from the RisingHF WiKi or by contacting support@risinghf.com.
- Page 14 RisingHF RHF2S025 user manual //Demo Uplink AT+CMSGHEX="00 11 22 33” • //Demo downlink Figure 2- 17 Demo uplink with ACK 4) Visit the https://cloud.iotsquare.xyz server. Click on the device name in the iotsquare server to enter the device details.
-
Page 15: Advanced Operation
“192.168.100.1” into the web configuration interface. Default login user name: admin, password: admin. RHF2S025 factory default mode is the AP mode, and there are two ways to login into web interface. Use your PC to scan the device SSID (ie WiFi name) which is “RHF2S025_XXXXXX”, “XXXXXX”... - Page 16 Figure 3- 2 Login on the web page 2) Page after login: Figure 3- 3 Page after login RHF2S025 web interface menu is as follows: Level 1 menu: Status: Mainly show system status Network: Network-related configuration, to provide settings of connecting to internet, test network and...
-
Page 17: Lora Sdk
Logout: logout 3.2. LoRa SDK 3.2.1. Modify SDK configuration RHF2S025 is built-in Packet Forwarder SDK, and provides a web page for configuration, User can configure their own SDK according to their needs. Currently available configuration options are shown below: Protocol Version: The protocol version of the SDK. -
Page 18: Led Instruction
Figure 3- 4 LoRa SDK configuration 3.3. Led instruction RHF2S025 panel provides a total of six LED for functional instructions, which make users know the different status of the device. They are Power, System, WiFi, LoRa,USB and 4G instruction LEDs. In the network RJ45 port there is another LED to show network status. -
Page 19: Key
Note: After the factory settings are restored, the user will lose all configuration data. 3.5. User interface RHF2S025 provides a total of two external interfaces for users to use, respectively RJ45 and USB interface. 3.5.1. RJ45 interface The RJ45 network port would be as WAN port in AP and PPPoE mode. -
Page 20: Usb Interface
Section 2.2 of this document for more details. 3.5.2. USB interface This interface allows you to upgrade the firmware for RHF2S025. When there is a U disk with FW inserted, re-power the device will trigger the upgrading. NOTE: Do not power off the device or perform other operations during the upgrade process to avoid upgrading failure. - Page 21 RisingHF RHF2S025 user manual Figure 4- 2 select Packet Forwarder 4) Fill in the MAC address, MAC address label is usually posted on the top of the gateway device, the format is xx:xx:xx:xx:xx:xx Figure 4- 3 Fill in the gateway information 5) Click“Register Packet Forwarder Semtech gateway”to complete the registration...
-
Page 22: Power Adapter
7) LoRaWAN communication demo note: Register a node in the cloud server to do LoRaWAN communication demo. Please refer to RisingHF RHF3M076 user manual ”[RHF-PS01509]LoRaWAN Class AC AT Command Specification - v4.3” for how to use RisingHF LoRaWAN modem. When the LoRa led turn to green from red, it connected to the cloud server. And you could do LoRaWAN communication with the node. -
Page 23: Restore Factory Settings
7. Upgrade firmware Follow the steps below to upgrade the firmware: 1) Download the FW into the U disk from RisingHF website. User can’t change the firmware name, or the device will fail to upgrade. 2) Insert the U disk into the device and then power on again. -
Page 24: Troubleshooting
RHF2S025 user manual 8. Troubleshooting Q1：RHF2S025 provides three kinds of mode to connect to network, but how to use them? A1：APmode: When the gateway is far away from the router, but a wired connection is possible. APSTA mode: When the gateway is nearby the router and WiFi signal is strong. - Page 25 Q7：How to do when the firmware upgrade fail? A7：Power on RHF2S025, it means the upgrading fails when the system led doesn’t start to blink slowly in 3 min. Please refer to section 6 of this document to repeat the upgrading steps.
-
Page 26: Revision
RisingHF RHF2S025 user manual Revision V0.3 2019-04-23 +Add description to connect to Loriot server V0.2 2019-04-04 + Add environmental noise scanning part function introduction V0.1 2019-03-18 + First version V0.3 2019-04-23 www.risinghf.com... - Page 27 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by RisingHF for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
