RisingHF
UM01749
LoRaWAN IOT Gateway RHF2S008P4G Installation Guide
V0.5
Document information
Info
Keywords
Abstract
LoRaWAN IOT Gateway RHF2S008P4G Installation Guide
Content
RisingHF, LoRaWAN, Installation, Lighting surge protection
This document describes how to install and use RisingHF
RHF2S008 LoRaWAN IoT Gateway.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RisingHF RHF2S008P4G
Summary of Contents for RisingHF RHF2S008P4G
- Page 1 RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide UM01749 LoRaWAN IOT Gateway RHF2S008P4G Installation Guide V0.5 Document information Info Content Keywords RisingHF, LoRaWAN, Installation, Lighting surge protection This document describes how to install and use RisingHF Abstract RHF2S008 LoRaWAN IoT Gateway.
-
Page 2: Table Of Contents
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide Content Content ..............................2 Figure ..............................3 Table ..............................3 1 Preface ............................... 1 2 RHF2S008P4G appearance ....................... 2 3 Installation ............................3 3.1 Mechanical size ..........................3 3.2 Install the Gateway ........................4 3.2.1 SIM Card Installation (For Mobile Cellar User Only) ............... - Page 3 Figure 3-7 GPS antenna installation ....................10 Figure 3-8 RF Connector and Lightening Protection Water Proof Enhancement ........11 Figure 3-9 Guide for PoE connection ....................13 Figure 3-10 RHF2S008P4G fixed in field ..................... 14 Figure 3-11 Suggested GW installation in field ..................15 Table...
-
Page 4: Preface
LoRaWAN IOT Gateway RHF2S008P4G Installation Guide 1 Preface This document (from v0.4) is the installation guide of RHF2S008P4G, an industrial LoRaWAN gateway. For the old version RHF2S008A4G, please refer to the v0.3. RHF2S008P4G LoRaWAN gateway is designed and produced by RisingHF, which is an 8 channel industrial gateway based on LoRaWAN protocol with PoE function. -
Page 5: Rhf2S008P4G Appearance
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide 2 RHF2S008P4G appearance LoRa Figure 2-1 RHF2S008 appearance V0.5 2017-04-08 www.risinghf.com... -
Page 6: Figure
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide 3 Installation Table 3-1 package list below show the list of materials in the package. Table 3-1 package list Material RHF2S008P4G RHF2S008P4G-xxx PoE injector PoE30G-AT LoRaWAN Antenna RXHF-ANTxxx-GF Fixed collar for LoRaWAN antenna... -
Page 7: Install The Gateway
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide Figure 3-2 RHF2S008 Mechanical size 3.2 Install the Gateway 3.2.1 SIM Card Installation (For Mobile Cellar User Only) If the user need use mobile cellar network, please insert the SIM card and test before go to the field. -
Page 8: Device Installation
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide 3.2.2 Device Installation Fix gateway to the main fixture, as the below picture shows: （1） （2） V0.5 2017-04-08 www.risinghf.com... - Page 9 RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide （3） Figure 3-4 Fix the GW to the main fixture Fix the auxiliary fixture to the main fixture. （1）The auxiliary fixture and main fixture V0.5 2017-04-08 www.risinghf.com...
- Page 10 RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide 、 （2）auxiliary fixture to main fixture Fix LoRaWAN antenna to the antenna fixture; （1）LoRaWAN antenna fixture position V0.5 2017-04-08 www.risinghf.com...
- Page 11 RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide （2）LoRaWAN antenna fixed （3）surge protector fixed V0.5 2017-04-08 www.risinghf.com...
- Page 12 RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide （4）Connect the LoRaWAN antenna to RF port with RF cable Figure 3-5 Fix antenna to the fixture 4G antenna installation. Connect 4G antenna with RHF2S008 directly. The assembled device is as below picture: Figure 3-6 4G antenna installed V0.5 2017-04-08...
-
Page 13: Rf Connector And Lightening Protection Waterproof Enhancement (Only For Outdoor Installation)
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide GPS antenna installation: （1）GPS Antenna （2）GPS installed with cable connected Figure 3-7 GPS antenna installation 3.2.3 RF Connector and Lightening Protection Waterproof Enhancement (Only For Outdoor Installation) It is recommended to make water proof enhancement for LoRaWAN antenna connector, 4G antenna connector and GPS antenna, if the device is installed outdoor. -
Page 14: Poe Input
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide （1） （2） （3） （4） Figure 3-8 RF Connector and Lightening Protection Water Proof Enhancement 3.2.4 PoE input Follow pic below to connect the power and Ethernet over PoE. V0.5 2017-04-08 www.risinghf.com... - Page 15 RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide （1）Unscrew the RJ45 water proof joint （2）connect to socket （3）insert the cable to RJ45 and screw the joint V0.5 2017-04-08 www.risinghf.com...
- Page 16 RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide （4）PoE connected Figure 3-9 Guide for PoE connection Note: It is recommended to use both a shielded socket and shielded cable when the PoE cable is long and outdoor and exposed to air. It’s strongly to ground the shielding cover of the cable.
-
Page 17: Lightening Protection Cautions
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide Figure 3-10 RHF2S008P4G fixed in field 3.3 Lightening Protection Cautions Lighting protection include direct lighting protection and indirect lighting protection. We should avoid fix the device to face the direct lighting protection. Below we just list some essential and useful methods to protect from indirect lighting, induction lighting or surge. -
Page 18: Performance Enhancement When Installation
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide 4. Lightning rod ground down lead should be no less than 8 mm diameter galvanized round steel or cross-sectional area not less than 48 mm squared multi-strand copper wire. When using multiple strands of copper wire for grounding, please make steel tube to prevent the mechanical damage. -
Page 19: Revision
RisingHF LoRaWAN IOT Gateway RHF2S008P4G Installation Guide Revision V0.5 2017-04-08 + add the part for suggested installation in field V0.4 2017-04-06 + update to support RHF2S008P4G. Just keep the part of installation. V0.3 2016-06-22 + First version V0.5 2017-04-08 www.risinghf.com... - Page 20 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by RisingHF for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
