Note: All other values are default values.
4.
Turn on the VIU-323 to start a terminal session. The message: "Press any key to start
configuration..." appears (if no message appears, press CTRL+X and wait for the
message). Press any key within six seconds of receiving the message to display a menu
of configuration options.
5.
Type 1 and press Enter; type 1 again and press Enter.
6.
Enter the IP address for Interface No. 1 and press Enter (the address must be entered
in dotted decimal format without leading zeroes, for example: 170.4.10.20).
7.
Enter the default router IP address and press Enter (the address must be entered in
dotted decimal format without leading zeroes, for example: 170.4.10.20).
8.
Enter the IP subnet mask in hexadecimal notation and press Enter. The PC displays
configuration information and the VIU-323 automatically reboots.
9.
When Ready appears on the PC, disconnect the cable that connects it to the VIU-323
and close the terminal session.
After you set the IP addresses, run OnLAN Config 323. Note that the Select Unit screen
will display the IP address of the VIU-323 that you defined above in the list of RADVision
units. Select it from the list and continue to configure the VIU-323. Notice that the IP
addresses defined above appear in their appropriate screens during the configuration
procedure.
IP Address Problems
9-7
