Polycom EagleEye Digital Breakout Adapter Supplemental User Manual

®
Polycom EagleEye
Supplemental User Guide
December 2014 | 1725-68907-001/A
Product Description
®
Polycom EagleEye™ Digital Breakout Adapter - Camera
The Polycom EagleEye Digital Breakout Adapter (DBA) - Camera, is a breakout adapter that allows the digital
cameras, the Polycom EagleEye IV, and the Polycom EagleEye Acoustic, to be broken out into HDMI and Serial
(DB9) signals.
®
Polycom EagleEye™ Digital Breakout Adapter - Codec
The Polycom EagleEye Digital Breakout Adapter (DBA) - Codec, allows the input of HDMI and Serial for control
into an HDCI input on the RealPresence Group Series codecs.
The two EagleEye Digital Breakout Adapters can be used together to extend the distance from EagleEye IV
cameras to the Group Series codecs.
Setting up the Polycom® EagleEye™ Digital Breakout Adapter
Package Contents and Optional Accessories
TM
Digital Breakout Adapter for Camera and Group Series Codec
Best Practices and Safe Use
EagleEye Digital Breakout Adapter - Camera:
•
Use the supplied Polycom power supply (part number 1465-52748-040).
•
Verify the polarity of the power supply as shown on the DBA next to the power supply input.
•
Use with HDCI Polycom EagleEye IV Camera Cable. Either 2457-64356-001 (3m); 2457-64356-100 (1m), or
2457-64356-018 (457mm).
•
Use with certified HDMI compliant cable.
•
Use with certified EIA/TIA-RS-232 cable. Use straight-through type, not crossover.
•
Do not hot plug the serial cable. Disconnecting or connecting the RS-232 cable during operation may cause
unexpected system behavior. If this happens, cycle the power to the codec or camera to eliminate this issue.
•
The signal quality is dependent on the quality of the HDMI and serial signals at the output of the DBA and
associated cables, if the mating device has an equalizer, and the electrical noise in the installed environment.
To ensure proper operation with all devices, the HDMI and EIA/TIA-RS-232 specs should be met at the input
to all mating devices.
EagleEye Digital Breakout Adapter - Codec:
•
Use with HDCI Polycom EagleEye IV camera cable. Either 2457-64356-001 (3m), 2457-64356-100 (1m), or
2457-64356-018 (457mm).
•
Use with certified HDMI compliant cable.
•
Use with certified EIA/TIA-RS-232 cable. Use straight-through type, not crossover.
•
Do not hot plug the serial cable. Disconnecting or connecting the RS-232 cable during operation may cause
unexpected system behavior. If this happens, cycle the power to the codec or camera to eliminate this issue.
•
Polycom tested with cables less than 3 meters in a normal environment. The maximum cable length possible
depends on the signal quality of the HDMI and serial signals at the output of the DBA and associated cables,
if the mating device has an equalizer, and the electrical noise in the installed environment. To ensure proper
operation with all devices, the HDMI and EIA/TIA-RS-232 specs should be met at the input to all mating
devices.
•
The following HDMI features are not provided: DDC for EDID support, HDCP, and CEC.
•
Without EDID support, digital (HDMI) sources connected to the system must have a mechanism for bypassing
EDID detection, for setting up the video resolution manually, or using a fixed video resolution. Refer to the
Video Format Resolutions table below for supported resolutions.
•
The signal quality is dependent on the quality of the HDMI and serial signals at the output of the DBA and
associated cables, if the mating device has an equalizer, and the electrical noise in the installed environment.
To ensure proper operation with all devices, the HDMI and EIA/TIA-RS-232 specs should be met at the input
to all mating devices.
Supported Video Format Resolutions
Mode Active Pixels Active Lines
480i 720 480
576i 720 576
480p60 720 480
576p50 720 576
720p50 1280 720
720p60 1280 720
1080i50 1920 1080
1080i60 1920 1080
1080p50 1920 1080
1080p60 1920 1080
Parameters and Interfaces
EagleEye Digital Breakout Adapter - Camera:
•
Includes its own power supply (part number 1465-52748-040 100-240VAC, 1.3A, 50/60Hz; 12VDC at 3.3A.
Verify the polarity of the power supply as shown on the Digital Breakout Adapter next to the power supply
input.
•
Operating ambient conditions: Operating temperature 0°C to 40°C, Relative Humidity: 35% to 90% non-
condensing @ 40°C.
EagleEye Digital Breakout Adapter - Codec:
•
Has no active components. Operating ambient conditions: Operating temperature 0°C to 40°C, Relative
Humidity: 35% to 90% non-condensing @ 40°C.
European EMC Immunity standard (EN55024:2010) testing was performed using cables less than 3 meters in
length.
Installation Requirements
Installation must be performed in accordance with all relevant national wiring rules. The outlet to which this
apparatus is connected must be installed near the equipment and must always be readily accessible. The user is
cautioned that any changes or modifications not expressly approved by Polycom, Inc. could void the user's
authority to operate the equipment. This product is only for use in commercial, and light industrial areas.
Safety Considerations for Storage and Transportation
•
The EagleEye Digital Breakout Adapter has a seven year period of life. The EagleEye Digital Breakout
Adapter has a seven year period of storage.
•
The EagleEye Digital Breakout Adapter has a -30°C to 60°C (-22°F to 140°F), 35% to 90% non-condensing
@ 40°C storage & transportation requirement.
Vertical Refresh Hz Pixel Clock MHz Video Standard
59.94 27 CEA-861-D:6
50 27 CEA-861-D:21
59.94 27 CEA-861-D:2
50 27 CEA-861-D:17
50 74.25 CEA-861-D:19
59.94 74.25/(1.001) CEA-861-D:4
50 74.25 CEA-861-D:39
59.94 74.25/(1.001) CEA-861-D:5
50 148.50 CEA-861-D:31
59.94 148.50/(1.001) CEA-861-D:16
