Preparing for Configuration

Navigating the Configuration Software Screens

The configuration software comprises sequential screens that can be accessed through the
Next and Prev buttons. Some screens also have secondary screens that are accessed through
buttons. These are identified by the name of the screen they invoke, for example, the
Date/Time Settings screen is a secondary screen of the Unit Identification screen and can be
accessed from the Date/Time button on this screen. The following is a description of the
configuration software navigation buttons.
Button Shortcut Key
Abort Alt+A
Next Alt+N
Prev Alt+P
Finish Alt+F
Detect Alt+D
Save Alt+S
OK
Cancel
In a Confirmation box
Yes Alt+Y
No Alt+N
The configuration software does not let you exit a screen before you have defined all of the
required parameters. A message appears informing you to fill in the required fields.
4-4
Action
Exits the Configuration program without saving your
changes.
Moves to a subsequent screen, saving any changes you
made.
Moves to a previous screen. If you exit a dialog box
using Prev, changes you make to the information in the
dialog box are saved.
Allows you to save the configuration settings in a file to
be uploaded at a later time to the VIU-323.
Sends a broadcast message to the network, requesting
identification from any units that have not yet identified
themselves.
Saves parameter values of the dialog box to the local
disk as a text file in the directory where you installed the
Configuration Software.
Saves the information and exits the dialog box. The
saved tables contain only static data that is both
readable and writeable.
Returns to the previous dialog box without saving any
changes you made to the current dialog box.
Saves the parameters and proceeds to the next screen.
Returns to the previous screen.
