11. Orient the Seat (8) and Seat Frame (7) assembly
as shown. Attach the Seat Frame to the Seat
Carriage (3) with four M8 x 40mm Screws (58).
12. Orient the Backrest (6) as shown. Attach the
Backrest to the Backrest Frame (5) with two M6
x 36mm Screws (69).
13. Plug the Seat Frame Pulse Wire (22) into the
receptacle in the Left Seat Shield (41).
11
58
3
12
69
5
13
22
Receptacle
41
10
8
7
58
6
