Model No. NTEX02722-INT.1
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
MEMBER CARE
UNITED KINGDOM
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
iFIT Inc.
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL
iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NordicTrack S27i and is the answer not in the manual?

Questions and answers

Related Manuals for ICON NordicTrack S27i

Summary of Contents for ICON NordicTrack S27i

  • Page 1 Write the serial number in the space above for reference. Serial Number Decal MEMBER CARE UNITED KINGDOM Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT WF5 9TT UNITED KINGDOM AUSTRALIA Call: 1800 993 770 E-mail: australiacc@iconfitness.com Write: iFIT Inc.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your studio cycle before using your studio cycle. iFIT assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Congratulations for selecting the revolutionary For your benefit, read this manual carefully before you use the studio cycle. If you have questions after NORDICTRACK COMMERCIAL S27I. The ® COMMERCIAL S27I is unlike any ordinary exercise reading this manual, please see the front cover of this bike.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tool(s): • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you complete all assembly steps.
  • Page 7 2. See the inset drawing. Orient the Handlebar Post (7) so that the lower slot (A) is on the side shown. Next, loosen the indicated Post Knob (100) and insert the Handlebar Post (7) all of the way into the Frame (1). Make sure that the indi- cated slots (B) are aligned.
  • Page 8 4. Remove the Mount Cover (153) from the Console Support (8), if necessary. Then, pull the wires (E) out of the Console Support. Make sure that the wires are behind the Console Bracket (11). Then, press the Mount Cover (153) into place on the Console Support (8).
  • Page 9 6. Look under the Console Support (8) and identify the Upper Wire (123), which has a larger con- nector than the Extension Wire (124). Connect the Upper Wire (123) to the Lower Wire (122) extending from the Handlebar Post (7). Tip: The wire connectors should slide together easily and snap into place with an audible click.
  • Page 10 8. Note: For clarity, the Console and the wires are not shown in the drawing. Tilt the Console (not shown) upward and down- ward a few times. If the movement feels too loose, tighten the four M6 x 15mm Cap Screws (157) in the Rear Bracket Mount (114) until the movement no longer feels loose.
  • Page 11 10. Orient the Lower Console Cover (154) as shown and press it onto the back of the Console (10). Position the wires (not shown) in the indicated notch (I). Tip: Avoid pinching the wires. Orient the Upper Console Cover (155) as shown and press it onto the back of the Console (10).
  • Page 12 12. Orient the Saddle Post (13) as shown. Loosen the indicated Post Knob (100). Next, insert the Saddle Post (13) into the Frame (1), and slide the Saddle Post to the desired height. Then, tighten the Post Knob. 13. Set the two Hand Weights (14) in the Weight Holders (164, 165).
  • Page 13 14. IMPORTANT: Always plug the Power Adapter (119) into the studio cycle before you plug it into an outlet. Plug the Power Adapter (119) into the receptacle on the rear of the studio cycle. Note: To plug the Power Adapter (119) into an outlet, see HOW TO PLUG IN THE POWER ADAPTER on page 14.

  • Page 14: How To Use The Studio Cycle

    HOW TO USE THE STUDIO CYCLE HOW TO PLUG IN THE POWER ADAPTER FEATURES OF THE STUDIO CYCLE IMPORTANT: If the studio cycle has been exposed Measuring Watts to cold temperatures, allow it to warm to room tem- perature before you plug in the power adapter (A). Each studio cycle is calibrated to measure your power If you do not do this, you may damage the console output and to allow you to monitor your watts and...
  • Page 15 HOW TO ADJUST THE GEOMETRY OF THE How to Adjust the Saddle Post STUDIO CYCLE For effective training, the saddle should be at the The studio cycle can be adjusted to match the geom- proper height. As you pedal, there should be a slight etry of your road bike to promote correct form and to bend in your knees when the pedals are in the lowest ensure proper training of the muscles.
  • Page 16 How to Adjust the Position of the Console tabs (H) on the buckles, adjust the The console (F) can toe straps to the be adjusted upward, desired position, downward, or to and then release the side. To adjust the tabs. the position of the console, simply hold the sides of the con-...
  • Page 17 How to Use the Clip-in Side of the Pedals HOW TO LOCK THE STUDIO CYCLE To use the clip-in side of the pedals, you must wear IMPORTANT: Lock the studio cycle cycling shoes and the included cleats must be attached when it is not in to your cycling shoes.

  • Page 18: How To Use The Console

    HOW TO USE THE CONSOLE CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode of the console, you can change the resistance of the pedals and the incline The advanced console offers an array of features of the frame with the touch of a button. designed to make your workouts more effective and enjoyable.
  • Page 19 HOW TO TURN ON THE CONSOLE HOW TO USE THE TOUCH SCREEN The included power adapter must be used to operate The console features a tablet with a full-color touch the studio cycle. See HOW TO PLUG IN THE POWER screen.
  • Page 20 HOW TO SET UP THE CONSOLE Firmware updates are always designed to improve your exercise experience. As a result, Before you use the studio cycle for the first time, set up new settings and features may not be described the console. in this manual.
  • Page 21 HOW TO USE THE MANUAL MODE 4. Follow your progress. 1. Touch the screen or press any button on the The console offers several display modes. The console to turn on the console. display mode that you select will determine which workout information is shown.
  • Page 22 6. Turn on the fan if desired. THE OPTIONAL HEART RATE MONITOR The fan has several speed settings, Whether your including an auto mode. While the goal is to auto mode is selected, the speed of burn fat or to the fan will automatically increase strengthen your or decrease as your pedaling speed...
  • Page 23 HOW TO USE A FEATURED WORKOUT When you select a workout, the screen will show an overview of the workout that includes details To use a featured workout, the console must be con- such as the duration and distance of the workout nected to a wireless network (see HOW TO CONNECT and the approximate number of calories you will TO A WIRELESS NETWORK on page 29).
  • Page 24 IMPORTANT: The calorie goal shown in the 5. Wear headphones if desired. workout description is an estimate of the number of calories that you will burn during To connect your headphones to the console, first the workout. The actual number of calories turn on your headphones, place them in pairing that you burn will depend on various factors, mode, and place them near the console.
  • Page 25 HOW TO CREATE A DRAW-YOUR-OWN-MAP If you make a mistake, touch Undo in the map WORKOUT options. 1. Touch the screen or press any button on the The screen will display the elevation and distance console to turn on the console. statistics for your workout.
  • Page 26 HOW TO USE AN IFIT WORKOUT 4. Select an iFIT workout from the home screen or the workout library. To use an iFIT workout, you must be logged into your iFIT account (see step 3 below) and the console Touch the buttons at the bottom of the screen to must be connected to a wireless network (see HOW select either the home screen (Home button) or the TO CONNECT TO A WIRELESS NETWORK on...
  • Page 27 6. Create a list of favorite iFIT workouts if desired. When your headphones and the console pair successfully, the audio from the console will play To mark an iFIT workout as a favorite, simply view through your headphones. the overview or workout summary of the desired 9.
  • Page 28 HOW TO CHANGE CONSOLE SETTINGS 3. Customize workout settings. IMPORTANT: Firmware updates are always To customize workout settings and enable workout designed to improve your exercise experience. As a features, touch In Workout, and then touch the result, new settings and features may not be described desired settings.
  • Page 29 7. Calibrate the incline system. 3. Enable Wi-Fi. To calibrate the incline system, touch Maintenance, Make sure that Wi-Fi is enabled. If it is not ® touch Calibrate Incline, and then touch Begin. The enabled, touch the Wi-Fi toggle to enable it. frame will automatically rise to the maximum incline level, lower to the minimum incline level, and then 4.

  • Page 30: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE If you are having problems connecting the console to a wireless network or if you are having problems Regular maintenance is important for optimal with your iFIT account or iFIT workouts, go to performance and to reduce wear. Inspect and properly support.iFIT.com.
  • Page 31 HOW TO ADJUST THE CONSOLE PIVOT AND TILT INCLINE SYSTEM TROUBLESHOOTING If the console feels too loose or does not stay in place If the frame does not move to the correct incline level, when it is moved from side to side, first remove the see HOW TO CHANGE CONSOLE SETTINGS on Mount Cover (153).
  • Page 32 HOW TO ADJUST THE REED SWITCH If the console does not display correct feedback, the reed switch should be adjusted. To adjust the reed switch, first press the power switch and unplug the power adapter. Next, remove the three indicated #8 x 5/8" Screws (17) from the Right and Left Shields (30, 32).
  • Page 33 HOW TO ADJUST THE DRIVE BELT If the pedals slip while you are pedaling, even when the resistance is adjusted to the highest setting, the drive belt may need to be adjusted. To adjust the drive belt, first press the power switch and unplug the power adapter.

  • Page 34: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.

  • Page 35: Part List

    PART LIST Model No. NTEX02722-INT.1 R1221B Key No. Qty. Description Key No. Qty. Description Frame Resistance Disc Base Lower Saddle Clamp Cleat Assembly Upper Saddle Clamp Roller Saddle M6 Shoulder Screw Anchored Zip Tie Inner Leg Sleeve Roller Axle Handlebar Post #8 x 1/2"...
  • Page 36 Key No. Qty. Description Key No. Qty. Description Carriage Knob Shoe Pin M6 x 20mm Machine Screw Pulley Magnet M4 x 10mm Machine Screw M6 x 15mm Screw Incline Motor Sleeve Thrust Washer M10 Washer Brake Knob Cap Tray Cover M6 Locknut M4 x 15mm Machine Screw Lower Brake Knob...

  • Page 37: Exploded Drawing

    EXPLODED DRAWING A Model No. NTEX02722-INT.1 R1221B 86 57...
  • Page 38 EXPLODED DRAWING B Model No. NTEX02722-INT.1 R1221B...
  • Page 39 EXPLODED DRAWING C Model No. NTEX02722-INT.1 R1221B...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
