Model No. PFEVEX74012.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
(under frame)
QUESTIONS?
If you have questions, or if there are
missing parts, please contact us:
UNITED KINGDOM
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
CASTLEFORD
WF10 5QJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
www.iconeurope.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ICON Pro-Form 425 ZLX PFEVEX74012.0
Summary of Contents for ICON Pro-Form 425 ZLX PFEVEX74012.0
- Page 1 UNITED KINGDOM Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. c/o HI Group PLC Express Way CASTLEFORD WF10 5QJ UNITED KINGDOM AUSTRALIA Call: 1800 993 770 E-mail: australiacc@iconfitness.com...
-
Page 2: Table Of Contents
User weight must not exceed 275 pounds. This product should always be used on a level surface. This product is not intended for therapeutic use. Replace label if damaged, illegible, or removed. PROFORM is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new PROFORM reading this manual, please see the front cover of this ® ZLX exercise bike. Cycling is an effective exercise manual. To help us assist you, note the product model for increasing cardiovascular fitness, building endur- number and serial number before contacting us. -
Page 5: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly. -
Page 6: Assembly
ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tools: • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you complete all assembly steps. - Page 7 3. Orient the Upright (2) as shown. Have a second person hold the Upright near the Frame (1). Locate the wire tie inside the Upright (2). Tie the lower end of the wire tie to the ends of the Main Wire Tie Wire (53) and the Frame Pulse Wire (42).
- Page 8 6. Orient the Console Plate (11) as shown. Then, insert the Main Wire (53) and the Frame Pulse Wire (42) upward through the Console Plate. Avoid pinching the wires Tip: Avoid pinching the wires. Insert the Console Plate (11) into the Upright (2). Orient the Handlebar (13) as shown.
- Page 9 8. While a second person holds the Console (4) near the Console Plate (11), connect the wires on the Console to the Main Wire (53) and to the Frame Pulse Wires (42). Insert the excess wire into the Console Plate (11) or into the Console (4).
- Page 10 11. Orient the Seat (8) and Seat Frame (7) assembly as shown. Attach the Seat Frame to the Seat Carriage (3) with four M8 x 40mm Screws (58). 12. Orient the Backrest (6) as shown. Attach the Backrest to the Backrest Frame (5) with two M6 x 36mm Screws (69).
- Page 11 14. Identify the Right Pedal (36), which is marked with an “R.” Strap Using an adjustable wrench, firmly tighten the Right Pedal (36) clockwise into the Right Crank Arm (83). Firmly tighten the Left Pedal (not shown) counterclockwise into the Left Crank Arm (not shown).
-
Page 12: How To Use The Exercise Bike
HOW TO USE THE EXERCISE BIKE HOW TO ADJUST THE SEAT HOW TO MOVE THE EXERCISE BIKE The seat can be To move the exercise adjusted forward bike, hold the handle or backward to the on the rear stabilizer position that is the and carefully lift it most comfortable. - Page 13 CONSOLE DIAGRAM FEATURES OF THE CONSOLE For example, lose unwanted pounds with the 8-week Weight Loss workout. iFit workouts control the resis- The advanced console offers an array of features tance of the pedals while the voice of a personal trainer designed to make your workouts more effective and coaches you through your workouts.
- Page 14 HOW TO USE THE MANUAL MODE Profile—When a workout is selected, this display mode will show a profile of the resistance settings 1. Turn on the console. of the workout. Pulse—This display mode will show your heart rate Press any button or begin pedaling to turn on the console.
- Page 15 5. Measure your heart rate if desired. HOW TO USE A PRESET WORKOUT If there are sheets 1. Turn on the console. of plastic on the Contacts metal contacts Press any button or begin pedaling to turn on the on the handgrip console.
- Page 16 HOW TO USE AN IFIT WORKOUT As you exercise, keep your pedaling speed near the goal speed for the current seg- iFit cards are available separately. To purchase iFit ment. The goal speed will cards, go to www.iFit.com or see the front cover of this appear in the display when manual.
- Page 17 HOW TO USE THE SOUND SYSTEM 2. Select a unit of measurement if desired. To play music or audio books through the console The console can show pedaling speed and dis- sound system while you exercise, plug your audio tance in either miles or kilometers. cable into the jack on the console and into a jack on your MP3 player or CD player;...
-
Page 18: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise bike regu- Next, locate the Reed Switch (46). Loosen, but do not larly. Replace any worn parts immediately. remove, the M4 x 16mm Screw (61). To clean the exercise bike, use a damp cloth and a small amount of mild soap. - Page 19 HOW TO ADJUST THE DRIVE BELT Hold the two M8 Locknuts (67) and loosen the two M8 x 16mm Flat Head Screws (73). Next, loosen the If you can feel the pedals slip while you are pedaling, M10 x 35mm Hex Screw (74) until the Drive Belt (77) is even when the resistance is adjusted to the highest tight.
-
Page 20: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 21: Part List
PART LIST Model No. PFEVEX74012.0 R0412A Key No. Qty. Description Key No. Qty. Description Frame Bearing Upright Reed Switch Seat Carriage Clamp Console Resistance Mechanism Backrest Frame Flywheel Axle Backrest Idler Seat Frame Resistance Motor Seat Resistance Cable Carriage Rail Main Wire Pulse Sensor M10 x 80mm Screw/Bolt... -
Page 22: Exploded Drawing
EXPLODED DRAWING A Model No. PFEVEX74012.0 R0412A... - Page 23 EXPLODED DRAWING B Model No. PFEVEX74012.0 R0412A...
-
Page 24: Ordering Replacement Parts
European standards of environmental protection. If you require more information about safe and correct disposal methods, please contact your local city office or the establishment where you purchased this product. Part No. 328506 R0412A Printed in China © 2012 ICON IP, Inc.
