Model No. PFEX33921.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to my.proform.com.
MEMBER CARE
For service at any time, go to
support.proform.com.
Or call 1-833-680-IFIT
(1-833-680-4348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO-FORM SPORT CX and is the answer not in the manual?

Questions and answers

Summary of Contents for ICON PRO-FORM SPORT CX

  • Page 1 proform.com Model No. PFEX33921.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to my.proform.com. MEMBER CARE For service at any time, go to support.proform.com.
  • Page 2: Table Of Contents

    PROFORM and IFIT are registered trademarks of ICON Health & Fitness, Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google LLC. The Bluetooth ®...
  • Page 3: Important Precautions

    To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 STANDARD SERVICE PLANS...
  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the new PROFORM ® reading this manual, please see the front cover of this SPORT CX exercise bike. Cycling is an effective manual. To help us assist you, note the product model exercise for increasing cardiovascular fitness, build- number and serial number before contacting us.
  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.
  • Page 7: Assembly

    ASSEMBLY • To hire an authorized service technician to • In addition to the included tool(s), assembly assemble this product, call 1-800-445-2480. requires the following tool(s): one Phillips screwdriver • Assembly requires two persons. one adjustable wrench • Place all parts in a cleared area and remove the packing materials.
  • Page 8 2. If there are shipping tubes (not shown) attached to the front and rear of the Frame (1), remove and discard the shipping tubes and the hardware attaching them. Orient the Front Stabilizer (2) as shown, and attach it to the Frame (1) with two M10 x 25mm Screws (69).
  • Page 9 4. Tip: See the inset drawing to learn how to operate the Adjustment Handle (14). Loosen handle Locate the Adjustment Handle (14) on the rear of the Frame (1). Pull the Adjustment Handle Pull handle outward, and insert the Saddle Post (7) into the Frame.
  • Page 10 6. Note: You can attach your own pedals if desired. Identify the Right Pedal (16). Using your fingers, turn the Right Pedal about halfway into the Right Crank Arm (18). Then, use the included wrench to fully tighten the Right Pedal. Repeat this step with the Left Pedal (not shown).
  • Page 11 8. See the inset drawing. Connect the connector on the Upper Wire (90) to the connector on the Lower Wire (82). Next, tighten the zip tie (C) around the indicated mark (D) on the Upper Wire (90). Then, cut off the excess zip tie.
  • Page 12 10. Untie the wire tie (E) holding the Upper Wire (90) to the Handlebar (4). While a second person holds the Console Mount (5) near the Handlebar (4), connect the Extension Wire (12) in the Console Mount to the Upper Wire (90) in the Handlebar (4). Tip: Avoid pinching the wires.
  • Page 13 12. Orient the Console Housing (86) and the Console Deck (89) as shown. Attach the Console Housing (86) to the Console Deck (89) with four M4 x 16mm Screws (11); start all the Screws, and then tighten them. 13. While a second person holds the Console Deck (89) near the Console Mount (5), connect the Console Wire (J) to the Extension Wire (12).
  • Page 14 15. The Console (6) requires three AA batteries (not included); alkaline batteries are recommended. Do not use old and new batteries together or alkaline, standard, and rechargeable batter- ies together. IMPORTANT: If the Console has been exposed to cold temperatures, allow it to warm to room temperature before you insert batteries.
  • Page 15: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE HOW TO LEVEL THE EXERCISE BIKE HOW TO ADJUST THE SADDLE POST If the exercise bike For effective exercise, the saddle should be at the rocks slightly on your proper height. As you pedal, there should be a slight floor during use, bend in your knees when the pedals are in the lowest turn one or both of...
  • Page 16 HOW TO ADJUST THE HANDLEBAR HOW TO USE THE PEDALS To use the pedals (F), To adjust the insert your shoes into height of the handlebar, first the toe cages and loosen the adjust- pull the ends of the ment handle (E) toe straps.
  • Page 17: How To Use The Console

    HOW TO USE THE CONSOLE CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can also connect your tablet to the console and use the iFIT ® app to record and track your workout The easy-to-use console enables you to change the information.
  • Page 18 The mode icons will show which mode is selected. Speed (rabbit icon)—This mode displays your Make sure that there the scan arrow icon does pedaling speed, in miles per hour. not appear. Pulse (heart icon)—This mode displays your heart To pause the console, simply stop pedaling.
  • Page 19 When the your tablet is The console has an auto-off feature. If the pedals connected, the Bluetooth icon will appear in the are not moved and the console buttons are not display.
  • Page 20 When your heart rate monitor is connected, the best results is Bluetooth icon will appear in the display. to maintain the proper heart Note: If there is more than one compatible heart rate...
  • Page 21: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 22: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING HOW TO MAINTAIN THE EXERCISE BIKE HOW TO ADJUST THE REED SWITCH Regular maintenance is important for optimal If the console does not display correct feedback, the performance and to reduce wear. Inspect and properly reed switch should be adjusted. tighten all parts each time the exercise bike is used.
  • Page 23 HOW TO ADJUST THE DRIVE BELT Then, tighten the M10 x 60mm Screw (65) until the Drive Belt (not shown) is tight. If you feel the pedals slip while you are pedaling, even when the resistance is adjusted to the highest level, When the Drive Belt (not shown) is tight, reattach the the drive belt may need to be adjusted.
  • Page 24: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your cardiovascular system, you must perform aerobic WARNING: Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
  • Page 25: Part List

    PART LIST Model No. PFEX33921.0 R0621A Key No. Qty. Description Key No. Qty. Description Frame Flywheel Spacer Front Stabilizer Wheel Rear Stabilizer Foot Handlebar Leveling Foot Console Mount Console Saddle Post Cap Saddle Post Inner Pivot Disc Saddle Reed Switch/Wire Saddle Arm Clamp Saddle Carriage...
  • Page 28: Ordering Replacement Parts
