Specifications - Polycom SoundPoint IP 670 Specifications

Polycom SoundPoint ® IP 670 Desktop Phone
®
Lines (Direct Numbers)
• Up to six lines (standalone mode)
• Up to 34 lines with Color Expansion Module(s)
SoundPoint IP Color Expansion Module Support
• The PoE version supports one Color Expansion Module
• The PSU version supports up to three Color Expansion
Modules
Display
• 320 x 160 backlit color graphical LCD
• LED backlight with custom variable intensity control
Feature Keys
• 4 context-sensitive "soft" keys
• 26 dedicated "hard" keys
- 6 line keys with bi-color (red/green) LED
- 8 feature keys
- 6 display/menu navigation keys
- 2 volume control keys
- Illuminated mute key
- Illuminated headset key
- Illuminated hands-free speakerphone key
- Dedicated hold key
Headset and Hearing Aid Compatibility
• Dedicated RJ-9 headset port
- Amplified headsets are recommended
• Compliant with ADA Section 508 Recommendations:
Subpart B 1194.23 (all)
• Hearing Aid Compatible (HAC) handset for magnetic
coupling to approved HAC hearing aids
• Compatibility with commercially-available TTY
adapter equipment
Audio Features
• Polycom HD Voice technology delivers life-like
voice quality for each audio path - the handset, the
hands-free speakerphone, and the headset
• Full-duplex hands-free speakerphone
- Type 1 compliant with IEEE 1329 full duplex
standards
• Frequency response - 150Hz - 7kHz for handset,
headset and hands-free speakerphone modes
1
• Codecs: G.722 (wideband), G.711 µ/A, and G.729A
(Annex B)
• Individual volume settings with visual feedback for
each audio path
• Voice activity detection
• Comfort noise fill
• DTMF tone generation/DTMF event RTP payload
• Low-delay audio packet transmission
• Adaptive jitter buffers
• Packet loss concealment
• Acoustic echo cancellation
• Background noise suppression
Call Handling Features
2
• Shared call/bridged line appearance
• Flexible line appearance (one or more line keys
can be assigned for each line extension)
• Busy Lamp Field (BLF)
• Distinctive incoming call treatment/call waiting
• Call timer
• Call transfer, hold, divert (forward), pickup
• Called, calling, connected party information
• Local three-way conferencing
• One-touch speed dial, redial
• Call waiting
• Remote missed call notification
• Intercom
Polycom Headquarters:
www.polycom.com
Polycom EMEA:
Polycom Asia Pacific:

Specifications

• Automatic off-hook call placement
• Do not disturb function
Other Features
• Enabled for the Polycom Productivity Suite
• Integration with Microsoft LCS 2005 for telephone
and presence
3
- Compatibility with Microsoft Office Communicator
and Windows® Messenger 5.1 Clients
• Universal Serial Bus (USB)
- Full Host Controller
- Compliant with OHCI 1.1 specification
- Support for Full-speed and Low-speed peripherals
- Type-A receptacle interface
• Local feature-rich GUI
• Time and date display
• User-configurable contact directory and call history
(missed, placed, and received)
• Customizable call progress tones
• Wave file support for call progress tones
• Unicode UTF-8 character support. Multilingual user
interface encompassing Chinese, Danish, Dutch,
English (Canada/US/UK), French, German, Italian,
Japanese, Korean, Norwegian, Portuguese, Russian,
Spanish, Swedish
Protocol Support
• IETF SIP (RFC 3261 and companion RFCs)
Network and Provisioning
• Two-port Gigabit Ethernet switch:
- 10/100/1000Base-Tx across LAN and PC ports
- Conformant to IEEE802.3-2005 (Clause 40) for
Physical Media Attachment
- Conformant to IEEE802.3-2002 (Clause 28) for Link
Partner Auto-Negotiation
• Manual or dynamic host configuration protocol
1
(DHCP) network setup
• Time and date synchronization using SNTP
• FTP/TFTP/HTTP/HTTPS
provisioning for mass deployments. Provisioning
server redundancy supported
• Web portal for individual unit configuration
• QoS Support – IEEE 802.1p/Q tagging (VLAN), Layer
3 TOS, and DSCP
• Network Address Translation (NAT) support – static
• RTCP support (RFC 1889)
• Event logging
• Local digit map
• Hardware diagnostics
• Status and statistics
Security 2
• Transport Layer Security (TLS)
• Encrypted configuration files
• Digest authentication
• Password login
• Support for URL syntax with password for boot
server
4
• HTTPS secure provisioning
• Support for signed software executables
Power
• Built-in, auto-sensing IEEE 802.3a Power over Ethernet
• External Universal AC adapter (included 48V DC)
Approvals
• FCC Part 15 (CFR 47) Class B
• ICES-003 Class B
• EN55022 Class B
• CISPR22 Class B
©2008 Polycom, Inc. All rights reserved
Polycom, the Polycom logo and SoundStation are registered trademarks and Polycom Communicator, Polycom HD Voice and PVX are trademarks of Polycom, Inc. in the U.S.
and various countries. All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.
4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) +1.925.924.6000, (F) +1.925.924.6100
270 Bath Road, Slough, Berkshire SL1 4DX, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
8 Shenton Way, #11-01 Temasek Tower, Singapore 068811 (T) +65.6389.9200, (F) +65.6323.3022
Part No. 3726-47258-001 Rev 04/08
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
server-based central
4
•
•
•
•
•
•
•
•
3
3
•
1.
4
2.
4
5
3.
4.
5.
AS/NZS CISPR 22 Class B
VCCI Class B
EN55024
EN61000-3-2; EN61000-3-3
ROHS compliant
Safety
UL 60950
CE Mark
CAN/CSA-C22.2 No. 60950
EN 60950-1
IEC 60950-1
AS/NZS 60950
Operating Conditions
Temperature: +10 to +40 degrees C (+50 to
+104 degrees F)
Relative humidity: 20%-85% (noncondensing)
Storage Temperature
-40 to +70 degrees C (-40 to +160 degrees F)
SoundPoint IP 670 Comes with:
SoundPoint IP 670 console
Handset with handset cord
Base stand
Network (LAN) cable
Universal power adapter (including country-specific
cord kit)
5
Quick Start Guide
Product registration card
Size
10.5 in x 6 in x 7.5 in x 2.5 in
(26.5 cm x 15 cm x 19 cm x 6.5 cm) (W x H x D x T)
Part Numbers/UPC Codes
2200-12670-001/610807681793 for NA, TWN
2200-12670-002/610807684053 for Japan
2200-12670-012/610807684060 for AU, NZ
2200-12670-015/610807684077 for UK, HK,
Singapore, Malaysia
2200-12670-016/610807684084 for Korea
2200-12670-022/610807684091 for China
2200-12670-122/610807684114 for ROE
2200-12670-025/610807681809, PoE version for
worldwide
Box Dimensions/Weight
13.0 x 15.5 x 6.0 in (33 x 39.5 x 15 cm) (L x W x H)
4.83 lb (2.19 kg) - includes all packaging material
Master Carton Quantity
Five
Country of Origin
Thailand
Warranty
One year
To enjoy the benefits of Polycom HD Voice when
using the phone in the headset mode, you must use a
wideband headset.
Most software-enabled features and capabilities must
be supported by the server. Please contact your IP
PBX/Softswitch vendor or service provider for a list of
supported features.
Requires SIP version 3.0.2 RevB or higher.
Requires BootROM version 4.1.0 or higher.
Universal power adapter not included in the PoE version
(P/N: 2200-12670-025).
