Specifications - Polycom CX700 Specifications

Polycom CX700 IP Phone
®
Size
• 252.7 x 268.6 x 91.3 mm (9.95 x 10.57 x 3.59 in)
when device is not tilted
• 193.2 x 268.6 x 192.1 mm (7.61 x 10.57 x 7.56
in) when device is tilted up
Weight
• Unit: 2.1 kg (4.6 lbs)
• Handset: 200 g (7 oz)
• Shipping Weight: 2 kgs (4.4 lbs..)
Power
• Power Over Ethernet IEEE 802.3af Class 2 (PoE)
• 13-Watt maximum consumption Universal AC/DC
switching power adapter
LCD Display
• 5.7" amorphous-TFT Active-Matrix Transmissive
color LCD
• Resistive touch-panel
• Backlight unit
• 320x240 resolution, 18 bit per pixel
Device Controls and Keypad
• 3x4 telephony dialpad (0-9, A-Z, *, #)
• Headset on/off button
• Speakerphone on/off button
• Mute on/off button
• Volume control
• Help button
• Touch wheel with center select button
• Biometrics fingerprint reader
Device to Network Connectivity
• Ethernet switch 2-port Ethernet switch 10/100
Base-T with RJ45 connector ports and activity
LEDs:
©2009 Polycom, Inc. All rights reserved.
Polycom and the Polycom logo design are registered trademarks of Polycom, Inc. in the U.S. and various countries.
All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.
Polycom Headquarters
4750 Willow Road
www.polycom.com Pleasanton, CA 94588
1.800.POLYCOM or
+1.925.924.6000

Specifications

• IEEE 802.3af Class 2 PoE Ethernet 10/100
Base-T
• IEEE 802.3 Ethernet 10/100 Base-T
USB Ports
• Type-A and Type-B supported (Type A connector is
for use with certified UC devices only)
• USB 1.1/USB2.0 compatible
• Full speed (12 MBPS) port
LED Indicators
• Off hook indicator
• Voice messaging indicator
• Call forwarding indicator
• Multi-color presence LED indicator
Audio
• Frequency response: 30 – 20kHz
• Signal-to-noise ratio: 78 dB (@ 1kHz)
• Dynamic range: >80 dB (@ 1kHz)
• Total Harmonic Distortion + Noise: <0.08%
(@ 1 kHZ)
Auxiliary Audio Output
• RJ9 headset jack with built-in amplifier
Audio Enhancements
• Automatic Gain Control
• Dynamic Noise Reduction
• Acoustic Echo Cancellation
Environmental Requirements
• Temperature: -10°C to 40°C (14°F to 104°F)
• Relative Humidity: 80% max (non- condensing)
• Altitude: -304.8 meter to 3962.4 meter (-1000
feet to13,000 feet)
• Light Exposure: Fluorescent overhead lighting and
window-filtered daylight (typical offices)
Polycom EMEA Polycom Asia Pacific
270 Bath Road 8 Shenton Way
Slough #11-01 Temasek Tower
Berkshire SL1 4DX Singapore 068811
+44 (0)1753 723000 +65.6389.9200
Regulatory Compliance – Approvals Gained
• • Electrical Safety
- UL60950-1 (USA / Canada)
- IEC / EN60950-1 (EU)
- GOST
- MIC
- CQC
• EMC – General
- CISPR22
• EMC – USA (Class B)
- FCC Part 15
• EMC - Canada (Class B)
- ICES00.3: 1998
• EMC – EU (Class B)
- EN 55022
- EN 55024
• EMC – ROW (Class B)
- C-Tick (Australia)
- VCCI (Japan)
- GOST (Russia)
- MIC (Korea)
- CQC (China)
Warranty
• 12 Months
Polycom Communicator Ships With:
• CX200 CX200 Desktop Phone base
• Handset
• 6 ft. handset curly cord
• Captive USB cable
• Quickstart Guide
• Warranty card
Part No. 3726-17861-001 Rev 01/23/09
