Specifications - Polycom SoundPoint IP 501 Specifications

Polycom SoundPoint IP 501*
Size
• 10.5 in x 6 in x 7.5 in x 1.75 in
(26.5 cm x 15 cm x 19 cm x 4.5 cm) (WxHxDxT)
Weight
• Shipping: 2.75 lb (1.26 kg)
Power
• Universal wall adapter with power provided to the
unused pairs of network cable. Optional cable for:
- Cisco® Inline Power
- IEEE 802.3af Inline Power
Headset Capability
• 4-position modular jack compatible with Plantronics®
and GN Netcom® amplified business headsets
Handset
• Hearing aid compatible
Display
• Grayscale graphical 160x80 pixel LCD
• Message alert indicator
Feature keys
• 12 dedicated feature keys
(3 keys with display indicators)
• 4 context-sensitive soft keys
• Predefined hold key
Audio
• Individual volume settings for each audio path with
visual display feedback
• Hands-free audio modes including headset and
full-duplex speakerphone
• Adaptive jitter buffers to improve speech quality
Networking
• Dual 10/100 Mbps switched Ethernet ports
Protocol and Feature Support
• Flexible software architecture allowing drop-in
signaling protocol stacks
• IETF MGCP v1.0 with feature phone extensions
- RFC3435
- Packet Cable Labs NCS IO7
- RFC3149 (Business Phone Packages)
- Configurable up to 3 lines -- - varies by IP PBX
or Softswitch solution
_______
* - The SoundPoint IP 501 is currently offered in North America,
Australia, and New Zealand only
** - Requires SIP version 1.5.x or higher
*** - Requires BootRom 3.0 or higher
Polycom Headquarters:
Polycom EMEA:
Polycom Asia Pacific:

Specifications

• IETF SIP (RFC 3261 and companion RFCs)
- Local feature-rich GUI
- Call transfer, hold, divert (forward)
- Called, calling, connected party
Identification/information
- One-touch speed dial, redial
- Local 3 way conferencing
- Simplified conference call handling**
- Up to 3 dedicated lines
- Flexible call appearance**
- Multiple line appearance**
- User configurable directories and call history
(Missed, placed and received)
- Presence: buddy list, my status
- Instant messaging
- Unicode character support
- Distinctive incoming call treatment/call waiting
- Do not disturb function
- Local call timer
- Multilingual user interface
- Automatic off-hook call placement
Security
- Digest authentication
- HTTPS secure provisioning**
- URL syntax for Boot Server address*** (RFC 1738)
- Support for ''signed'' software executables***
Codecs
• G.711 µ/A and G.729A (Annex B) configuration
• Manual or Dynamic Host Configuration Protocol
(DHCP) IP address setup
• Time and date synchronization using SNTP
• Server provisioned XML-based user configuration files
SoundPoint IP 501 includes:
• Desk stand
• 11-foot CAT 5 network cable with power port
• AC adapter
• Quick start guide
• Warranty registration card
Approvals
• CISPR 22 class B
• VCCI
• EMI
- FCC class B Part 15
- ICES-003 class B
- EN 55022 class B
Safety
• UL 1950
• CSA C22.2 No. 950
• EN 60950
Warranty
• 1 year
©2005 Polycom, Inc. All rights reserved.
Polycom, the Polycom logo and SoundPoint are registered trademarks of Polycom, Inc.
All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.
4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) +1.925.924.6000, (F) +1.925.924.6100
270 Bath Road, Slough, Berkshire SL1 4DX, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
Polycom Hong Kong Ltd., Rm 1101 MassMutual Tower, 38 Gloucester Road, Wanchai, Hong Kong, (T) +852.2861.3113, (F)+852.2866.8028
Part No. 0000-00000-000 Rev. 4/05
