:: Bag 2 :: Bag 2 - - Step 2 Step 2
91976
B6.4 FT Alum.
Chassis Weight,
11g
:: Bag 2 :: Bag 2 - - Step 3 Step 3
!
Do not discard these highligted
parts! You will install them in Step 6.
:: :: Bag 2 Bag 2 - - Step 4 Step 4
91997 x2 x2
Steering
Link, B6.4
4671
M3x10mm
Set Screw
!
Tighten the
steering link ball
cups all the way
until snug.
91734
Battery
Foam, B6
x4 x4
91749
M2 x 3mm
FHCS
#31500 - M3 x 2.5mm set screw. #31500 - M3 x 2.5mm set screw. #31500 - M3 x 2.5mm set screw.
31382
FT Ballstud
Washer, Aluminum
(1mm)
31531
M3 x 6mm
BHCS
23T: Sanwa/ KO/ JR / Spektrum
24T: Hitec
25T: Reedy/ Futaba/Savox /ProTek / MKS
91988
Battery
Foam, B6.4
71176
Side Rails
(L & R)
x4 x4
25202
M3 x 10mm
FHCS
71128 71128
Anti-Roll Bar, Anti-Roll Bar,
(1.3mm) (1.3mm)
!
Do not overtighten Do not overtighten
You could bend the bar!
Align the servo horn 90 degrees.
!
Use sub trim after build to
31284
8mm Ball
Stud, Long
M3 x 2.5mm
Set Screw
center steering.
91728
91728
Servo Horn
Servo
Ring
Horn
x7 x7
25201
M3 x 8mm
FHCS
31500
91821 91821
Anti-Roll Anti-Roll
Bar Collar Bar Collar
Servo not
included!
