Associated Electrics RC10 SC64 TEAM KIT Manual

Associated Electrics RC10 SC64 TEAM KIT Manual

1:10 scale 2wd electric off road competition short course kit
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the RC10 SC64 TEAM KIT and is the answer not in the manual?

Questions and answers

Related Manuals for Associated Electrics RC10 SC64 TEAM KIT

Summary of Contents for Associated Electrics RC10 SC64 TEAM KIT

  • Page 2 • FT Dual Turnbuckle Wrench (#1114) • Calipers or a Precision Ruler • Soldering Iron • Hobby Knife • Wire Cutters • Needle Nose Pliers Associated Electrics, Inc. Customer Service 21062 Bake Parkway. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
  • Page 3 :: Hardware - 1:1 Scale View :: Hardware - 1:1 Scale View Button Head (bhcs) Flat Head (fhcs) Ball Bearings 2x4mm (31510) 2x3mm (91749) 4x7x2.5mm (31732) 2.5x6mm (31520) 2.5x8mm (31448) 5x8x2.5mm (8680) 2.5x8mm (31521) 3x8mm (25201) 2.5x10mm (31522) 3x10mm (25202) 5x10x4mm (91560) 3x4mm (91158) 3x12mm (25203)
  • Page 4 Each part in the This symbol indicates a Racers Tip. foldout has a number assigned to it for ordering replacement parts. Associated Electrics, Inc. Customer Service 21062 Bake Parkway. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
  • Page 5 4/23 :: Bag 1 - Bag 1 - Step 1 Step 1 Front 31283 91973 5mm Ball Steering 31732 Stud, Long Bellcrank 4 x 7 x 2.5 Note orientation (Right) Ball Bearing of steering rack. 91973 Steering Bellcrank 91973 (Left) Steering Rack 31382...
  • Page 6 :: Bag 2 Bag 2 - - Step 2 Step 2 91988 91976 91734 Battery B6.4 FT Alum. Battery Foam, B6.4 Chassis Weight, Foam, B6 71176 Side Rails (L & R) 25202 25201 91749 M3 x 10mm M3 x 8mm M2 x 3mm FHCS FHCS...
  • Page 7 :: Bag 2 Bag 2 - - Step 5 Step 5 91885 Servo Mount 31531 Brace M3 x 6mm BHCS 91887 Servo Mount 41089 M3 x 6mm #91728 - Servo Spacers LP SHCS are not required for most servos. :: Bag 2 Bag 2 - - Step 6 Step 6 89219...
  • Page 8 :: Bag 2 - Bag 2 - Step 8 Step 8 25225 M3 x 3mm Set Screw 91821 Anti-Roll Bar Pivot The front hinge pin brace has a sharp edged side, and a 91820 rounded edge side. Front Anti- 91657 Mount the sharp 25225 Roll Bar Link...
  • Page 9 :: Bag 3 - Step 2 Bag 3 - Step 2 91901 91049 Use shorter Caster 25215 Heavy-duty screw in front! Block M3 Locknut, Ballstud, black 10mm 31531 M3 x 6mm 31520 BHCS 31532 M2.5 x 6mm M3 x 8mm BHCS BHCS You can install the kit...
  • Page 10 :: Bag 4 - Step 2 Bag 4 - Step 2 Arm Mount D: The (#91882) C and (#91883) D aluminum ° Out arm mounts allow for a large amount of setup combinations when using the (#92014) 0.5° and 1° arm mount inserts. For a complete list of pill setup combinations, see page 24, or visit our website by using the link below.
  • Page 11 :: Bag 5 - Step 3 Bag 5 - Step 3 6575 As you tighten the diff bolt, you will notice the T-nut ears moving closer to the bottom of the outdrive slot. This compresses the Locking spring behind the T-nut. The spring should be completely T-nut compressed at the time the T-nut reaches the end of the slot.
  • Page 12 :: Bag 6 - Step 2 Bag 6 - Step 2 91563 Diff Height 91791 10x15x4 Bearing B6.1 Laydown Add a drop of Diff Gearbox Top Setup Lube (#6591) to the teeth of the diff gear, idler gear, and top shaft. 91792 B6.1 Diff Height Insert...
  • Page 13 :: Bag 6 - Step 5 Bag 6 - Step 5 91801 25612 89202 Slipper Spring M3 Locknut, M3 x 12mm Adapter, Outer 91801 Flanged BHCS Slipper Spring Adapter, Inner 71148 91801 Rear Shock 92159 B6.1 Slipper Tower, SC6.2 Shock Spring Bushing, 10mm...
  • Page 14 :: Bag 7 - Step 1 31383 Rear Axle Height 91047 Ballstud Washers, Heavy-duty 5.5x2.0mm, blue +3mm Ballstud, 92267 Rear Hub +2mm 92180 Rear Hub Link Mounts +1mm 92179 Rear Hub 89202 Insert +0mm M3 x 12mm M3 x 12mm BHCS Setup Build x2 (right and left side)
  • Page 15 :: Bag 8 - Step 2 92308 92340 92308 Racers Tip: Ball Cup, Turnbuckle Ball Cup, 3.5mm 3.5x67mm 3.5mm Use black grease (#6588) on the threads of the turnbuckles for easier ball cup Stering Turnbuckle installation! 43.30mm Orient the notch to the left throughout the car.
  • Page 16 :: Bag 9 - Step 1 Bag 9 - Step 1 31510 31510 M2 x 4mm M2 x 4mm 91936 91938 BHCS BHCS FT 13mm FT 13mm Mount the shock Shock Piston, Shock Piston, pistons with the 89278 number facing up! 2mm [2x1.6] 2mm [2x1.8] 89278...
  • Page 17 :: Bag 9 - Step 4 Bag 9 - Step 4 91926 13mm 31510 Shock Cap M2 x 4mm Front Shock: 30wt BHCS #5422 Shock Bleeding Steps: Rear Shock: 30wt #5422 #5422 Before assembly, get each bleed screw and thread it 1-2 turns into the shock cap, then Stroke Stroke remove the screw.
  • Page 18 :: Bag 9 - Step 7 Bag 9 - Step 7 Use outside hole in front arm! 25612 M3 Locknut M3 Locknut w/Flange w/Flange 3 3 2 2 25188 M3 x 20mm BHCS Build x2 (right and left side) :: :: Bag 9 - Step 8 Bag 9 - Step 8 Make sure the flange on the...
  • Page 19 :: Bag 10 - Step 1 See page 25 for gear mesh setting instructions! Motor not included! Pinion & Setscrew not included! 31532 89218 M3 x 8mm 3 x 8mm BHCS Washer :: :: Bag 10 - Step 2 Bag 10 - Step 2 Receiver not Transponder ESC not...
  • Page 20 :: Bag 10 - Step 3 Bag 10 - Step 3 Fan not included! 91978 Fan Mount 89203 Fan mount options: M3 x 16mm #1 - Laydown gearbox BHCS #2 - Layback gearbox #3 - Endbell location #4 - Plug (no fan) 25201 M3 x 8mm FHCS...
  • Page 21 :: Bag 10 - Step 5 Bag 10 - Step 5 Front Front 91729 Thumb Screw, B6 :: Bag 10 - Step 6 - Optional Chassis Brace Configuration *NOT INCLUDED Bag 10 - Step 6 - Optional Chassis Brace Configuration *NOT INCLUDED 91885 91723 91885...
  • Page 22 :: Bag 10 - Step 7 Bag 10 - Step 7 Wheels, Tires, and Wheels, Tires, and Inserts are Inserts are not included! Carefully apply CA glue (tire adhesive) to the tire bead on the side. Do one side at a time, allowing it to dry before gluing the other side! CA glue not included!
  • Page 23 :: Notes Notes...

  • Page 24: Tips For Beginners

    :: Tuning Tips :: Tuning Tips Painting: Your Kit requires a clear polycarbonate body and polycarbonate specific paint. You will need to prep the body before you can paint it. Wash the INSIDE thoroughly with warm water and liquid detergent (do not use any detergents with scents or added hand lotion ingredients!).
  • Page 25 :: Tuning Tips (cont.) :: Tuning Tips (cont.) Motor Gearing: Proper motor gearing will result in maximum performance and run time while reducing the chance of overheating and premature motor failure. The gear ratio chart lists recommended starting gear ratios for the most widely used motor types.

This manual is also suitable for:

70009
