Associated Electrics RC10 SC64 TEAM KIT Manual page 3

3
:: Hardware - 1:1 Scale View :: Hardware - 1:1 Scale View
Button Head (bhcs)
2x4mm (31510)
2.5x6mm (31520)
2.5x8mm (31521)
2.5x10mm (31522)
3x4mm (91158)
3x5mm (31530)
3x6mm (31531)
3x8mm (31532)
3x10mm (25211)
3x12mm (89202)
3x14mm (25187)
3x16mm (89203)
3x18mm (2308)
3x20mm (25188)
3x22mm (25189)
3x24mm (89204)
3x30mm (91478)
Diff Balls
3/32 Carbide Diff Balls (6581) (kit)
3/32 Ceramic Diff Balls (6584)
Thrust Washer (91990)
Caged Thrust Washer (91990)
Notes:
Flat Head (fhcs)
Set Screws
Socket Head (shcs)
Shims and Washers
(FT Option)
2x3mm (91749)
2.5x8mm (31448)
3x8mm (25201)
3x10mm (25202)
3x12mm (25203)
3x14mm (89208)
3x16mm (25204)
3x18mm (89209)
3x2.5mm (31500)
3x3mm (25225)
3x5mm (89219)
3x10mm (4671)
3x20mm (91737)
1.6 x 5mm (91611)
3 x 18mm (25191)
3 x 6mm (41089)
3 x 22mm (41095)
5.5x0.5mm (31381)
5.5x1.0mm (31382)
5.5x2.0mm (31383)
2.6x6mm Washer (89278)
3x8mm Washer (89218)
Ball Bearings
4x7x2.5mm (31732)
5x8x2.5mm (8680)
5x10x4mm (91560)
5x12x4mm (91567)
10x15x4mm (91563)
Ballstuds
Silver 5mm long (31283)
Silver 8mm long (31284)
HD 6mm (91047)
Ti HD 6mm (91751)
HD 8mm (91048)
Ti HD 8mm (91752)
HD 10mm (91049)
Ti HD 10mm (91753)
Nuts (lock/plain)
M3 Plain Nut (91477)
M3 Alum. Locknut, Blue (31550)
M3 Locknut, Black (25215
M3 Locknut w/Flange (25612)
FT 3mm Locknuts, Blue(25392)
Serrated Steel (Silver)(91826)
FT Alum. Locknut (Blue) (25391)
Serrated Steel (Black) (91738)
Serrated Steel LP (Black) (91150)
M4 Nuts:
