- Page 1 WELDING INVERTER PEGAS 160 E Smart (FOD) PEGAS 200 E Smart (FOD) OPERATING MANUAL ALFA IN a.s. © www.alfain.eu PEGAS 160-200 E Smart FOD Manual EN 03...
-
Page 2: Table Of Contents
SAFETY INSTRUCTIONS AND WARNINGS ..........4 TECHNICAL DATA ..................6 EQUIPMENT ....................8 OPERATOR CONTROLS ................9 GETTING STARTED ................. 10 ROUTINE MAINTENANCE & INSPECTION ..........11 STATEMENT OF WARRANTY ..............12 DISPOSAL ....................13 10. WARRANTY LIST ..................13 ALFA IN a.s. © www.alfain.eu... -
Page 3: Introduction
3/13 1. INTRODUCTION Congratulations on your new ALFA IN product. We are proud to have you as our customer and will strive to provide you with the best service and reliability in the industry. This Operating Manual has been designed to instruct you on the correct use and operation of your ALFA IN product. -
Page 4: Safety Instructions And Warnings
The operator must be aware of all the special regulations which he needs to conform to when welding in enclosed spaces with a high risk of explosion. To prevent electric shock, we strongly suggest the following rules: ALFA IN a.s. © www.alfain.eu... - Page 5 Only personnel authorised by this company can carry out maintenance on the machine. NOTE: Device complies with IEC 61000-3-12. Working ambient temperature between -10 and +40 °C. Relative humidity below 90% at +20 °C. Up to 3000 m altitude. ALFA IN a.s. © www.alfain.eu...
-
Page 6: Technical Data
During operation, the device may be the source of interference. Caution We warn users, that they are responsible for possible interference from welding. 3. TECHNICAL DATA PEGAS 160 E smart (FOD) Method Mains voltage V/Hz 1x230/50-60 Welding current range... - Page 7 25 A. Attention! Do not connect to the interconnected voltage (delta voltage) (between 2 phases)! Replacement of the plug may only be performed by ALFA IN authorized service personnel. ALFA IN continuously strives to produce the best product possible and therefore reserves the right to change, improve or revise the specifications or design of this or any product without prior notice.
-
Page 8: Equipment
VM0253 50 160A 5.0178 Box black 50x58,5x18 cm Pressure Reducer 6124 BASECONTROL Ar 2 manometers Pressure Reducer 6125 BASECONTROL CO2 2 manometers 706.1037 Torch SRT 17 4m V 35-50 Welding Helmet Barracuda S777c. S777C Black ALFA IN a.s. © www.alfain.eu... -
Page 9: Operator Controls
5. OPERATOR CONTROLS Fig . 1 Main parts Pos. Description LED ON Method switch MMA (electrode)/TIG Current potentiometer LED over heating Panel quick connector (-) Panel quick connector (+) Mains socket with a plug ON/OFF switch ALFA IN a.s. © www.alfain.eu... -
Page 10: Getting Started
2. Connect the work lead to positive terminal 6 and fasten it by turning the connector to the right. 3. Connect the work clamp to the work piece or at the welding table. 4. By means of the switch 2 select TIG ALFA IN a.s. © www.alfain.eu... -
Page 11: Routine Maintenance & Inspection
5. To clean the welder, disconnect it from the mains supply voltage then open the enclosure and use a vacuum cleaner to remove any accumulated dirt and dust. The welder should also be wiped clean. If necessary, solvents that are recommended for cleaning electrical apparatus may be used. ALFA IN a.s. © www.alfain.eu... -
Page 12: Statement Of Warranty
3. ALFA IN will repair or replace, at its discretion, any warranted parts or components that fail due to defects in material or workmanship within the warranty period. -
Page 13: Disposal
As a warranty list serves proof of purchase (invoice) on which is the serial number of the machine, eventually a warranty list below, which is filled in by an authorized dealer. Serial number: Day, month (written in words) and year of sale: Stamp and dealer signature: ALFA IN a.s. © www.alfain.eu...
