- Page 1 INSTALLATION INSTRUCTIONS VOLT LOW VOLTAGE LANDSCAPE LIGHTING ® VOLT® Cast Brass Deck Light ITEM: VDL-600 & VDL-6000 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- Page 2 INSTALLATION INSTRUCTIONS VOLT® Cast Brass Deck Light VDL-600 & VDL-6000 IMPORTANT: PLEASE READ BEFORE INSTALLATION This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 PACKAGE CONTENTS A. (1) Luminaire B. (2) Lock Screws Product Dimensions 2” 3 3/8” 2 1/4” Pro Technique for Hiding Lead Wire Determine the location for the fixture. Drill a hole straight through the desired mounting location and run the lead wire out the backside of the location so that the wires are not visible from the front side.
- Page 4 INSTALLATION INSTRUCTIONS VOLT® Cast Brass Deck Light VDL-600 & VDL-6000 Remove Lens Assembly Rotate the lens assembly counter Base clockwise until it is stops and then lift the lens assembly straight off. Note: The first time it may be difficult because the luminaire has a tight o-ring seal and a grease sealant for moisture protection.
- Page 5 Install Bulb Insert the bulb with correct wattage and type marked on the luminaire label. CAUTION: Do not exceed maximum Bulb wattage marked on luminaire label. NOTE: DO NOT touch bulb with bare hands. Use soft cloth to handle bulb. Socket Install Lens Assembly Push the lens assembly back onto the...
- Page 6 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2023, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • www.voltlighting.com...
