Product Manual 26547V1
(Revision G, 1/2021)
Original Instructions
MicroNet™ Safety Module
Fault Tolerant Protection System
Manual 26547 consists of 2 volumes (26547V1 & 26547V2)
Volume 1 - Installation and Operation
