Released
easYgen-800
Technical Manual
Genset Control
easYgen-800
Version 3.0.1.3
Document ID: B37691A, Revision D - Build 51671

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the easYgen-100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Woodward easYgen-100 Series

Summary of Contents for Woodward easYgen-100 Series

  • Page 1 Released easYgen-800 Technical Manual Genset Control easYgen-800 Version 3.0.1.3 Document ID: B37691A, Revision D - Build 51671...
  • Page 2 Designed in Germany and Poland; manufactured in China. Woodward GmbH Handwerkstr. 29 70565 Stuttgart Germany Telephone: +49 (0) 711 789 54‑510 Fax: +49 (0) 711 789 54‑101 E-mail: stgt-info@woodward.com Internet: http://www.woodward.com © 2021 Woodward GmbH. All rights reserved. easYgen-800 B37691A...
  • Page 3 Released Brief Overview Brief Overview Fig. 1: easYgen-800 Terminals 1 to 22: Power supply, relays, discrete inputs, MPU, D+, ... Terminals 23 to 26: CAN (J1939) Terminals 33 to 35: RS-485 interface USB service port for PC/laptop with ToolKit-SC Terminals 62 to 64: RS-232 interface ETHERNET interface connector (RJ-45) Terminals 56 to 61: Analog inputs Terminals 49 to 55 (screwable): Generator and Ground current, discrete input 8...
  • Page 4 • Clamp fastener installation material (4x) • • »Installation Procedure Supplement« paper with links to the latest edition of • Technical Documentation and software for download: (http://wwdmanuals.com/easYgen-800) Configuration software and Technical Manual are available at Woodward website: http://wwdmanuals.com/easYgen-800 easYgen-800 B37691A...
  • Page 5 Released Brief Overview Sample application setup Fig. 2: Sample application setup A typical application mode for the control unit is the use for non parallel operation in a single genset application. • In this case, the easYgen will function as an engine control with generator and •...
  • Page 6 Released Brief Overview Transition procedures are described in chapter ╚═▷ “5.4 Transition Procedures”. easYgen-800 B37691A...

  • Page 7: Table Of Contents

    Released Table of Contents Table of Contents General Information ............11█...
  • Page 8 Released Table of Contents 4.1.3.2 Manage Configuration Data ............40█...
  • Page 9 4.4.3.1 IKD 1 I/O Expansion Board for Woodward Controllers ........
  • Page 10 Released Table of Contents Data Telegrams ..............121█...

  • Page 11: General Information

    • • Response button command “SMS ACK” for GSM text added; • • Support of woodward IKD1 and IKD2 added, each module with 8 • inputs and 8 outputs. • The arrow down button addded as the lamp test button.
  • Page 12 Released 1 General Information 1.1.1 Revision History Rev. Date Editor Changes ◦ easYgen-800/1800 sensor data fluctuation after repower on. ◦ Technical Manual • In • ╚═▷ “3.2 Wiring”: ◦ terminal ratings and descriptions updated in ◦ ╚═▷ Table ◦ corrections in ◦...

  • Page 13: Symbols Used In This Manual

    Released 1 General Information 1.1.2 Symbols Used in this manual 1.1.2 Symbols Used in this manual Safety instructions Safety instructions are marked with symbols. The safety instructions are always introduced by signal words that express the severity of the danger. DANGER! This combination of symbol and signal word indicates an immediately dangerous situation that can cause death or severe injuries if not avoided.

  • Page 14: Copyright And Disclaimer

    All information and instructions in this manual have been provided under due consideration of applicable guidelines and regulations, the current and known state of the art, as well as our many years of in-house experience. Woodward assumes no liability for any damages due to: •...

  • Page 15: Service And Warranty

    In addition, our employees are interested in any new information and experiences that arise from usage and could be valuable for improving our products. Warranty terms Please enquire about the terms of warranty from your nearest Woodward representative. To find your closest Customer Service representative, go to: ══▷ http:// www.woodward.com/Directory.aspx Safety 1.4.1...

  • Page 16: Personnel

    Released 1 General Information 1.4.2 Personnel NOTICE! Damage due to improper use! Improper use of the remote panel unit may cause damage to the control unit as well as to the connected components. Improper use includes, but is not limited to: •...
  • Page 17 Released 1 General Information 1.4.3 General hazard warnings Prime mover safety WARNING! Hazards due to insufficient prime mover protection The engine, turbine, or any other type of prime mover must be equipped with an overspeed (over-temperature, or over-pressure, where applicable) shutdown device(s) that operates independently of the prime mover control device(s) to protect from runaway or damage to the engine, turbine, or any other type of prime mover.

  • Page 18: System Overview

    For even higher challenges in genset control, the easYgen series offers further solutions encompassing complex and ambitious applications. For dedicated protection tasks, ask Woodward for its protection (relay) solutions. Operation Modes • See •...

  • Page 19: Features And Functions Of Both Easygen-800 And -1800

    Released 2 System Overview 2.2 Features and Functions of both easYgen-800 and -1800 Fig. 3: easYgen-800 Features and Functions of both easYgen-800 and -1800 Both easYgen-800 and easYgen-1800 are very close in hardware and software. The easYgen-1800 is the device with more/higher functionality. For comparison and better differentiation both are described below.
  • Page 20 Released 2 System Overview 2.2 Features and Functions of both easYgen-800 and -1800 Item easYgen-800 easYgen-1800 RS485 ● ● Ethernet ● ● ● ● J1939 ● ● ● ● Micro SD card (slot) ● ● Real-time clock ● ● Event log ●...
  • Page 21 Released 2 System Overview 2.2 Features and Functions of both easYgen-800 and -1800 • easYgen-1800 only: For Mains, controller has over and under voltage, over and • under frequency, loss of phase and phase sequence wrong detection functions • For generator, controller has over and under voltage, over and under frequency, loss •...

  • Page 22: Functions

    Released 2 System Overview 2.3 Functions • Accumulation of total run time and total electric energy of A and B. Users can reset it • for convenience. Functions • Protection: automatic start/stop of the genset, ATS (Auto Transfer Switch) control •...
  • Page 23 Released 2 System Overview 2.4 Intended Use of This Control be set using PC (via USB port) and can be adjusted and monitored with the help of RS-485 port. It can be widely used in a number of automatic genset control system with compact structure, simple connections and high reliability.

  • Page 24: Installation

    Released 3 Installation 3.1 Mounting Installation Mounting Fix the controller unit using the included clips. Please see below for the overall dimensions of the controller and the cutout dimensions of the panel. Tighten the clips (tightening torque 0.3 Nm [2.65 lb⋅in]) in order to achieve the IP65 degree of protection.
  • Page 25 Released 3 Installation 3.2 Wiring Speed Sensor Input Use 2-core shielded wires. Connect the shielding layer to terminal 16 while the other side is not connected. Connect the two signal wires to terminals 17 and 18. The output voltage of speed sensor should be between 1 to 24 V .
  • Page 26 Released 3 Installation 3.2 Wiring Use min. 90°C copper conductors only. Field wiring terminals marking: Shall be marked with AWG wire range and terminal torque rating. Installed in accordance with the NEC (United States) or the CEC (Canada). Current sense inputs shall be marked: “From Listed or R/C (XODW2.8) current transformers”.
  • Page 27 Released 3 Installation 3.2 Wiring Function Cable Remarks Size Relay is supplied by terminal 3, rated 2 Adc 24 Vdc, inductive (according to UL6200) STARTER 1.5 mm² Rated 10Adc, 24Vdc running stand alone, rated 5Adc, 24Vdc when running in parallel with the FUEL/GAS relay Relay is supplied by terminal 3, rated 2 Adc 24 Vdc, inductive (according to...
  • Page 28 Released 3 Installation 3.2 Wiring Function Cable Remarks Size ([PARAMETER / MPU − Connected to speed sensor. A Configure connection between MPU− and B− is application / provided internally. Configure engine / Configure start/ MPU + Connected to speed sensor. stop]) must be disabled: ╚═▷...
  • Page 29 Released 3 Installation 3.2 Wiring Function Cable Remarks Size 41 .. not connected GENERATOR VOLTAGE AC 1.0 mm² Connected to A-phase of genset (2 A fuse is recommended) 1.0 mm² Connected to B-phase of genset (2 A fuse is recommended) 1.0 mm²...
  • Page 30 Released 3 Installation 3.2 Wiring Wiring typical applications Fig. 6: easYgen-800 wiring of a typical application easYgen-800 B37691A...

  • Page 31: Interfaces

    Released 3 Installation 3.3 Interfaces Interfaces Interface Connections Fig. 7: Interface Connections Interfaces Intended use Remarks RS-232 For serial communication For details, ╚═▷ “8 RS-485 For Remote Control via Modbus Technical Specifications” J1939 Engine communication J1939 and others Configuration tool »ToolKit-SC« access only! Ethernet For Ethernet network communication Micro SD card (slot)

  • Page 32: Micro Sd Card Slot

    Released 3 Installation 3.4 Micro SD Card Slot Name Description Transceiver Data- Receive Data+ Not connected Not connected Receive Data- Not connected Not connected There are two plug-integrated LEDs: Color Function Description Green Activity The LED is flashing when there is activity on the link;...

  • Page 33: Install Toolkit-Sc

    General notes ToolKit-SC is a software tool for configuration including configuration file management, monitoring, remote control, and custom language management. The ToolKit-SC.exe file is available as a download on the Woodward website and the device-specific download website. Please follow installation instruction.

  • Page 34: Configuration

    • The configuration software ToolKit-SC is part of the delivery and (latest edition) can be downloaded from our website Woodward.com. Search for "ToolKit-SC". Different Discrete Inputs can NOT use one and the same Input Type; otherwise, there are abnormal functions! E.g.: Contents Setting of Flexible Input Port 4 is Input Type #5 "Lamp test".
  • Page 35 Released 4 Configuration 4.1.1 Front Panel: Operating and Display Elements Fig. 8: easYgen-800 Icons Keys Description STOP Auto/Manual mode: Stop running generator Stop mode: Reset alarm Lamp test (press at least 3 seconds) Notes During stopping process, press this button again to stop generator immediately.
  • Page 36 WARNING! Users can change passwords. Please make note of the new password after changing it. If you forget the password, please contact Woodward services and send all device information on the “ABOUT” page of the controller for legitimation. easYgen-800...

  • Page 37: Front Panel Control

    Released 4 Configuration 4.1.2 Front Panel Control 4.1.2 Front Panel Control General Notes Buttons below the screen/display have specific functions that are described in ╚═▷ “5 Operation”. The configuration via front panel is limited to the current code level and restricted due to the editing/input possibilities of different buttons.
  • Page 38 Released 4 Configuration 4.1.2.1 HMI Screens Without Password Level • Generator • • Load • • Alarm • • Event log • • Others • • About • • Home screen etc. • »Home« screen includes: • Gen: voltage, frequency, current, active power, reactive power •...
  • Page 39 Released 4 Configuration 4.1.2.1 HMI Screens Without Password Level Fig. 9: Power Factor Active power Reactive power Power factor Conditions Active power Reactive Remark power COS>0L P>0, Q>0 Positive Positive Positive inductive load COS>0C P>0, Q<0 Positive Negative Positive capacitive load COS<0L P<0, Q>0 Negative...

  • Page 40: Configure Toolkit-Sc

    Released 4 Configuration 4.1.3 Configure ToolKit-SC »Others« screen includes: • Time and Date • • count down time for maintenance • • input/output ports status • »About« screen includes: • Issue time of software and hardware version • • product PD number •...

  • Page 41: Configure Customized Language

    Released 4 Configuration 4.1.3.3 Configure Customized Language Refresh config! A configuration update between ToolKit-SC and the device (and vice versa) requires pushing the button »Read config« or »Write config«! 4.1.3.3 Configure Customized Language General notes ToolKit-SC can display English, Chinese, or Traditional Chinese. These languages can be selected from the »Language«...

  • Page 42: Access Via Toolkit-Sc Configuration Tool

    Released 4 Configuration 4.1.4 Access via ToolKit-SC Configuration Tool 4.1.4 Access via ToolKit-SC Configuration Tool ToolKit-SC Screen Overview Fig. 11: ToolKit-SC home screen ⚙ 1. ▷ Open ToolKit-SC on your computer. ToolKit-SC is installed and connection between your computer and the easYgen device is established The ToolKit-SC home screen (see above) displays.

  • Page 43: Parameters

    Released 4 Configuration 4.2 Parameters ▶ Fig. 12: ToolKit-SC: write configuration The settings are transmitted to the device and immediately become active. Parameters 4.2.1 Parameter Menu Structure Parameter Menu Parameters of both HMI (front panel access) and ToolKit-SC are not presented in the same order.
  • Page 44 Released 4 Configuration 4.2.1 Parameter Menu Structure Fig. 13: Menu Structure easYgen-800 - overview easYgen-800 B37691A...

  • Page 45: Parameter Settings Menu--Hmi Access

    Released 4 Configuration 4.2.2 Parameter Settings Menu--HMI Access 4.2.2 Parameter Settings Menu--HMI Access ⚙ 1. ▷ Press and hold the ENTER button for more than three seconds ▶ The main menu opens Select »Configure« 2. ▷ Enter a password for the parameter settings screen 3. ▷...
  • Page 46 Released 4 Configuration 4.2.3 Configure Measurement Items Parameters Defaults Description 2: 2 Phase, 3 The measurement is performed Line-Line. Wire (2P3W) VL12, VL23 and VL31 3: Single Phase, 2 2 Phase, 3 Wire (2P3W) Wire (1P2W) The measurement is performed Line-Neutral and Line-Line: VL12 VL1N and VL2N Single Phase, 2 Wire (1P2W)

  • Page 47: Configure Application

    Released 4 Configuration 4.2.4 Configure Application Items Parameters Defaults Description Gnd. CT primary rated (5 to 6000)/5 500/5 Primary value from the used ground current transformer current (CT) 4.2.4 Configure Application 4.2.4.1 Configure Inputs and Outputs 4.2.4.1.1 Configure Discrete Inputs Configure Discrete Inputs [PARAMETER / Configure application / Configure discrete inputs] Fig.
  • Page 48 Released 4 Configuration 4.2.4.1.2 Configure Discrete Outputs Items Parameters Defaults Description (Adjust to logic) Close to activate Close to Close to activate (N.O.): The discrete input is analyzed Activate as "enabled" by energizing the input (normally open). Open to activate Open to activate (N.C.): The discrete input is analyzed as "enabled"...
  • Page 49 Released 4 Configuration 4.2.4.1.2.2 Configure Relay Outputs Items Parameters Defaults Description output remark, Preheat)) (Adjust to logic) Output (N.O.) Output Select according to logic of the connected signal (normally (N.O.) open or normally connected) Output (N.C.) (Map Programmable 00 to 299 Default of discrete output 1 Output) Engine...
  • Page 50 Released 4 Configuration 4.2.4.1.2.3 Configure Custom Sequences & Combinations Items Parameters Defaults Description Default of discrete output 6 Centralized alarm Notes See chapter ╚═▷ “4.3.3 Programmable Outputs” for details 4.2.4.1.2.3 Configure Custom Sequences & Combinations General note easYgen offers customer programmable logic "inside". Two setting types are available and described below: •...
  • Page 51 Released 4 Configuration 4.2.4.1.2.3.2 Logic flags 1 to 6 The result is available as Programmable Output »Engine flag {X}«; see chapter ╚═▷ “4.3.3 Programmable Outputs”). If both S1-Delay and S1-Duration are "0", S1 is always TRUE. 4.2.4.1.2.3.2 L ogic flags 1 to 6 Fig.
  • Page 52 Released 4 Configuration 4.2.4.1.3 Configure Analog Inputs Items Parameters Defaults Description Temperature Type 00 to 15 07 SGX See chapter ╚═▷ “4.3.1 Programmable Sensors” If a type (01 or Curve can be Notes higher) with curve loaded ... For temperature curve management and is selected: customization.
  • Page 53 Released 4 Configuration 4.2.4.1.3 Configure Analog Inputs Items Parameters Defaults Description Engine heater Enabled / dis‐ Disabled Notes control abled Selectable only for Analog Input 02 »enabled«: The following related settings will be taken into account -50 to 300 ºC 50 ºC Release the alarm when sensor value is same (-122...
  • Page 54 Released 4 Configuration 4.2.4.1.3 Configure Analog Inputs Items Parameters Defaults Description »enabled«: The following related settings will be taken into account Limit 0 to 1000 kPa 124 kPa Release the alarm when sensor value is same (17.98 or lower than this value and Delay time is over psi, 1.24 bar) Return...
  • Page 55 Released 4 Configuration 4.2.4.1.3 Configure Analog Inputs Items Parameters Defaults Description Fuel pump control Enabled / dis‐ Disabled Notes abled »enabled«: The following related settings will be taken into account 0 to 300 % 10 % Release the alarm when sensor value is same or lower than this value and Delay time is over 0 to 300 % 80 %...
  • Page 56 Released 4 Configuration 4.2.4.1.3 Configure Analog Inputs Items Parameters Defaults Description ... and/or edited (curve) Wire break alarm Warn Warn Alarm type to be released if wire break is detected Shutdown None Enabled if a sensor type is selected: Notes * is filled with the related values and units (temperature, pressure, level) High limit warning...
  • Page 57 Released 4 Configuration 4.2.4.1.4 Configure External Analog Inputs (Ext. AIN24) Items Parameters Defaults Description Pressure Select local pressure unit for display Temperature °C °C Select local temperature unit for display °F 4.2.4.1.4 Configure External Analog Inputs (Ext. AIN24) [PARAMETER / Configure application / Configure inputs/outputs / Configure external inputs / Configure external analog inputs] Items Parameters...
  • Page 58 Released 4 Configuration 4.2.4.1.4 Configure External Analog Inputs (Ext. AIN24) Items Parameters Defaults Description Fuel Level Sensor With selection of the sensor type, all limit warnings and shutdowns below are related to the according range, default value and units; marked with "*" Description Text field for 20 ((empty))
  • Page 59 Released 4 Configuration 4.2.4.1.5 Configure External Discrete Inputs Items Parameters Defaults Description Delay 0 to 3600 The alarm status change must be valid for this period of time before it is released 4.2.4.1.5 Configure External Discrete Inputs [PARAMETER / Configure application / Configure inputs/outputs / Configure external inputs / Configure external inputs / Configure ext.
  • Page 60 Released 4 Configuration 4.2.4.1.6 Configure External Discrete Outputs Items Parameters Defaults Description (Release condition) From Safety On Never Condition "switch" of releasing the input signal From Starting Always Never Input delay 0.0 to 20.0 s 2.0 s The input status must be valid for this period of time before it is released (Description) Text field for 20...
  • Page 61 Released 4 Configuration 4.2.4.1.7 Configure external LEDs 1 Fig. 22: ToolKit-SC: Configure external LEDs Items Parameters Defaults Description Ext. LED enable enabled/disabled disabled Notes All 16 external outputs are enabled/disabled together. »enabled«: The following related settings will be taken into account.
  • Page 62 Released 4 Configuration 4.2.4.1.8 Configure external LEDs 2 Label print Once the configuration of external LEDs is complete, the corresponding LED labels can be printed on paper by means of the “Label print” button in . The following screen opens: Fig.

  • Page 63: Configure Engine

    Released 4 Configuration 4.2.4.2 Configure Engine For description of the available options, settings and the parameter configuration, see ╚═▷ “4.2.4.1.7 Configure external LEDs 1”. 4.2.4.2 Configure Engine [PARAMETER / Configure application / Configure engine] Items Parameters Defaults Description Engine Type Engine type 00 to 39 00 Con‐...
  • Page 64 Released 4 Configuration 4.2.4.2 Configure Engine Items Parameters Defaults Description Start pause time 3 to 60 s 10 s The waiting time before second power up when engine start failed Engine monitoring 0 to 3600 s 10 s Alarms for low oil pressure, high temperature, delay time under speed, under frequency /voltage, charge fail are inactive.

  • Page 65: Configure Test Run

    Released 4 Configuration 4.2.4.3 Configure TEST Run Items Parameters Defaults Description Oil Pressure enabled / dis‐ enabled abled 0 to 1000 kPa 200 kPa When generator oil pressure higher than the set value, starter will be disconnected. See the installation instruction. NOTICE! Disable "Firing speed RPM"...

  • Page 66: Configure Breakers

    Released 4 Configuration 4.2.4.4 Configure Breakers Items Parameters Defaults Description Daily Time (Day) 1 to 31 »Monthly«: Select a week day Sunday, to Sunday »Weekly«: Select a week day Saturday Time (hour) 0 to 24 h 0 (o'clock) Define the start time (hour) Time (minute) 0 to 59 Define the start time (minute)

  • Page 67: 4.2.5.1 Monitoring Generator

    Released 4 Configuration 4.2.5.1 Monitoring Generator Items Parameters Defaults Description Delay 0 to 3600 s The alarm status change must be valid for this period of time before it is released Overvoltage enabled/disabled enabled Notes shutdown »enabled«: The following related settings will be taken into account Limit 0 to 200 %...
  • Page 68 Released 4 Configuration 4.2.5.1 Monitoring Generator Items Parameters Defaults Description Underfrequency enabled/disabled enabled Notes warning »enabled«: The following related settings will be taken into account Limit 0 to 200 % 84 % Release the alarm when sensor value is same or lower than (42.0 Hz) this value and Delay time is over Return...
  • Page 69 Released 4 Configuration 4.2.5.1 Monitoring Generator Items Parameters Defaults Description Generator current enabled/disabled enabled Notes alarm »enabled«: The following related settings will be taken into account Limit 0 to 200 % 120 % Release the alarm when sensor value is same or higher (600 A) than this value and Delay time is over Action...

  • Page 70: Monitoring Breakers

    Released 4 Configuration 4.2.5.2 Monitoring Breakers Items Parameters Defaults Description Delay 0 to 3600 s The alarm status change must be valid for this period of time before it is released Overload enabled/disabled disabled Notes »enabled«: The following related settings will be taken into account Action Warn...
  • Page 71 Released 4 Configuration 4.2.5.3 Monitoring Engine Items Parameters Defaults Description Loading speed 0 to 100 % 90 % In AUTO mode the GCB closes if the actual engine speed is (1350 r/ higher than the configured loading speed. This function is min) only used if the MPU input is used.

  • Page 72: Can Interface

    Released 4 Configuration 4.2.5.4 CAN Interface Items Parameters Defaults Description Action Warn Warn Shutdown Monitoring Start/Stop [PARAMETER / Configure monitoring / Engine / Start/Stop] Items Parameters Defaults Description Shutdown malfunction Shutdown malfunction 0 to 3600 s Time between ending of genset idle delay and stopped delay when “Stop solenoid Hold”...

  • Page 73: Configure Interfaces

    Released 4 Configuration 4.2.6 Configure Interfaces Items Parameters Defaults Description Limit 0 to 200 % 120 % Release the alarm when sensor value is same or higher (28.8 V) than this value and Delay time is over Return 0 to 200 % 115 % Cancel the alarm when sensor value is same or lower than (27.6 V)

  • Page 74: Configure Gsm Module

    Released 4 Configuration 4.2.6.1 Configure GSM Module Items Parameters Defaults Description »enabled«: The following related settings will be taken into account IP address XXX.XXX.XXX.XXX 192.168.0.144 Subnet mask XXX.XXX.XXX.XXX 255.255.255.0 Gateway XXX.XXX.XXX.XXX 192.168.0.1 Gateway XXX.XXX.XXX.XXX 192.168.0.1 MAC address XX-XX-XX-XX-XX- 25-25-25-25-25-25 SD card Enable SD card enabled/disabled disabled...
  • Page 75 Released 4 Configuration 4.2.6.1.2 GSM Short Message Remote Control International area code must be added. E.g. USA 001... »SMS orders« must be typed-in in the form described below e.g. all letters must be capital! If an easYgen model does not support an information or detail, value will be empty. The following »SMS Orders«...

  • Page 76: Configure Ethernet Interface

    Released 4 Configuration 4.2.6.2 Configure Ethernet Interface 4.2.6.2 Configure Ethernet Interface General Notes The Ethernet Interface is used for controller monitoring and has two connection modes: • Network Client mode • • Web Server mode • Change of controller's network parameters (e.g. IP address, sub network mask) take effect only after controller restart.

  • Page 77: Configure Maintenance

    Released 4 Configuration 4.2.7 Configure Maintenance The IP address must be in the same network segment as the IP address of monitoring equipment (e.g. PC). Example: Monitoring equipment IP address is 192.168.50.144, controller IP can be 192.168.50.146, sub network mask (for both) is 255.255.255.0 2. ▷...
  • Page 78 Released 4 Configuration 4.2.7 Configure Maintenance Fig. 25: Schedule Maintenance Items Parameters Defaults Description Notes For Maintenance {x} = 1 to 3: Maintenance {x} enabled/disabled disabled Notes »enabled«: The following related settings will be taken into account Description Text field for 20 ((empty)) Customer specific sensor name letters...

  • Page 79: Configure Counters

    Released 4 Configuration 4.2.8 Configure Counters Items Parameters Defaults Description Indication 4.2.8 Configure Counters [PARAMETER / Configure counters] Items Parameters Defaults Description Engine running hours Time 0 to 65534 hours 0 hours Preset value 0 to 59 min 0 min Preset value Set (push button) PUSH: Preset time is written to the connected easYgen...

  • Page 80: Configure Switchable Parameter Set

    Released 4 Configuration 4.2.9 Configure Switchable Parameter Set Items Parameters Defaults Description Total start times Total number of starts 0 to 9999999.9 0.0 kW Electric energy consumed Set (push button) PUSH: Preset kW value is written to the connected easYgen Total B Time 0 to 65534 hours...

  • Page 81: Configure Language / Clock

    Released 4 Configuration 4.2.10 Configure Language / Clock Items Parameters Defaults Description Engine rated speed 0 to 6000 r/min 1500 r/min 4.2.10 Configure Language / Clock [PARAMETER / Configure language / clock] Items Parameters Defaults Description Language Simplified English With "Other" the customer specific (loaded) language (file) Chinese will be used for HMI display.

  • Page 82: Configure Hmi

    Released 4 Configuration 4.2.12 Configure HMI Items Parameters Defaults Description Auto mode 4.2.12 Configure HMI [PARAMETER / Configure HMI] Items Parameters Defaults Description Mute buzzer enabled/disabled disabled Disabled: No acoustic signal with alarm/warning Activate status bar color enabled/disabled disabled HMI only: Use a contrast background color of information line area at the bottom of the display? Set display color...
  • Page 83 Released 4 Configuration 4.3.1 Programmable Sensors Sensor Description Remark 5 VOLVO-EC 6 DATCON 7 SGX 8 SGD 9 SGH 10 PT100 11 SUSUKI 12 PRO 13 to 15 Reserved Pressure Sensor 0 Not used Defined resistance range is (0 to 6) KΩ. 1 Custom Res Curve Default is »7 SGX sensor«.

  • Page 84: Programmable Inputs

    Released 4 Configuration 4.3.2 Programmable Inputs Sensor Description Remark 4 SGH 5 to 15 Reserved Configuration/Setting When reselecting sensors, the sensor curve will be transferred to the standard value. For example, if a temperature sensor is SGX (120°C resistor type), its sensor curve is SGX (120°C resistor type);...
  • Page 85 Released 4 Configuration 4.3.2 Programmable Inputs Alarm type description NO shutdown Release Condition Description Never input inactive Always input is active all the time From crank detecting from start From safety on detecting after safety on run delay Type Description User defined This type offers the following sub selections: •...
  • Page 86 Released 4 Configuration 4.3.2 Programmable Inputs Type Description Override shutdown alarms All shutdown alarms are prohibited except emergence stop.(Means battle mode or override mode) Annunciator mode All outputs are prohibited in this mode Reset Maintenance 1 Controller will set maintenance time and date 1 as default when input is active Reset Maintenance 2 Controller will set maintenance time and date 2 as default when input is active Reset Maintenance 3...

  • Page 87: Programmable Outputs

    Released 4 Configuration 4.3.3 Programmable Outputs Type Description Switchable rating 1 Alternative configuration is active when the input is active. Users can set different parameters to make it easy to select current configuration via input Switchable rating 2 port. Switchable rating 3 Gas leakage shutdown Connect with detection module warn input port Raise speed (ECU)
  • Page 88 Released 4 Configuration 4.3.3 Programmable Outputs Type Description Pre-lubrication Actions in period of pre-heating to safety run Remote control bit This port is controlled by communication (PC) GSM power enable Power for GSM module (GSM module is reset when GSM communication failed) Open CB Opening a breaker is requested Close GCB...
  • Page 89 Released 4 Configuration 4.3.3 Programmable Outputs Type Description Reserved Reserved Reserved ECU warning alarm Indicate ECU sends a warning signal ECU shutdown alarm Indicate ECU sends a shutdown signal ECU communication failure Indicate controller not communicates with ECU Reserved Reserved Reserved Reserved Reserved...
  • Page 90 Released 4 Configuration 4.3.3 Programmable Outputs Type Description Reserved Emergency Stop Action when emergency stop alarm Start fail Action when failed start alarm Engine stop malfunction Action when failed stop alarm Underspeed warning Action when under speed alarm Underspeed shutdown Action when under speed shuts down Overspeed warning Action when over speed warns...

  • Page 91: Status Menu

    Released 4 Configuration 4.4 Status Menu Type Description Reserved Fuel level low warning Action when controller has low oil level alarm Reserved Reserved Analog input 4 High limit Status message warning Analog input 4 Low limit Status message warning Analog input 4 High limit Status message shutdown Analog input 4 Low limit...

  • Page 92: Toolkit-Sc Status Screens

    Released 4 Configuration 4.4.2 ToolKit-SC Status Screens • Alarm • • Log • • Others • • About • • ... and the home screen • in a loop 4.4.2 ToolKit-SC Status Screens General notes ToolKit-SC enables dedicated access to status information summarized into the following screens: Fig.
  • Page 93 Released 4 Configuration 4.4.2 ToolKit-SC Status Screens Items Parameters Description Status and delay Gen status, Breaker status, Remote start Alarms Display of current alarms and warnings Digital inputs 1 start request in AUTO, 2 High temperature, 3 Low oil pressure, 4 User defined, 5 User-defined, 6 User-defined, 7 Lamp test, 8 User defined, Emergency stop Accumulation...
  • Page 94 Released 4 Configuration 4.4.2 ToolKit-SC Status Screens Items Parameters Description SD card Status, Total capacity, Remain capacity Earth fault current Percent Next maintenance time Maintenance 1 to 3 Event Log and Version [PARAMETER / STATUS MENU / Event log and version] Items Parameters Description...

  • Page 95: Configure For Using Accessories

    Configure For Using Accessories For configuration see ╚═▷ “4.2 Parameters”. 4.4.3.1 IKD 1 I/O Expansion Board for Woodward Controllers General notes Fig. 27: IKD 1 The IKD 1 is an I/O expansion board, which enables connection of eight discrete inputs and eight relay outputs via CAN bus.
  • Page 96 Released 4 Configuration 4.4.3.1 IKD 1 I/O Expansion Board for Woodward Controllers Parameter Contents Dimensions 168 mm x 128 mm x 51mm Ambient working conditions Temperature： -40 to 85 °C Humidity： 95 %, non-condensing Sealing IP20 Weight Ca. 0.36 kg...

  • Page 97: Operation

    Released 5 Operation Operation • • Front Panel: Operating and Display Elements: See ╚═▷ “4.1.1 Front Panel: Operating and Display Elements” Warning/Alarm Signaling The Alarm type and Warning are visualized through flashing of the LED lights »Alarm« and »Warning« located beside the display. Alarm Indicator LED Warning Indicator LED Alarm Type...

  • Page 98: Operation Modes

    Released 5 Operation 5.2 Operation Modes Acknowledge alarm The alarm reset is done with additional (2 time) pressing the mute/acknowledge button (Alarm LED is no longer flashing). Operation Modes General notes The easYgen offers three operation modes: • AUTO • •...

  • Page 99: Operation Mode Stop

    Released 5 Operation 5.2.3 Operation Mode STOP CAUTION! MANual breaker open/close request can destroy the genset. Take care for genset and supply. 5.2.3 Operation Mode STOP General notes In operation mode STOP, the breaker is open and the engine is not running. This is a configurable operation mode, only.

  • Page 100: Stop Engine

    Released 5 Operation 5.3.2 Stop engine Fig. 28: Engine start procedure 5.3.2 Stop engine The AUTO Stop procedure is going through sub procedures with own timers. easYgen-800 B37691A...
  • Page 101 Released 5 Operation 5.3.2 Stop engine The remaining time of each of the timers initiated is shown in the display. When started via “Remote Stop (off Load)” input, start procedures is the same as described below but breaker open relay is deactivated. Fig.

  • Page 102: Manual Start/Stop

    Released 5 Operation 5.3.3 MANual START/STOP 5.3.3 MANual START/STOP Engine control is separated from breaker management. Breaker(s) must be manually opened/closed (supply should be in normal range). MANual Start ⚙ 1. ▷ Press the MAN button ▶ The LED next to the button will illuminate to confirm the operation 2. ▷...
  • Page 103 Released 5 Operation 5.4.1 Disconnect during cranking If the speed sensor (»Firing speed RPM«) is not selected, the rotating speed displayed on the controller is calculated from generator frequency and the number of poles. If the generator frequency (»Firing speed Hz«) is not selected, the relative power quantity will neither be registrated nor displayed (e.g.

  • Page 104: Commissioning

    (if idle run be set). During this time, please watch for engine’s running situations and AC generator’s voltage and frequency. If abnormal, stop genset running and check all wires connection according to this manual If there is any other question, please contact your local Woodward support 7. ▷ easYgen-800...

  • Page 105: Interfaces And Protocols

    Released 7 Interfaces and Protocols 7.1 J1939 Interfaces and Protocols J1939 Cummins ISB/ISBE Terminals of Connector B Remark controller Fuel relay output Start relay output Connect with starter coil directly Auxiliary output port Expand 30A relay, ECU power Set Auxiliary output 1 as “ECU power” battery voltage of 01, 07, 12, 13 is supplied by relay...
  • Page 106 Released 7 Interfaces and Protocols 7.1 J1939 Cummins QSX15-CM570 Terminals of 50 pins connector Remark controller Fuel relay output Oil spout switch Start relay output Connect to starter coil directly Terminals of controller 9 pins connector Remark CAN GND SAE J1939 shield-E CAN communication shielding line(connect with ECU terminal only) CAN(H) SAE J1939 signal-C...
  • Page 107 Released 7 Interfaces and Protocols 7.1 J1939 Terminals of OEM connector of Remark controller engine CAN(H) Impedance 120 Ω connecting line is recommended. CAN(L) Impedance 120 Ω connecting line is recommended. Detroit Diesel DDEC III-IV / Common J1939 Terminals of CAN port of engine Remark controller...
  • Page 108 Released 7 Interfaces and Protocols 7.1 J1939 MTU ADEC (Smart Module) / ECU8 Terminals of ADEC (X1port) Remark controller Fuel relay output X1 10 X1 Terminal 9 Connected to negative of battery Start relay output X1 34 X1 Terminal 33 Connected to negative of battery Terminals of controller SMART (X4 port) Remark...
  • Page 109 Released 7 Interfaces and Protocols 7.1 J1939 Terminals of “Data bus” Remark controller connector CAN GND CAN communication shielding line(connect with controller’s terminal only) CAN(H) Impedance 120 Ω connecting line is recommended. CAN(L) Impedance 120 Ω connecting line is recommended. Volvo EDC4 / TD520, TAD520 (optional), TD720, TAD720 (optional), TAD721, TAD722, and TAD732 Terminals of...
  • Page 110 Released 7 Interfaces and Protocols 7.1 J1939 Terminals of Engine 42 pins port Remark controller CAN GND CAN communication shielding line(connect with controller’s this terminal only) CAN(H) 1,35 Impedance 120 Ω connecting line is recommended. CAN(L) 1,34 Impedance 120 Ω connecting line is recommended. Battery Engine 2 pins Remark...

  • Page 111: Technical Specifications

    Released 8 Technical Specifications Technical Specifications Ambient Items Contents Power Supply Operating Voltage 8.0 V to 35.0 V , Continuous Power Supply. Reverse polarity protected Maximum supply Short Time 80 V (5-10 s) voltage Long Time 50 V Minimum supply 6.5 V voltage Maximum operating...
  • Page 112 Released 8 Technical Specifications Items Contents Maximum frequency Generator: 99.5 Hz Frequency resolution 0.1 Hz (10 .. 99 Hz) Frequency accuracy ±0.1 Hz Nominal CT secondary rating Overload Max.: 10 A Measurement Current Accuracy Alternator Frequency 50 Hz/60 Hz Case Dimension 237 mm ×...
  • Page 113 Released 8 Technical Specifications Items Contents Fuel Relay Output Rated 10 Adc, 24 Vdc running stand alone, rated 5 Adc, 24 Vdc when running in parallel with the STARTER relay Rated 2 Adc 24 Vdc, inductive (according to UL 6200) Auxiliary Relay Output (1 ..

  • Page 114: Measuring And Monitoring

    Released 8 Technical Specifications 8.1 Measuring and Monitoring Display • 480 × 272 TFT LCD with backlight, multilingual interface (including English, Chinese • or other languages) which can be chosen at the site, making commissioning convenient for factory personnel • LCD wear-resistance and scratch resistance due to hard screen acrylic; •...
  • Page 115 Released 8 Technical Specifications 8.1 Measuring and Monitoring • Frequency Hz • • For generator, controller has over and under voltage, over and under frequency, loss • of phase, phase sequence wrong, over and reverse power, over current functions Load •...

  • Page 116: Appendix

    Released 9 Appendix 9.1 Alarms and Warnings Appendix Alarms and Warnings 9.1.1 Alarm Classes Alarm class Visible in the LED and horn Open GCB Shut-down Engine blocked display engine until acknowledge Warn This alarm does not interrupt the operation of the unit. An output of the centralized alarm occurs and the “Horn”...
  • Page 117 Released 9 Appendix 9.1.2 Warnings Type Description Charge alternator low When the controller detects that charger voltage has fallen below the pre-set voltage value, it will initiate a warning alarm. Battery undervoltage When the controller detects that start battery voltage has fallen below the pre- set value, it will initiate a warning alarm.

  • Page 118: Shutdown Alarms

    Released 9 Appendix 9.1.3 Shutdown Alarms Type Description GSM Communication fail When select GSM enable but the controller couldn’t detect GSM model, controller sends corresponding warning signal. Ground fault If earth fault detection is enabled, the controller will initiate a shutdown alarm it it detects that the earth fault current has exceeded the pre-set value and the selected action is “Warn”, it will initiate a warning alarm.

  • Page 119: Trip And Stop Alarms

    Released 9 Appendix 9.1.4 Trip and Stop Alarms Type Description Low oil pressure When the controller detects that the oil pressure has fallen below the pre-set value, it will initiate a shutdown alarm. Level sensor wire break When the controller detects that the level sensor is open circuit and the action select “Shutdown”, it will initiate a shutdown alarm.

  • Page 120: Trip Alarms

    Released 9 Appendix 9.1.5 Trip Alarms Type Description Ground fault If earth fault detection is enabled, the controller it will initiate a trip and stop alarm if it detects that the earth fault current has exceeded the pre-set value and the action select “Trip and Stop”. 9.1.5 Trip Alarms On initiation of the trip condition the controller will de-energize the ‘Close Generator’...

  • Page 121: Data Telegrams

    Released 9 Appendix 9.3 Data Telegrams Symptoms Possible Solutions Check if the connections from the controller to the engine and the output ports settings are correct. ECU warning or shutdown Get information from the LCD of the alarm page; If there is a detailed alarm, check the respective engine.

  • Page 122: Modbus Communication Protocol

    Released 9 Appendix 9.3.1.2 Modbus Communication Protocol 9.3.1.2 Modbus Communication Protocol When communication command is sent to the slave, corresponding slave receives the communication command, then removes address code, and read the information. If no mistakes, it will execute commands, and sends the result back to the master. Response information includes address code, function code, data and error check code (CRC).
  • Page 123 Released 9 Appendix 9.3.1.6 Data Field code, data field and the CRC code. The data of data field is in double bytes with every two bytes for a group, and high byte is in advance. 05_hex Force Single Coil Master uses this command to save a single coil data into bit registers in the device (such as ATS transfer control).

  • Page 124: Error Check Code (Crc)

    Released 9 Appendix 9.3.1.7 Error Check Code (CRC) Function # 06 (06_hex) – Preset Single Register Request: Data sequence Data signification Register address Register value (2-byte) Byte count Response: Data sequence Data signification Register address Register value (2-byte) Byte count 9.3.1.7 Error Check Code (CRC) The Error Check Code allows the receiving device to detect a packet that has been...
  • Page 125 Released 9 Appendix 9.3.1.7 Error Check Code (CRC) 3. ▷ (If the LSB was 0): Repeat Step 3 (another shift). (If the LSB was 1): Exclusive OR the CRC register with the polynomial value A001 hex (1010 0000 0000 0001). 4. ▷ Repeat Steps 3 and 4 until 8 shifts have been performed.
  • Page 126 Released 9 Appendix 9.3.1.7 Error Check Code (CRC) Example: Read 3 holding registers @ Function Code 03_hex (slave address ☼ 01_hex, starting address 0026_hex) Address Data(Hex) 0026_hex 0027_hex 0028_hex Request Bytes Example (Hex) Slave address 01 Send to the slave 01 Function code 03 Read Holding Registers Starting address...
  • Page 127 Released 9 Appendix 9.3.1.7 Error Check Code (CRC) Example: Read coil @ Function Code 05_hex (slave address 01_hex, starting ☼ address 0002_hex is addressed as 1.) Address Data(Hex) 0000 0001 0002 Request Bytes Example (Hex) Slave address 01 Send to the slave 01 Function code 05 Force Single Coli Starting address...

  • Page 128: Error Handling

    Released 9 Appendix 9.3.1.8 Error Handling Example: Preset register as 0002_hex @ Function Code 06_hex (slave address ☼ 01_hex, starting address 00E3_hex) Request Bytes Example (Hex) Slave address 01 Send to the slave 01 Function code 06 Preset Single Register Starting address 00 Starting address is 00E3_hex...

  • Page 129: Read Holding Registers 03_Hex

    Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address code 1 byte Error code 1 byte CRC code 2 bytes illegal function code The function code received in the query is NO allowed slave action illegal data address The data address received in the query is NO allowed slave address illegal data value A value contained in the query data field is NO allowed slave value 9.3.2...
  • Page 130 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved (MSB) 1bit Emergency Stop 1 for active 1bit Over Speed 1 for active 1bit Under Speed 1 for active 1bit Loss of Speed Signal 1 for active 1bit Over Frequency 1 for active...
  • Page 131 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Flexible Sensor 1 1 for active 1bit Open Flexible Sensor 1 1 for active 1bit High Flexible Sensor 1 Low 1 for active 1bit Reserved 1bit Flexible Sensor 2 1 for active...
  • Page 132 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit...
  • Page 133 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Aux Input 1 Shutdown 1 for active 1bit Aux Input 2 Shutdown 1 for active 1bit Aux Input 3 Shutdown 1 for active 1bit Aux Input 4 Shutdown 1 for active...
  • Page 134 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Expansion Switch 1 for active 1bit Input Com Fail Expansion Switch 1 for active 1bit Output Com Fail Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit...
  • Page 135 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Input 3 ELE Trip 1 for active 1bit Input 4 ELE Trip 1 for active 1bit Input 5 ELE Trip 1 for active 1bit Input 6 ELE Trip 1 for active 1bit Input 7 ELE Trip...
  • Page 136 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit...
  • Page 137 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit...
  • Page 138 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Loss of Exciting 1 for active 1bit Earth Fault 1 for active 1bit Negative Seq Current 1 for active 1bit Reserved...
  • Page 139 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Breaker Warn 1 for active 1bit Temp Sensor Open 1 for active 1bit Warn High Temp Warn 1 for active 1bit Low Temp Warn 1 for active 1bit Reserved 1bit...
  • Page 140 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit...
  • Page 141 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit...
  • Page 142 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Aux Input 1 Warn 1 for active 1bit Aux Input 2 Warn...
  • Page 143 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1bit Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Emergency Stop 1 for active 1bit Input Status Digital Input 1 Status 1 for active 1bit...
  • Page 144 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Expansion Switch 1, 1 for active 1bit Input 8 Expansion Switch 2, 1 for active 1bit Input 1 Expansion Switch 2, 1 for active 1bit Input 2 Expansion Switch 2, 1 for active 1bit...
  • Page 145 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Expansion Switch 1, 1 for active 1bit Output 3 Expansion Switch 1, 1 for active 1bit Output 4 Expansion Switch 1, 1 for active 1bit Output 5 Expansion Switch 1, 1 for active 1bit...
  • Page 146 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 1bit Reserved 1bit Reserved 1bit Reserved 1 for active 1bit Reserved 1 for active 1bit Reserved 1 for active 1bit Reserved 1 for active 1bit Reserved 1 for active 1bit Reserved...
  • Page 147 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes...
  • Page 148 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved Signed (*10) 2Bytes Reserved Signed (*10) 2Bytes Reserved Signed (*10) 2Bytes Reserved Signed (*10) 2Bytes Reserved Signed (*10) 2Bytes Reserved Signed (*10) 2Bytes Reserved Signed (*10) 2Bytes Reserved 2Bytes...
  • Page 149 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Engine Speed 2Bytes Battery Voltage (*0.1) 2Bytes Charger Voltage (*10) 2Bytes...
  • Page 150 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Fuel Temperature 2Bytes Inlet Temperature 2Bytes Exhaust Temperature 2Bytes Turbo Pressure 2Bytes Fuel Consumption 2Bytes Total Fuel 4Bytes Consumption Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved...
  • Page 151 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count 0203 Accumulated Energy 4Bytes 0204 0205 Accumulated Energy 4Bytes 0206 kVarh 0207 Accumulated Energy 4Bytes 0208 kVAh 0209 Reserved 4Bytes 0210 Maintenance Remain 2Bytes Time (HH) Maintenance Remain 2Bytes Time (MM) Maintenance Remain...
  • Page 152 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes...
  • Page 153 Released 9 Appendix 9.3.2 Read Holding Registers 03_hex Address Items Description Bytes Count Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes Reserved 2Bytes...

  • Page 154: Force Single Coil 05H_Hex

    Released 9 Appendix 9.3.3 Force Single Coil 05H_hex Address Items Description Bytes Count Reserved 2Bytes 9.3.3 Force Single Coil 05H_hex If an easYgen model does not support an information or detail, value will be empty. Address Item Description Remote Start Key 1 for active Remote Stop Key 1 for active...

  • Page 155: Preset Single Register 06H_Hex

    Released 9 Appendix 9.3.4 Preset Single Register 06H_hex Address Item Description Reserved 1 for active 9.3.4 Preset Single Register 06H_hex 9.3.4.1 Generator Status If an easYgen model does not support an information or detail, value will be empty. Items Description At Rest This status has no ―delay value Pre-heating...

  • Page 156: Breaker Status

    Released 9 Appendix 9.3.4.3 Breaker Status 9.3.4.3 Breaker Status If an easYgen model does not support an information or detail, value will be empty. Items Description Load Off This status has no ―delay value Reserved Gen Closed This status has no ―delay value Opening Transfer Rest Reserved...

  • Page 157: Glossary And List Of Abbreviations

    Released 10 Glossary and List of Abbreviations Glossary and List of Abbreviations Circuit Breaker Current Transformer Discrete Input Discrete (Relay) Output Engine Control Unit Failure Mode Indicator Generator Circuit Breaker (speed) Governor; rpm regulator Human Machine Interface e.g., a front panel with display and buttons for interaction Current Mains Circuit Breaker...

  • Page 158: Index

    Released Index Index Alarms  Classes .............. 116█...
  • Page 159 Released Index Mounting .............. 24█...
  • Page 160 Released Woodward GmbH Handwerkstraße 29 — 70565 Stuttgart — Germany Phone +49 (0) 711 789 54-510 +49 (0) 711 789 54-101 stgt-info@woodward.com...

This manual is also suitable for:

Easygen-800Easygen-1800Easygen-100Easygen-400Easygen-6008440-2250 ... Show all

Table of Contents
