Summary of Contents for Planar Dome E2

  • Page 1 Dome EX Displays Quick Reference Windows XP Windows 2000...
  • Page 2: Before You Begin

    Enabling this function can improve video performance on the board by 100% or more. The results: faster image loads, increased window and level speed, and enhanced system performance. For more information, visit www.planar.com. System Requirements • PCI slot per board (64-bit recommended) •...
  • Page 3: Unpacking The Display

    Unpacking the Display Check the contents of your Dome EX display package for all the items shown here. Save the original packaging materials for storage and shipping. Dome EX digital fl at panel Power block DVI-to-DVI video cable Display controller Dome EX and Dome CXtra quick references Power cord...
  • Page 4 Setting DIP Switch S2 If you are installing the DX2 display controller, you will need to set DIP switch S2 for your system confi guration. Slide switch 1 into the ON position to enable VGA mode. Enable VGA on only one (1) board when you install multiple boards.
  • Page 5: Installing The Display Controller

    Installing the Display Controller Before you install the DX2 or AX5 display controller, turn your computer off . Leave the power cord plugged into the grounded outlet. To install the controller 1 Turn off all peripherals. Disconnect all cables from the back of your computer. 2 Remove the computer cover.
  • Page 6: Connecting The Display

    Connecting the Display Use only the cable and power cord supplied with the Dome EX display. To connect the display 1 Press the PUSH button on the desk stand and remove the stand cover. 2 Plug one end of the DVI cable into the DVI connector port.
  • Page 7 1 Log on with administrator priviledges. 2 Right-click the desktop. Select Properties > Settings. 3 Select the display icon. 4 Select Extend my Windows desktop onto this monitor. Click Apply. 5 Click OK. To change the display properties Use the Dome tab to change display properties after the Dome EX display is...
  • Page 8 1 Log on with administrator priviledges. 2 Right-click the desktop. Select Properties > Settings. 3 Select the Plug and Play Monitor on Dome DX2/PCI Properties from the Display list. 4 Select Extend my Windows desktop onto this monitor. Click Apply.
  • Page 9 4 Click Yes to the license agreement. The installation starts. 5 Follow the onscreen instructions to complete the installation. Planar recommends that you select the Express installation option. 6 When the Setup complete message appears, select Yes, I want to restart my computer now and click Finish.
  • Page 10 Display Resolutions and Palette Options Display Resolution Dome E2 1200 x 1600 1600 x 1200 1200 x 1600 1600 x 1200 Dome E3 1536 x 2048 2048 x 1536 3072 x 2048* 4096 x 1536 1536 x 2048 2048 x 1536...
  • Page 11: Cleaning The Lcd Screen

    Cleaning the LCD Screen Do not spray or use acetone, toluene, or harsh solvents on the display case or screen. Chemical cleansers may cause damage to the display. Use a dry, clean, lint-free cotton cloth to remove surface dust from the display screen. Do not use chemically treated dust cloths.
  • Page 12 Download the full version of the Dome EX User’s Guide and the latest driver from the Planar web site. © 2006 Planar Systems, Inc. Planar, Dome, Dome CXtra, and RightLight are registered trademarks of Planar Systems, Inc. Technical information in this document is subject to change without notice.

This manual is also suitable for:

Dome exDome e3Dome e3cDome e5
