No. Displayed message
EEPROM parameter initialized
W84
after software update
EEPROM parameters lost!
W85
Please check settings!
All I•STICK parameters are lost!
W86
Please check your settings.
Parameter in the I•STICK
W87
initialized! Please check settings
Parameters lost in the I-Stick!
Please check settings
W88
E89 Monitoring voltage F1, F2
E90 Monitoring voltage F1, F2
W91 P_ext smaller than p_A
W92 DUT evacuation takes too long
Filling the DUT with the tracer
W93
gas takes too long.
10-8
Warnings and malfunction messages
Description and possible remedy of cause
Missing or changed parameter in the EEPROM and new software version number
determined.
A software update has been performed and one or more new parameters
determined. The message can be acknowledged in this case. The parameter(s) is
(are) automatically added.
Defective or missing parameters in the EEPROM. The software version number
has not changed.
If the warning is re-activated after reconnection, the EEPROM on the wiring level
can not be written or is defective. EEPROM on wiring level defective!
The write access has been interrupted. Check the settings and acknowledge the
error message.
I•STICK on wiring level is empty and has been initialized with default values. All
customer parameters must be re-entered or determined.
I•STICK not connected.
I•STICK does not contain any values.
I•STICK is defective!
Missing or changed parameter in the I•STICK and new software version number
determined.
A software update has been performed and one or more new parameters
determined. The message can be acknowledged in this case. The parameter(s) is
(are) automatically added.
Defective or missing parameters in the I•STICK. The software version number has
not changed.
If the warning is re-activated after reconnection, the I•STICK on the wiring level
cannot be written or is defective. I•STICK on wiring level defective!
The write access has been interrupted. Check the settings and acknowledge the
error message.
Voltage monitoring for fuses F1, F2 AD 24 B < 5.6 V.
Fuse F1 interface card (SSK) defective.
Voltage monitoring for fuses F1, F2 AD 24 B < 7.8 V.
Fuse F2 interface card (SSK) defective.
Pressure in the DUT falls below the value of p_A, although only the test chamber
was pumped
DUT grossly leaking.
Adaption DUT leaking.
Incorrect setting for p_A.
Time t1 > as the set evacuation time t_A.
Valve V30 does not open.
Backing pump defective.
DUT leaking.
Incorrect time setting for t_A.
Incorrect setting for the evacuation pressure p_B.
Time t1> as the predetermined DUT filling time t_C.
Valve tracer gas inlet V33 does not open.
Time for tracer gas inlet t_C too small.
Trace gas p_C selected too high.
