Huskvarna, 2018-03-12
Safety and Operating Instructions
Dear customer,
thank you for choosing a Husqvarna quality product. We hope that you will genuinely enjoy it.
Please note that the enclosed manual contains Atlas Copco references.
The Husqvarna Group is vouching for the quality of this product.
If you have any questions, please do not hesitate to contact Discount-equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LG 400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Atlas Copco LG 400

Summary of Contents for Atlas Copco LG 400

  • Page 1 Dear customer, thank you for choosing a Husqvarna quality product. We hope that you will genuinely enjoy it. Please note that the enclosed manual contains Atlas Copco references. The Husqvarna Group is vouching for the quality of this product. If you have any questions, please do not hesitate to contact Discount-equipment.
  • Page 2 We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic, Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti, Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S.
  • Page 3 Safety and operating instructions Forward and reversible plate © 2015 Construction Tools EOOD | No. 9800 1109 01a | 2015-02-19 Original instructions...

  • Page 4: Table Of Contents

    LG 400 Contents Contents Introduction............... . 5 About the Safety and operating instructions.
  • Page 5 Contents LG 400 When taking a break............24 Parking, electric start.

  • Page 6: Introduction

    Safety and operating instructions Introduction Thank you for choosing a product from Atlas Copco. Since 1873, we have been committed to finding new and better ways of fulfilling our customers' needs. Through the years, we have developed innovative and ergonomic product designs that have helped customers improve and rationalize their daily work.

  • Page 7: Safety Instructions

    Safety and operating instructions LG 400 Appropriate work overall or similar clothing (not ● Safety instructions loose-fitting) that covers your arms and legs. To reduce the risk of serious injury or death to Drugs, alcohol or medication yourself or others, read and understand the Safety...
  • Page 8 LG 400 Safety and operating instructions Release the filler cap slowly to let pressure ► WARNING Dust and fume hazard escape. Dusts and/or fumes generated or dispersed when using the machine may cause serious and permanent ► Never overfill the fuel tank.
  • Page 9 Safety and operating instructions LG 400 Avoid eating, drinking, and using tobacco products ► WARNING Projectiles in areas where there is dust or fumes. Failure of the work piece, of accessories, or even of the machine itself may generate high velocity ►...
  • Page 10 LG 400 Safety and operating instructions WARNING Vibration hazards WARNING Trapping hazard Normal and proper use of the machine exposes the There is a risk of neck ware, hair, gloves, and clothes operator to vibration. Regular and frequent exposure getting dragged into or caught by rotating machine to vibration may cause, contribute to, or aggravate parts.

  • Page 11: Transport, Precautions

    Never modify the machine. Modified machines are ► not covered by warranty or product liability. ► Always use original parts and accessories approved by Atlas Copco. Change damaged parts immediately. ► Replace worn components in good time. ► WARNING Hot oil hazard When changing the oil, oil filter or hydraulic oil on a hot machine, there is a risk of burns.

  • Page 12: Overview

    LG 400 Safety and operating instructions Cylinder head cover Overview To reduce the risk of serious injury or death to yourself or others, read the Safety instructions section found on the previous pages of this manual before operating the machine.

  • Page 13: Labels

    New labels can be ordered from the spare parts list. HONDA Throttle control Shock absorber Atlas Copco Construction Tools AB 105 23 Stockholm, Sweden Type Operating mass kg Rated power kW Year of Mfg...

  • Page 14: Data Plate

    LG 400 Safety and operating instructions Data plate Safety label Construction Tools EOOD Type Operating mass kg Rated power kW Year of Mfg Product Identification Number Made in xxxxxxxx The handle must be locked during transportation. 3382 0102 00 Safety label...

  • Page 15: Biological Hydraulic Oil Label

    Safety and operating instructions LG 400 Biological hydraulic oil label Transport Lifting the machine WARNING Lifting hazard Never lift the machine without checking if it is intact. A damaged machine can fall apart, which can result Use ear protectors label in serious injury.

  • Page 16: Secure Transport

    LG 400 Safety and operating instructions Filling procedure Secure transport 1. Stop the engine and let it cool down before filling Secure the machine for all transportation. the tank. ♦ Place lashing straps (A) in a U-shape around the bottom plate and secure both front and rear.

  • Page 17: Operating On Slopes

    Safety and operating instructions LG 400 Never work on slopes that exceed the capabilities ♦ of the machine. The maximum slope of the machine in operation is 20° (depending on the condition of the ground). 20° Operating on slopes WARNING Slope hazards During operation, secure the machine so it can not ♦...

  • Page 18: Before Starting, Honda

    LG 400 Safety and operating instructions 1. Check the engine oil level. Before starting, Honda Follow the general safety precautions supplied with the machine at delivery. We recommend to study the engine manual supplied with the machine. Check that maintenance routines have been carried out.

  • Page 19: Starting The Engine, Honda

    Safety and operating instructions LG 400 4. Turn the start switch (D) to ON. Starting the engine, Honda 1. Open the fuel cock (A). 5. Grip the handle of the recoil starter (E) and pull until resistance is felt. Release the handle to the 2.
  • Page 20 LG 400 Safety and operating instructions 7. Allow the engine to idle a few minutes before increasing to full power (G). © 2015 Construction Tools EOOD | No. 9800 1109 01a | 2015-02-19 Original instructions...

  • Page 21: Starting The Engine, Lombardini Electric Start

    Safety and operating instructions LG 400 2. Turn the ignition key (C) to ignition position I. The Starting the engine, Lombardini electric start control lamps for charging and oil pressure light 1. Move the throttle control handle to idling position.

  • Page 22: Control Box, Electrical System

    LG 400 Safety and operating instructions 6. Increase to full power by moving the throttle Control box, electrical system control to position (D). For non EPA throttle control: Operating lamp, lights when engine is running. For EPA throttle control: Charging lamp, lights if there are charging problems.

  • Page 23: Stopping The Engine, Honda

    Safety and operating instructions LG 400 Stopping the engine, Honda Stopping the engine, Lombardini electric start 1. Move the throttle control to idling position (A). Let the engine idle for a few minutes. 1. Move the throttle control to idling position.

  • Page 24: Operating

    LG 400 Safety and operating instructions 2. Allow the engine to idle for a few minutes. Operating 3. Move the throttle control to the stop position (C). For non EPA throttle control: DANGER Handle hazard When changing the locking position, the handle must be held, otherwise it can cause injuries.

  • Page 25: Packing Indicator Ci (Option)

    Safety and operating instructions LG 400 Packing indicator CI (Option) NOTICE Operating with constant red indication (LED D) does not improve the compaction. Instead, such operation can be damaging for the machine. (Yellow) indicates a degree of compaction between 0 and 30%.

  • Page 26: Maintenance

    LG 400 Safety and operating instructions Inspect the machine before starting. Inspect the ♦ Maintenance entire machine so that leakages or other faults are detected. Regular maintenance is a basic requirement for the continued safe and efficient use of the machine.

  • Page 27: Checking The Engine, Honda

    Safety and operating instructions LG 400 Checking the engine, Honda Checking the engine, Lombardini ♦ Check the oil level on the dipstick. 1. Check the oil level on the dipstick (A). ♦ Check the fuel level (A). 2. Check the fuel level (B).

  • Page 28: Checking The Controls, Lombardini

    LG 400 Safety and operating instructions Checking the controls, Lombardini Checking the safety straps 1. Check that the throttle control (A) is not damaged ♦ Check the safety straps on the front and back of and does not jam. the machine. Replace if they are damaged.

  • Page 29: Changing The Engine Oil And Filter, Lombardini

    Safety and operating instructions LG 400 1. Unscrew the drain plug (A) for the oil and drain 1. Open the oil drain valve (A) and drain the oil into off all the oil. Use a draining hose (B). a container using a draining hose (B).

  • Page 30: Checking The V-Belt

    LG 400 Safety and operating instructions Clean the silencer spark catcher. See the engine ♦ Checking spark plug, Honda manual for more information. ♦ Check, clean and replace the spark plug. CAUTION Cover the V-belt Running a machine without the protective cover over the V-belt may cause trapping or machine damage, which can cause injury.

  • Page 31: Checking Bolted Joint

    Safety and operating instructions LG 400 Change the engine oil. See the engine manual for ♦ Hydraulic system, checking the hydraulic oil more information. level 1. Check the hydraulic oil level by using the dipstick Clean the engine's cooling flanges.

  • Page 32: Hydraulic System, Changing The Hydraulic Oil

    LG 400 Safety and operating instructions Hydraulic system, changing the hydraulic Changing the oil in the eccentric element 1. Drain the oil from the eccentric element by loosen the filler plug (A). 1. Remove the dipstick (A). 2. Use an oil suction pipe to empty the hydraulic oil from the tank.

  • Page 33: Disposal

    Safety and operating instructions LG 400 Disposal A used machine must be treated and disposed of in such a way that the greatest possible portion of the material can be recycled and any negative influence on the environment is kept as low as possible, and in accordance with local restrictions.

  • Page 34: Technical Data

    LG 400 Safety and operating instructions Technical data Machine data LG 400 Honda Lombardini Engine Type Honda GX 390, 4-stroke, Manual start Lombardini 15 LD440, 4-stroke Power, kW (hp) 7.7 (10.5) 6.4 (8.7) Rated speed, r.p.m. 3,100 3,100 Performance Operating speed, m/min (feet/min)

  • Page 35: Noise And Vibration Data

    Type at operator's ear dB(A) rel 1pW dB(A) rel 1pW hours/day LG 400 Honda LG 400 Lombardini Permitted working hours per day are calculated on action value of 2.5 m/s as per 2002/44/EC. Uncertainties, sound value Uncertainties, sound value...

  • Page 36: Dimensions

    LG 400 Safety and operating instructions Dimensions mm (in.) *Contact area, m (sq feet). © 2015 Construction Tools EOOD | No. 9800 1109 01a | 2015-02-19 Original instructions...

  • Page 37: Ec Declaration Of Conformity
