Printed Matter No. 9836 9710 01
Publication Date 2022-11-14
Valid from Serial No. A7780001
LSV48 SA085-NPT
(8500 r/min)
(8500 rpm)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
LSV48 SA085
8423070751
WARNING
Product Instructions
Sander NPT
Advertisement
Table of Contents
Related Manuals for Atlas Copco LSV48 SA085
Summary of Contents for Atlas Copco LSV48 SA085
- Page 1 LSV48 SA085 Printed Matter No. 9836 9710 01 Sander NPT Publication Date 2022-11-14 Valid from Serial No. A7780001 Product Instructions LSV48 SA085-NPT 8423070751 (8500 r/min) (8500 rpm) WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Maintenance and service instructions .......... 12 Service recommendations .............. 12 Replacement of vanes................. 12 Lubrication instructions ................... 12 Rust protection and cleaning ............... 12 Lubrication ................... 12 Lubricating guide ................. 13 Dismantling/Assembling instructions .............. 14 Instructions for vane motor .............. 14 © Atlas Copco Industrial Technique AB - 9836 9710 01... - Page 3 Recycling ....................... 15 Recycling instruction.................. 15 Recycling information .................. 15 © Atlas Copco Industrial Technique AB - 9836 9710 01...
-
Page 4: Product Information
■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions. -
Page 5: Website
You can find information concerning our products, accessories, spare parts and published matters on our website. Safety Data Sheets MSDS/SDS The safety data sheets describes chemical products sold by Atlas Copco. For more information, consult the website: www.atlascopco.com/sds Country of origin Please refer to the information on the product label. -
Page 6: Service Overview
If the product is not working properly, take it out of service and inspect it. If no detailed information about preventive maintenance is included, follow these general guidelines: ■ Clean appropriate parts accurately ■ Replace any defective or worn parts © Atlas Copco Industrial Technique AB - 9836 9710 01... -
Page 7: Installation
Air quality ■ For optimum performance and maximum product life we recommend the use of compressed air with a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration type air dryer. ■ Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of liquid water. -
Page 8: Visual Inspection - Air Installation
Look for any damage that can compromise the safety of the tool. Installation of vibrating tools We recommend using a minimum length of 300 mm (12") of flexible hose for compressed air between a vi- brating tool and the quick-action coupling. © Atlas Copco Industrial Technique AB - 9836 9710 01... -
Page 9: Operation
The support handle can be attached to any side of the tool: Remove the support handle by turning it counterclockwise. Attach the support handle to the opposite side. Tighten the handle clockwise to the recommended torque. © Atlas Copco Industrial Technique AB - 9836 9710 01... -
Page 10: Operating Instructions
Operation LSV48 SA085 Operating instructions Operating instructions © Atlas Copco Industrial Technique AB - 9836 9710 01... -
Page 11: Free Speed
LSV48 SA085 Operation Free speed Model Min r/min Max r/min LSV48 SA085-NPT 8500 © Atlas Copco Industrial Technique AB - 9836 9710 01... -
Page 12: Service
For accurate lubricating properties – use Rhenus LKR 03 fluid grease. The requisite amount of grease is max. 17 cm . Normal grease consumption is 10 ml/ 1000 running hours. Grease gun will give 0.25 ml/ push. © Atlas Copco Industrial Technique AB - 9836 9710 01... -
Page 13: Lubricating Guide
General purpose Brand Bearings Energrease LS-EP2 Castrol Spheerol EP L2 Esso Beacon EP2 Rembrandt EP2 Mobil Mobilegrease XHP 222 Shell Alvania EP2 Texaco Multifak EP2 Molycote BR2 Plus © Atlas Copco Industrial Technique AB - 9836 9710 01... -
Page 14: Dismantling/Assembling Instructions
Service LSV48 SA085 Dismantling/Assembling instructions Instructions for vane motor © Atlas Copco Industrial Technique AB - 9836 9710 01... - Page 15 Metal, Steel Ring screw Metal, Steel Autobalancer Metal, Steel Strainer screw Metal, Steel Strainer Plastics, Other, PA plastic Handle Metal, Aluminium Bushing Metal, Brass Lever Metal, Steel Adapter Metal, Steel © Atlas Copco Industrial Technique AB - 9836 9710 01...
- Page 16 Recycling LSV48 SA085 *The rotor blades (vanes) in the product contain PTFE, the normal health and safety recommendations concerning PTFE must be observed. © Atlas Copco Industrial Technique AB - 9836 9710 01...
- Page 20 Original instructions © Copyright 2022, Atlas Copco Industrial Technique AB. All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. Atlas Copco Industrial This applies in particular to trademarks, model denominations, part numbers Technique AB and drawings.
