Printed Matter No. 9839 1766 01
Publication Date 2019-07-18
Valid from Serial No. D0840001
LTP61 H1500-25 (850-1500 Nm)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
LTP61 H1500-25
8431080056
WARNING
Product Instructions
Nutrunner
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Atlas Copco LTP61 H1500-25
Summary of Contents for Atlas Copco LTP61 H1500-25
- Page 1 Printed Matter No. 9839 1766 01 Nutrunner Publication Date 2019-07-18 Valid from Serial No. D0840001 Product Instructions LTP61 H1500-25 (850-1500 Nm) 8431080056 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Tightening of threaded connections ............ 10 Service instructions ................ 10 Lubrication Instructions................... 11 Rust protection and cleaning ............... 11 Lubrication guide ................. 11 For maximum performance .............. 11 Dismantling/Assembling Instructions .............. 11 Assembly ..................... 11 Recycling ....................... 13 Environmental Regulations................ 13 Recycling information .................. 13 © Atlas Copco Industrial Technique AB - 9839 1766 01... -
Page 3: Product Information
■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions. -
Page 4: Website
Please consult the Atlas Copco website for more information www.atlascopco.com/sds. Product safety video for nutrunners Learn more about safety features on Atlas Copco nutrunners and what measures the operator has to take for a safe operation. Click the link or scan the QR code below to view the video: https://www.youtube.com/watch?v=FAh6yttvUpw... -
Page 5: Technical Product Data
Vibration value <2.5 m/s Weight 6.8 kg 14.5 lb Technical Product Data Technical Product Data can be found on either ServAid, or the Atlas Copco website. Please visit: https://servaid.atlascopco.com or www.atlascopco.com. Service Overview Service recommendations Preventive maintenance is recommended at regular intervals. See the detailed information on preventive maintenance. -
Page 6: Installation
Air quality ■ For optimum performance and maximum product life we recommend the use of compressed air with a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration type air dryer. ■ Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of liquid water. -
Page 7: Operation
Make sure that the rotational direction of the tool is correct before starting the tool. ► Keep your hands away from the reaction bar while using the tool. ► © Atlas Copco Industrial Technique AB - 9839 1766 01... - Page 8 (A – C) of the machine from point (B). Start- ing at point (B), draw two lines at angles of +15 and -15 respectively from the marked 90 -line. Mark the area (F) between the drawn lines. © Atlas Copco Industrial Technique AB - 9839 1766 01...
-
Page 9: Tightening Torque
The air pressure is set at as high a level as possible up to max 6.3 bar – with the aid of a compressed air regulator. Installation of an Atlas Copco regulator, type MIDI REG 15, is recommended. Loosen the set screw and adjust the torque setting by means of the screw. The torque is increased when screwing the screw clock-wise. -
Page 10: Service
Clean all parts thoroughly in white spirit or similar cleaning agent. To prevent clogging and decreased power, it could be necessary to clean the strainer (if used) and the exhaust filter between the overhauls. © Atlas Copco Industrial Technique AB - 9839 1766 01... -
Page 11: Lubrication Instructions
With extreme dry air the service life of vanes and machine performance might be reduced. A daily supply of 0.1 – 0.2 ml oil into the machine inlet will improve the machine performance. Alternatively consider an automatic lubricator device, Atlas Copco oil fog lubricator DIM, or single point lubricator DOS, which will improve the machine performance. - Page 12 Service LTP61 H1500-25 © Atlas Copco Industrial Technique AB - 9839 1766 01...
-
Page 13: Recycling
Metal, Steel Plate Metal, Steel Silencer Plastics, Other, PA *The rotor blades (vanes) in the tool contains PTFE, the normal health and safety recommendations con- cerning PTFE must be observed. © Atlas Copco Industrial Technique AB - 9839 1766 01... - Page 16 Original instructions Atlas Copco Industrial © Copyright 2019, Atlas Copco Industrial Technique AB. All rights reserved. Any Technique AB unauthorized use or copying of the contents or part thereof is prohibited. This SE-10523 STOCKHOLM applies in particular to trademarks, model denominations, part numbers and drawings.
