- Page 1 11, 180, 190, 220, 230, 270, 280, 390, 400 Safety and operating instructions Handheld hydraulic breakers © 2015 Construction Tools EOOD | No. 3392 5206 01f | 2015-03-25 Original instructions...
-
Page 3: Table Of Contents
LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Contents Contents Introduction............... . 5 About the Safety and operating instructions. - Page 4 Contents LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Technical data..............19 Troubleshooting.
-
Page 5: Introduction
Safety and operating instructions Introduction Thank you for choosing a product from Atlas Copco. Since 1873, we have been committed to finding new and better ways of fulfilling our customers' needs. Through the years, we have developed innovative and ergonomic product designs that have helped customers improve and rationalize their daily work. -
Page 6: Safety Instructions
Safety and operating instructions LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Drugs, alcohol or medication Safety instructions WARNING Drugs, alcohol or medication To reduce the risk of serious injury or death to Drugs, alcohol or medication may impair your yourself or others, read and understand the Safety judgment and powers of concentration. -
Page 7: Operation, Precautions
LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Safety and operating instructions WARNING Hydraulic oil at high pressure WARNING Operating pressure Thin jets of hydraulic oil under high pressure can If the maximum operating pressure for the hydraulic penetrate the skin and cause permanent injury. - Page 8 Safety and operating instructions LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Select, maintain and replace consumables/ ► WARNING Dust and fume hazard working tools/ other accessories as recommended Dusts and/or fumes generated or dispersed when in the operating and safety instructions. Incorrect using the machine may cause serious and permanent selection or lack of maintenance of consumables/ respiratory disease, illness, or other bodily injury (for...
- Page 9 LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Safety and operating instructions WARNING Splinters hazard WARNING Vibration hazards Using the insertion tool as a hand struck tool can Normal and proper use of the machine exposes the result in splinters hitting the operator and can cause operator to vibration.
-
Page 10: Maintenance, Precautions
Safety and operating instructions LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Participate in health surveillance or monitoring, ► WARNING Noise hazard medical exams and training programs offered by High noise levels can cause permanent and disabling your employer and when required by law. hearing loss and other problems such as tinnitus (ringing, buzzing, whistling, or humming in the ears). -
Page 11: Overview
Atlas Copco hydraulic power packs or, by means of an It is important to choose the correct size of breaker Atlas Copco LFD oil flow divider, with most hydraulic for the work to be performed. excavators, backhoe loaders and tractors. -
Page 12: Data Plate
Safety and operating instructions LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Data plate Accumulator Construction Tools EOOD The accumulator must only be charged with Nitrogen. NOTICE Only certified personnel are allowed to work with the accumulator. xxxxx EHTMA category The machine is clearly marked with EHTMA categories. -
Page 13: Quick-Release Couplings
(158°F). flows. Nipple At delivery, breakers LH11, LH 180 and LH 190 E are factory set to 20 l.p.m (EHTMA C). They can not be adjusted to a higher flow. LH 220, LH 220 HBP, LH 230 E, LH 230 E HBP, LH 270, LH 270 HBP, LH 280 E and LH 280 E HBP are supplied factory set to 30 l.p.m (EHTMA D). -
Page 14: Insertion Tool
Safety and operating instructions LH 11, 180, 190, 220, 230, 270, 280, 390, 400 1. Disconnect the breaker from the power source. Moil point 2. Fix the breaker in vertical position in a vice or in The moil point is only used for another way so that the breaker is fixed. -
Page 15: Fitting And Removing The Insertion Tool
LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Safety and operating instructions Check if the gauge’s hole (A) can be pushed down ● Start and stop on the insertion tool’s shank, this means that the shank is worn out and the insertion tool should be Start replaced. -
Page 16: Starting A Cut
Safety and operating instructions LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Always connect T and P hoses before starting. ♦ Breaking ♦ Let the machine do the work; do not press too Starting a cut hard. The vibration-reducing handle must ♦... -
Page 17: When Taking A Break
LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Safety and operating instructions Change damaged parts immediately. ♦ When taking a break Replace damaged and worn components in good ♦ time. ♦ During all breaks you must place the machine in such a way that there is no risk for it to be Make sure that all the attached and related ♦... -
Page 18: Disposal
Safety and operating instructions LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Disposal A used machine must be treated and scrapped in such a way that the greatest possible portion of the material can be recycled and any negative influence on the environment is kept as low as possible. -
Page 19: Technical Data
18-22 28 x 160 19.1 95-115 18-22 32 x 152 19.1 95-115 18-22 32 x 160 19.1 95-115 18-22 LH 190 E 25 x 108 22.1 95-115 18-22 28 x 152 23.7 95-115 18-22 28 x 160 23.7 95-115 18-22 32 x 152 23.7... - Page 20 Safety and operating instructions LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Shank Impact Accumulator Operating dimension *Weight Length freq. pressure pressure Flow rate EHTMA (mm) (kg) (mm) (Hz) (bar) (bar) (l/m) Category 28 x 160 22.1 25-33 110-125 18-30 D (C)
- Page 21 42.1 27.4 1380-1600 ⁄ 42.1 27.4 1380-1600 ⁄ ⁄ 42.1 27.4 1380-1600 ⁄ 42.1 27.4 1380-1600 ⁄ ⁄ LH 190 E 1 x 4 ⁄ 48.7 25.6 1380-1600 52.3 27.4 1380-1600 ⁄ 52.3 27.4 1380-1600 ⁄ ⁄ 52.3 27.4 1380-1600 ⁄...
-
Page 22: Noise And Vibration Declaration Statement
LH 180 (Hex 25x108, 20 lpm) 15.1 LH 180 (Hex 32x160, 20 lpm) 14.9 LH 190 E (Hex 25x108, 20 lpm) LH 190 E (Hex 32x160, 20 lpm) © 2015 Construction Tools EOOD | No. 3392 5206 01f | 2015-03-25 Original instructions... - Page 23 LH 11, 180, 190, 220, 230, 270, 280, 390, 400 Safety and operating instructions Noise Vibration Sound pressure Sound power Three axes values Declared values Declared values EN ISO 11203 2000/14/EC EN ISO 28927-10 r=1m dB(A) uncertainty guaranteed value spreads Type rel 20µPa factor dB(A)
-
Page 24: Ec Declaration Of Conformity
Directive 2006/42/EC (Machinery Directive) and 2000/14/EC (Noise Directive), and the harmonised standards mentioned below. Guaranteed sound power level Measured sound power level [dB(A)] [dB(A)] LH 11 LH 180 LH 190 E LH 220 LH 220 HBP LH 230 E LH 230 E HBP LH 270 LH 270 HBP LH 280 E... - Page 28 Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers, and drawings. www.atlascopco.com...
