7.8 Technical Parameters of Power over Ethernet (PoE)

Standards IEEE 802.3at-2009 (PoE+) and IEEE 802.3af-2003 (PoE) are supported. Ca-
bling needed is Category 5, up to 12.5 . It is possible to use a passive PoE injector.

PoE PD: parameters for opposite PSE

Input voltage range
Power available
Maximum current
Table 37: PoE PD: parameters for opposite PSE

PoE PSE parameters

Power supply needed
Power available

7.9 Other Technical Parameters

Parameter
CPU power
Flash memory
RAM
M-RAM
42.5 – 57 V
25.50 W
600 mA
44 – 57 V, 65 W
2x 25.50 W (ETH0, ETH1)
Table 38: PoE PSE parameters
Description
2 DMIPS per MHz
256 MB
512 MB
128 kB
Table 39: Other technical parameters
49
SmartFlex SR306
