LOGIQ 7/LOGIQ 7 Pro Quick Guide

Patient Environmental Devices

1. Peripheral Device (Signals I/O Port, Power In)
2. Front Panel (Signal I/O Port, Power Out)
3. Non-Imaging Probes
4. Imaging Probes
5. Probe Port
6. 4D probe cable connector
7. ECG Cable
8. PCG Sensor
9. Physio-Signal Input Panel
10. Rear Panel
Safety
Direction 5307393-100 Rev. 1
16
10
11
17
12
18
13
19
20
15
22
23
24
Figure 1. Patient Environmental Devices
11. Signals I/O Port
12. Power Out
13. Signals I/O Port
14. Footswitch Connector
15. Power In
16. Peripheral Devices
17. Signals I/O Port
18. Power In
19. InSite Modem (Signal I/O Port)
1
2
14
25
21
3 6
5
9
7
4
8
20. Power Telephone Line
21. Footswitch
22. Power Line (AC~)
23. Ground Line
24. Power Cable with Protective Earth
25. DVD Multi Drive
