Thunderbolt™ 3 Dock with USB-C™ Laptop Compatibility | Dual 4K DisplayPort™ | 60W PD
Product Diagram (TB3CDOCKDP)
Front
1
2
Port/LED
• Solid: Indicates that the Docking Station is
1
Power LED
connected and receiving power.
• Used to connect your Host Computer to the
Docking Station.
Thunderbolt 3 Host
• Used to charge the Host Computer.
2
Port
• Used to mount the Docking Station
3
Mounting Holes x 4
• Used as a charging port (e.g. mobile device) or
4
USB-A Port
for connecting a USB storage device (e.g. flash
drive) or USB peripheral device (e.g. mouse).
• Used to connect an Audio Device to the
5
3.5mm Audio Port
Docking Station.
• Used to secure the Docking Station to a
secure stationary object.
6
Lock Slot
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
3
4
5
Function
Note: A maximum of 60 watts of Power Delivery
is available for the connected Host Computer.
Note: Located on the bottom of the Docking
Station.
Note: Located on the side of the Docking
Station.
Back
6
7
Port
RJ45 Port
7
RJ45 LEDs
8
USB-A Ports x 2
9
USB-C Port
10
USB-C Port
11
DisplayPort Ports x 2
12
DC 20V Port
Requirements
For the latest requirements and to view the full User Manual, please visit
www.startech.com/TB3CDOCKDP.
Quick-Start Guide
8
9
10
11
Function
• Used to connect the Docking Station to a
Network Device.
• Green: Indicates that the Docking Station is
receiving a link speed of 10 Mb, 100 Mb or 1 Gb.
• Flashing Amber: Indicates network activity.
• Used to connect a USB storage device (e.g. flash
drive), or USB peripheral device.
• Used to connect a USB-C storage device (e.g.
flash drive), or USB-C peripheral device.
• Used to connect a USB-C storage device (e.g.
flash drive), or USB-C peripheral device.
• Used as a charging port.
• Used to connect two Video Display Devices to
the Docking Station.
• Used with the Universal Power Adapter to
power the Docking Station.
Manual Revision: December 18, 2019 3:24 PM
12
