- Page 1 Thunderbolt™ 3 Dock with USB-C Laptop Compatibility | Dual 4K DisplayPort | 60W PD Actual product may vary from photos User Manual SKU#: TB3CDOCKDP For the latest information and specifications visit www.startech.com/TB3CDOCKDP Manual Revision: 12/18/2019...
- Page 2 This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual...
-
Page 3: Safety Statements
• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o pericoli per la sicurezza. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 4 • Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så sätt att risk för snubblingsolyckor och andra olyckor kan undvikas. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 5: Table Of Contents
Thunderbolt 3 Host ................5 USB-C Host..............................6 Connecting Peripherals .................6 USB-A Port (Charging) ..........................6 3.5 mm Audio Port ............................ 7 RJ45 Port (Network Device) ........................8 USB-A Port ..............................8 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 6 DisplayPort Port ............................9 Compatible Active Adapters ......................... 10 LED Indicators ..................11 Power LED ..............................11 RJ45 LED ............................... 11 Video Resolution ..................12 Mounting the Docking Station ............13 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 7: Product Diagram
Product Diagram Front View Power LED USB-A Port Thunderbolt 3 Host 3.5 mm Audio Port Port Mounting Holes x 4 Lock Slot (side) (bottom) To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 8: Rear View
Rear View USB-A Ports x 2 USB-C Ports x 2 DisplayPort Ports DC 20V Port RJ45 Port To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 9: Product Information
C), an additional adapter (sold separately) is required. See Compatible Active Adapters section for further details. Cables • DisplayPort Cable x 1 • Thunderbolt 3 Cable x 1 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 10: Operating Temperature
Universal Power Adapter. 2. Connect the Universal Power Adapter to the DC 20V Port on the Docking Station and to an AC Electrical Outlet. DC 20V Port To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 11: Driver Installation
Host Computer. • Connect a Thunderbolt 3 Cable (included) to the Thunderbolt 3 Host Port on the Docking Station and to a Thunderbolt 3 port on the Host Computer. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 12: Usb-C Host
USB Battery Charging Specification Revision 1.2. If you’re only using the front USB 3.0 port to charge a device, a connection to a host laptop isn’t required. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 13: 3.5 Mm Audio Port
Docking Station. 2. If connecting speakers, connect the other end of the 3.5 mm Audio Cable to the Audio In Port on the Audio Device. 3.5 mm Audio Port To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 14: Rj45 Port (Network Device)
USB drives (e.g. M.2 SSD). If you have connected a high power USB drive to the rear USB-A Port on the Docking Station you may experience the following: To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 15: Usb-C Port
The USB-C Port can be used as a charging port (e.g. cell phone, tablet, etc.). 1. Connect a USB-C Cable to the USB-C Port on the Docking Station and to a USB port on a compatible device. USB-C Port (Charging) To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 16: Displayport Port
• Connect a USB Peripheral’s USB-C Connector to the USB-C Port on the Docking Station. USB-C Port DisplayPort Port The two DisplayPort Ports let you connect two Displays to the Host Computer. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 17: Compatible Active Adapters
Compatible Active Adapters Type of Adapter Needed (sold separately) Display HDMI DisplayPort to HDMI 4K Audio/Video Converter (DP2HD4KS) DisplayPort to DVI Adapter (DP2DVIS) DisplayPort to VGA Adapter (DP2VGA2) To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 18: Led Indicators
• Green: Indicates that the Docking Station is receiving a link speed of 10Mbps, 100Mbps or 1Gbps. • Flashing Amber: Indicates network activity. Amber and Green RJ45 LEDs To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 19: Video Resolution
DP Alt Mode 2K: 2560x1440 60Hz or 2560x1600 UHD: 30Hz 3840x2160 Full HD: 60Hz 1920x1080 or 1920x1200 2K: 2560x1440 60Hz Thunderbolt 3 or 2560x1600 UHD: 60Hz 3840x2160 4K: 4096x2160 60Hz To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 20: Mounting The Docking Station
Failure to do so may result in personal injury, equipment damage, and/or surface damage. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 21 Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
