8.
WARNING ‒ Risk of injury!
Scratched glass in the appliance door may develop
into a crack.
▶
Do not use any harsh or abrasive cleaners or
sharp metal scrapers to clean the glass on the
oven door, as they may scratch the surface.
Clean the door panes on both sides with glass
cleaner and a soft cloth.
9.
Dry the door panes and refit them.
18.4 Fitting the door panes
WARNING ‒ Risk of injury!
If a door pane or appliance door has not been installed
correctly, this is dangerous.
▶
Make sure that all of the door panes and the appli-
ance door have been correctly fitted before you
switch the appliance back on again.
1. Tip: When fitting the door panes, make sure that
they are in the original order.
Insert the intermediate pane so that the
the right-hand side is pointing upwards.
2. Check the fit of the four spacers and two seals.
Place the spacers on the centre of the lines
‒
Secure the seals at the corners
‒
3.
Insert the intermediate pane with spacers and seals
in the direction of the arrow
The arrow on the intermediate pane must line up
with the arrow on the frame
arrow on
⁠ ⁠ .
⁠ .
⁠ .
⁠ .
4. Insert the second intermediate pane without the
spacers and seals, and slide it in the direction of the
arrow until it is inserted in the frame
The arrow on the intermediate pane must line up
with the arrow on the frame
5.
Push down on the intermediate pane around
slide the retainer
until it clicks into place.
a The retainer has been inserted.
6.
Place the inner pane onto the appliance door so
that the number is legible at the bottom right. In-
sert the inner pane into the fixing rail
towards the back.
Appliance door en
⁠ .
⁠ .
in at an angle and push down
at an angle
,
